GE Genius I/O

Bus controller module

Series:Genius Bus I/O
Part Number:IC697BEM731F
Operating Voltage:5.0 Volt DC
Backplane Current:1.3 Amps
Bus Cable:Belden 9182 type cable
Module Width:Single Slot
Description:Genius I/O Bus Controller
Application:IC66 PLC System
Location:IC66 PLC Rack
Connectors:3PL and 1PL Ports
LED Indicators:3 LED Indicators
Average Weight:2.0 Pounds

Sink I/O terminal block

Input voltage range: 10-30V DC
Output voltage: 24V DC typical
Input: Up to 2mA per channel
Output: Rated for up to 2A per channel
Wiring Capability:  typically 16-24 AWG
Operating Temperature: -40°C to +60°C
Humidity Tolerance: Up to 95% non-condensing

DC sink I/O terminal block

Series:Genius I/O
Voltage Ratings:12/24 Volts DC
Operating Temperature:0 to 60 degrees Celsius
Storage Temperature:-40 to 100 degrees Celsius
Relative Humidity:5%-95%, Non-condensing

Terminal block

Voltage Rating: Up to 250V AC/DC
Current Capacity: Typically up to 10A
Operating Temperature: -40°C to +70°C
Humidity Tolerance:
Up to 95% non-condensing

Hand-Held Monitor

Hand-held monitor
Hardware configuration
fault clearing
I/O forcing and bus selection.
0-60 Degree Celsius (32-140 Degree Fahrenheit)
-40 to 70 Degree Celsius (-40 to 158 Degree Celsius)
Product Description Hand-held monitor
115 to 230V AC, 47 to 63 Hz
Fully Charged Operation 6 hours
4 lines of 16 characters each
20 sealed keys
English, German, French/Italian

Normally Closed Relay Output Block

Series Genius I-O
Part Number IC660BBR100
Product Type Relay Output Block
Output Block Type Normally Closed
Number of Outputs 16
Output Configuration 4 Groups of 4 Outputs Each
Output Voltage Type AC or DC
Power Requirements 87 Milliamps at 115 Volts AC

GENIUS BLOCK IN/OUT MODULE

ELECTRONIC ASSEMBLY
FOR GENIUS I/O BLOCK
115 VAC
8 CIRCUIT
LOW LEAKAGE

GENIUS BLOCK IN/OUT MODULE

IC660EBD101D
GENIUS I/O
16-circuit input/output module
Supports source and sink input types
24V DC

Electronic assembly block

16-circuit source/sink input and output
For 3-wire electromechanical and solid-state sensors
Interfaces with several discrete DC actuators and sensors
Part of the Genius I/O product family
Two versions available: 24/48 VDC and 24 VDC versions

Analog I/O Module

Series:Series 90-30
Part Number:IC693ALG442
Product Description:Analog Current/Voltage Combination Module
No of Output Channels:2, single-ended
Update Rate:8 milliseconds
Resolution at 4-20 mA:0.5 microamps
Resolution at 0-20 mA:0.625 microamps
No of Input Channels:4 differential
Input Range:-0-10 Volts, -10 to 10 Volts
Input Impedance:800 K Ohms

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TSD100
Product Type:Terminal assembly
Operating Temperature:32 to 140 degrees Fahrenheit
Number of Circuits per I/O Block:8
Supported Memory:EEPROM

Genius Block I/O module

Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660TSD021
Product Type:Terminal assembly
Compatibility:IC660BBD021 I/O Block
Solid-State Sensors:Supported
Relative Humidity:5 to 95%
Input Filter Time:5 to 100 milliseconds

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TSD020
Product type:Terminal assembly
3-Wire Solid-State Sensors:Supported
Operating Temperature:0 to 60 degrees Celsius
Inrush Current:10 Amps

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TSA100
Product Type:Terminal assembly
Operating Temperature:0 to 60 degrees Celsius
Heat Dissipation Rating:6 Watts

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TSA020
Product Type:Terminal assembly
Operating Temperature:0 to 60 degrees Celsius
Wire Gauge:12 AWG Wire

Genius Block I/O module

Brand:GE Fanuc
Series:Genius I-O
Part number:IC660TBR101
Product type:Terminal assembly
Compatibility:IC660BBR101
Relay type:Normally open

Genius Block I/O module

Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660TBR100
Product type:Terminal assembly
Compatibility:IC660BBR100
Operating temperature:0 to 60 degrees Celsius
Block Circuit Type:Normally Closed

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD120
Block Type:High-speed counter
Operating Voltage:93 to 132 Volts AC / 10 to 30 Volts DC
Frequency/Ripple:47 to 63 Hertz / 10% maximum
Required AC Power:60 milli Amps typical / 250 milli Amps maximum

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD110
Block Type:16 circuits, inputs only
Rated Voltage:115 Volts AC Volts
Operating Voltage:93 to 132 Volts AC
Frequency:47 to 63 Hertz
Power Supply Dropout Time:1 cycle
Input to Ground Isolation:1500 Volts

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD025
Block Type:DC 32 circuit discrete input and output
Rated Voltage:5/12/24 Volts DC
Operating Voltage:4.9 to 5.3 Volts DC
Ripple:10% maximum (12/24 Volts) / 1% maximum (5 Volts)
Heat Dissipation (Maximum):18 Watts maximum
Block to Block Isolation:850 Volts

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD024
Block Type:DC 32 circuit discrete input and output
Rated Voltage:12/24 Volts DC
Operating Voltage:10 to 30 Volts DC
Ripple:10% maximum
Heat Dissipation (Maximum):18 Watts maximum
Block to Block Isolation:850 Volts

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD023
Block Type:16 circuit discrete input and output
Rated Voltage:24 Volts DC
Operating Voltage:18 to 30 Volts DC
Ripple:10% maximum
Power Supply Dropout Time:10 milliseconds (DC)
Block to Block Isolation:1500 Volts for 1 minute

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD022
Block Type:16 circuit discrete input and output
Rated Voltage:24 Volts DC
Operating Voltage:18 to 30 Volts DC
Ripple:10% maximum
Power Supply Dropout Time:10 milliseconds (DC)

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBD021
Block Type:16 circuit discrete input and output
Rated Voltage:24 Volts DC
Operating Voltage:18 to 30 Volts DC
Ripple:10% maximum
Power Supply Dropout Time:10 milliseconds (DC)
Block to Block Isolation:1500 Volts for 1 minute

Genius Block I/O module

Series:Genius I-O
Part Number:IC660TBA106
Block Type:Six analog input circuits
Rated Voltage:115 Volts AC / 125 Volts DC
Frequency/Ripple:47 to 63 Hertz / 10% maximum ripple
Power Supply Dropout Time:1 cycle (AC) / 10 milliseconds (DC)
Heat Dissipation (Maximum):12 Watts
Block to Block Isolation:1500 Volts for 1 minute
Group to Group Isolation:1500 Volts RMS
