Allen-Bradley

OPERATOR INTERFACE

OPERATOR INTERFACE
PANELVIEW STANDARD
KEYPAD & TOUCH
PANELVIEW 550
5.3 INCH DISPLAY
256 X 128 PIXELS
MONOCHROME DISPLAY
REMOTE I/O
RS-232
100-240 VAC INPUT
50/60 HZ

SMC Flex Interface Board

INTERFACE BOARD
SMC FLEX INTERFACE PCB BOARD
FOR SOFTSTART
Input Voltage:24V DC
Communication Ports:RS-485, EtherNet/IP
Current/Power Ratings:5A at 240V AC
Analog I/O: Standard 0-10V

Inverter Control Board

Inverter Control Board
Input Control Signals:0–10 V or 4–20 mA
Power Regulation: 600–1200 V DC link
Current Handling:50–100 A
Switching frequency range: 1–6 kHz
Operating Temperature: 0–60°C

Circuit Board

Power Input: 24V DC internal
Input Ranges:0–10 V DC / 4–20 mA
Resolution: 12-bit or 16-bit
Digital I/O: 120V AC
Temperature Range: 0–60°C

OPERATOR INTERFACE

OPERATOR INTERFACE
PANELVIEW PLUS 7
TOUCH SCREEN
12.1 INCH DISPLAY
1280 X 800 PIXELS
WIDE ASPECT-RATIO COLOR
EMBEDDED SWITCH/DLR
24 VDC INPUT
WINDOWS 10 IOT CORE

Flex I/O Terminal Base Unit

TERMINAL BASE
FLEX I/O
16 I/O TERMINALS
18 COMMON TERMINALS
18 +VOLTAGE TERMINALS
SCREW-CLAMP
CONFORMAL COATED
OPEN STYLE
DIN MOUNT

PROGRAMMABLE SAFETY CONTROLLER

1756L82ES
PROGRAMMABLE SAFETY CONTROLLER
GUARDLOGIX 5580
5 MB STANDARD MEMORY
2.5 MB SAFETY MEMORY
175 ETHERNET/IP NODE CAPACITY
1 USB 2.0 PORT
1 ETHERNET/IP PORT (10/100 MBPS/1 GB SPEED)
0 TO 60 DEGREE C OPERATING TEMPERATURE

COMMUNICATION INTERFACE MODULE

1771ACN15
COMMUNICATION INTERFACE MODULE
1 PORT CONTROLNET
SINGLE-PORT NON-REDUNDANT MEDIA
CONTROLNET 1.5 AND BEYOND
1 AMP
5 VDC

SYNCHLINK BASE BLOCK

1751SLBA
SYNCHLINK BASE BLOCK
CONVERTS SYNCHLINK TO ELECTRICAL SIGNALS
TO INTERFACE UP TO 4 FIBER 4-PORT SPLITTER BLOCKS
1.2 AMP
600 MA
24 VDC
OPEN STYLE
MOUNTABLE

Digital output module

1769OG16
OUTPUT MODULE
COMPACTLOGIX
DC DIGITAL
4.5-5.5VDC
TTL OUTPUT
16 POINT
16 CURRENT SINKING (LOW TRUE) POINT

SynchLink Block

1751SL4SP
SYNCHLINK
4 PORT SPLITTER BLOCK
CONVERTS ELECTRICAL
SIGNALS FROM SYNCHLINK BASE
BLOCK TO 4 FIBER
OPTIC
PORTS

ANALOG OUTPUT MODULE

1444AOFX0004RB
ANALOG OUTPUT MODULE
5 AMP MAX
18-32 VDC
20 MA OUTPUT
DISSIPATION: 3.6 W
OPERATING TEMPERATURE: -40 TO +105 DEGREES C

Flex I/O Relay Output Module

1794OW8XT
OUTPUT MODULE
FLEX I/O
DISCRETE
CONTACT
8 POINTS FORM A RELAY CONTACTS OUTPUT
EXTENDED TEMPERATURE -20 TO +70 DEG
OPEN STYLE
DINMOUNT
IP20

Expansion Relay Module

1444RELX0004RB
EXPANSION RELAY MODULE
4 SINGLE POLE DOUBLE THROW RELAYS
CONNECT UP TO THREE TO
ONE 1444-DYN04-01RA
DYNAMIC MEASUREMENTMODULE.
REQUIRES 1444-TB-B BASE
AND 1444-REL-RPC- CONNECTOR SET

Panelview Plus 1000 Operator Terminal

Display Size:10.4 in
Manufacturer:Rockwell Automation
Product Family:PanelView Plus Operator Terminals
Operator Input:Touch
Resolution:640 x 480
Toiuchscreen:1 million presses
Input Voltage range:18-32VDC
Communication:Ethernet and RS-232
Input Power:18 to 32 VDC
Memory:64 MB

Voted EODS Relay Module

1440REX0304RG
RELAY MODULE
OVER SPEED
XM 442
OPEN STYLE
MOUNTABLE

COMMUNICATIONS MODULE

Product Type:Gas & Liquid Flow Computer
Slot(s):1
Rack Type:Local or Remote
Data Transfer Type:Ladder Logic
RAM:128 MB min
Hard Drive Space:100 MB min
Pentium PC:100 mHz or faster
Backplane Current Load:800 mA @ 5V DC

Operator interface terminal

Product Line:Panelview Plus 700
Display Size:6.5 in.
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:18-32 VDC
Memory:128 MB
Backlight:2711P-RL7C2

PanelView Plus 700 Operator Terminal

Resolution:640 x 480
Input Voltage range:18-32VDC
Part Number/Catalog No.:2711P-T7C4D1
Product Line:Panelview Plus 700
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:18-32 VDC
Memory:64 MB
Operator Input:Touch

PanelView Plus Graphic Terminals

Part Number:2711P-RDB7C
Description:Display Module
Resolution:640 x 480
Display colors:18-bit color graphics
Luminance:300 cd/m2 (Nits)(3)
Input interface:Touch / Keypad
Anti-Glare overlay:not included
Touch Input:8-wire analog resistive

Operator interface

Product Line:Panelview 6 Plus
Display Size:6.5 inches
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:100 to 240 Volts AC
Memory:512 MB RAM
Backlight:2711P-RL7C2
Communication Cable:2711-NC13

Display module

Display Size:5.5 in.
Operator Input:Touch
Shipping Weight:8 pounds
Display Color:Color
Input Type:Touchscreen
Communication:Ethernet and RS-232
Input Power:100 to 240 Volts AC
Memory:512 MB RAM
Backlight:2711P-RL7C2
Product Line:Panelview 6 Plus

Display module

Resolution:640 x 480
Display colors:18-bit color graphics
Luminance:300 cd/m2 (Nits)(3)
Anti-Glare overlay:not included
Touch Input:8-wire analog resistive
Touch interface lifespan:1 Million actuations
Actuation force:10-110 g
Part Number/Catalog No.2711P-RDT7C
Series:PanelView Plus
Input:Touch
Display:7-inch Color

Display module

Resolution:800x600 pixels
Display Size:12.1 inches
Display colors:18-bit color graphics
Anti-Glare overlay:not included
Luminance:300 cd/m2 (Nits)(3)
Product Type:Display Module
Accessory for:1250 Terminal
Input Type:Keypad/Touch
Display:12 in. Color

PanelView Plus

Part Number:2711P-RDT12C
Description:Display Module
Display Size:12.1 inches
Display Area:246 x 184 mm (9.7 x 7.2 in.)
Resolution:800 x 600
Display colors:18-bit color graphics
Luminance:300 cd/m2 (Nits)(3)
Input interface:Touch
