Honeywell

Hpm I/o Link Pc Board

I/O Type:Digital or analog I/O
Voltage Range:24 VDC (±10%)
Isolation:1500 VAC typical
Environmental Rating:Operates in -40°C to +70°C

Control Processor module

5 VR supplyvoltage:5 V DC ± 10%
5 VR supplycurrent:Max. 10 mA
Output supplyvoltage:14-31 V DC
Make: SAFT
Type2: LS14500CFG
Material: Lithium Thiony Chloride
Voltage: Nominal 3.6 V
Capacity: > 2 Ah

Power Supply Unit

Operating temperature:-5°C-+70°C (+23°F-+158°F)
Storage temperature: -40°C-+85°C (-40°F-+185°F)
Relative humidity: 10-95% (non condensing)
Approvals:CE, TUV, UL, CSA, FM
24 V supply voltage: 24 V DC -15%-+30%
24 V supply current:
< 6 A at 24 Vin (16 A load)
< 7 A at 20.4 Vin (16 A load)
Inrush current: < 5 A at 24 Vin
Hold-up time: < 1ms

Universal Safety Interface

UNIVERSAL SAFETY INTERFACE
MMEM CC, EUCN
Approvals: CE, TUV, UL, CSA, FM
5 V supply voltage: 5 V DC ± 5%
5 V supply current: max 1.2A
Operating temperature:-5°C - +70°C (+23°F - +158°F)
Storage temperature: -40°C - +85°C (-40°F - +185°F)
Relative humidity: 10 - 95% (non condensing)

Analog Input Module

Input Type Current (2-wire or self-powered transmitters)
Input Channels 16 Channels (16 Single Ended)
Common Mode Rejection Ratio, dc to 60 Hz 70 dB
A/D Converter Resolution 16 bits
Input Range 4-20 mA (through 200 Ω)
Normal Mode Rejection Ratio, at 60 Hz 20 dB
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.0 Hz
Maximum Normal Mode Input ± 30 Volts

Hlai/sti galvanic isolator module

Description : HLAI/STI FTA, GI/IS MC-GAIH13
CE compliant, conformally coated
Redundancy
Channels : 16
Galvanically Isolated
Terminals : Compression
Size B : 12 inches (307 mm)

Analog Input Module

Inputs per module:8 (isolated)
Input types:mV, V, T/C, RTD, ohms, mA
A/D Converter:One per module
A/D Resolution:15 Bits
Update rate:500ms
Long term Stability:0.1% per year

Digital Input Module

Inputs per module:16 (sinking)
Input Voltage Range:10 VDC to 32 VDC
Peak Voltage;32 VDC
AC Frequency:N/A
Minimum ON Current:1.0 mA
Maximum OFF Current:0.7 mA
OFF to ON response time:4 ms max
ON to OFF response time:4 ms max

PROBE LOW TEMP 20FT PH

Measuring Range: 0–14 pH.
Process Fluid: 0°C to 50°C (32°F to 122°F)
Response Time: ≤30 seconds
Cable: 20 feet shielded, UV-resistant
Pressure Rating: ≤5 bar (72.5 psi)
Calibration: 2–3 point calibration

Analog Input Module

ANALOG CARD
0(4)-20 MA INPUT
16 CHANNEL
24 VDC SUPPLY
CARD MOUNT

Universal Input Output IOTA

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Universal Input Output IOTA Red

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Digital Output Module

Output Channels:32
Output Type:SINK (Open Drain)
Load Voltage:15 30 VDC Maximum
Load Current:0.1 A per channel (Max)
On-State Voltage:0v VDC
Off-State Voltage:24 V (typ)
Off-State Leak Curren:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

Revision C IO Link Cable

Type: IO Link Cable
Part Number: 51202341-102 Revision C
Country of Origin: USA
Cable Length: 1 meter
Shielding: Shielded

HORIZONTAL BACK PLANE PWA

Operating Voltage: 24 V DC
Input Current: 1 A
Output Power: 20 W
Bus Interface: RS-485
Operating Temperature: -20°C to +70°C
Humidity Range: 5% to 95% non-condensing
Certifications: CE, UL, ISO 9001

IOL FOE PM VIOLET - 0.5M

Cable Type: Fiber Optic Ethernet.
Connector Type: IOL (Input/Output Link) connectors.
Length: 0.5 meters
Operating Voltage: 24 VDC.
Operating Current: 0.5 A.
Maximum Power Consumption: 12 W

Digital Input Module

PC BOARD
LOGIC CARD
NON-REDUNDANT
IOTA
9 INCH

DIGITAL INPUT MODULE

Approvals: CE, TUV, UL, CSA, FM
Number of input channels: 16
Input type: According to DIN (=NAMUR)
Switch level: 1.4-1.9 mA
Hysteresis: 0.2 mA ± 0.05 mA
Field wire resistance: Max. 50 Ω
output voltage 7.9-8.7 V
output current 170 mA (short-circuitproof)3
Maximum load capacitance: 100 nF
Test current: Typically 0.5 mA
Output voltage: Typically 0.5 V DC
Field fault voltage: Max. 250 V AC

Digital Output IOTA Redundant

Output Channels:32
Output Type SINK: (Open Drain)
Load Current :0.1 A per channel (Max)
On-State Voltage 0v VDC (load current @:0.1A max
Off-State Voltage:24 V (typ),
Off-State Leak Current:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

Digital Input IOTA Redundant

Power supply:24V DC
Rated Current:55mA at 24V
Power Consumption:1.32W at 20mA
Power/DCS to Field:1500 VAC
DCS side connections:
37 pin DSUB connector on CC-UGIA01
Voltage Input:24V DC
Interface to DCS:4 to 20mA with HART

Analog Output IOTA Redundant

Power supply 24V DC
Rated Current 55mA at 24V
Power Consumption 1.32W
Power/DCS to Field 1500 VAC
DCS side connections 37 pin
DSUB connector on CC-UGIA01
Voltage Input 24V DC
Current Input 4 to 20mA with HART,
CC-UGAI01 in sink mode.
Open wire current <150uA

Digital module

Channels: 16 digital channels
Input Type: 24 VDC
Isolation:500 VDC
Update Rate: ≤10 ms
Power Consumption: ≤5 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing.

SC S300 SAFETY CONTROLLER SIL3

Input Voltage: 24 VDC (±10%)
Output Voltage: 24 VDC
Current Capacity: Typically up to 5A
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing

SC S300 SAFETY CONTROLLER SIL3

Digital Inputs:24 VDC
Cycle Time: <10 ms
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Contact Rating: 5A @ 250VAC
Operating Force: 1.8N minimum
Release Force: 0.1N minimum
Pre-travel: 1.5mm maximum

Digital Input Module

Input Channels:32
Galvanic Isolation: 1500 VAC RMS or ±1500 VDC
Isolation Technique:Optical (in IOM)
DI Power Voltage Range:18 to 30 VDC
ON Sense Voltage/Current:13 VDC (min) or 3 mA (min)
OFF Sense Voltage/Current:5 VDC (max) or 1.2 mA (max)
nput Impedance:4.2 K
Absolute Delay Across Input Filter and Isolation:5 ms ± 20%
