The warranty of industry automation components and parts that "amikon" 1-year warranty.
S120 SERIES CIRCUIT BOARD
Voltage: 24 V DC (±10%)
Current Consumption: ≤500 mA
Digital I/O: 24 V DC
Analog Inputs: +/-10 V or 4–20 mA
Operating Temperature: 0°C to +55°C (32°F to 131°F).
Storage Temperature: -40°C to +70°C (-40°F to 158°F).
Humidity: ≤95% RH (non-condensing).
Vibration Resistance: 5–150 Hz, ≤1.5 g
Inverter Triggering Board
Control Circuit: 24 V DC (±10%)
Isolation Voltage: ≥2500 V AC
Output Pulse Voltage: 12–24 V DC
I/O Channels: Digitat inputs (24 V DC)
Power Consumption: ≤15 W
Vibration Resistance: ≤2.5 g (5–150 Hz)
BOARD
ASKPCB
The board complies with UL 796 standards
Flame rating: V-0,
ensuring good fire resistance
Minimum conductor width: 0.28 mm
Maximum operational temperature: 130°C
