CONTROL BOARD
Input Voltage:24V DC (±10%, isolated)
Internal Logic:3.3V/5V TTL
Protections:Short-circuit
PCB: 6-layer design
Thermal Rating: 0°C to +55°C
INVERTER MOTHERBOARD
INVERTER MOTHERBOARD
FOR ACS580
3AXD50000716975
Input Voltage Range:380–500V AC (3-phase)
DC Bus Link:Integrated protection
Control Voltage:24V DC
Logic Board Power:Switch-mode PSU
Communication Isolation:1500V AC reinforced
Operating Temp:-15°C to +45°C
Control Module
Analog: 2x 0–10V/4–20mA inputs
Digital: 8x programmable DI
Main circuit up to 690V AC
Functional isolation: ≥2.5kV
Thermal Resilience: ±55°C ambient
CONTROL BOARD
Input Voltage:380–690V AC
Output Power:up to 630 kW
Control Voltage:24V DC (±10%)
Ambient Operation:-15°C to +50°C
Humidity Protection:<95% non-condensing
CE Mark: Low Voltage Directive
Digital I/O: 6 programmable DI
Analog I/O: 2x 0–10V/4–20mA
CONTROL UNIT
Input Power (AC):400–690V (±10%) 3-phase
Motor Power Range:250kW–1.5MW
Control Voltage:Single-phase 26V DC to 30V DC (±15%)
Operating Temp:-15°C to +50°C
Harsh Environment:UL 1203
Busbar Terminals:values 8.9Nm ±0.5
AS-Interface Safety ATEX Gateway
CONTROL UNIT
Input Voltage:200–690V AC (-15%/+10%)
Power Range:15–400kW
Control Voltage:Single-phase 24V DC
Relay Outputs:4 × Form-A
AF-650PG: Profibus DP or CANopen
CURRENT MEAS.SCAL
Input Range:0–600A AC/DC
Output Range:±10V DC / 4–20mA
Isolation Voltage:2.5kV RMS
Accuracy:±0.25% FS (25°C)
Bandwidth:DC – 10kHz
Drift:<75ppm/°C
Response Time:<50µs
Hall Effect Sensor: 24V DC
Voltage Meas.Scaling Card
Rated Input Voltage:3300V AC/DC ±10%
Output Signal:±10V DC
Isolation Voltage:8kV RMS
Bandwidth:DC – 5kHz (-3dB)
Linearity Error:≤±0.15% FS
Drift:<50ppm/°C
Output Ripple:<5mV p-p at 50Hz
Response Time:<500µs for step inputs
Input Impedance: 1MΩ nominal
Starter kit
CPU:16-bit Renesas RX630 MCU
Memory:256KB RAM
Communication:2 × Ethernet (10/100BASE-T)
I/O Simulation:Virtual D/I and D/O
Power Supply:24V DC
6 × D/O (Transistor Sink: 0.5A @ 24V DC
Power cables :24V DC
POWER SUPPLY BOARD
AC Input Range: 200–500V AC
Frequency: 50/60Hz nominal
Input Surge Withstand: 4kV
+24VDC Logic Supply: 4A continuous
±15VDC Gate Driver Supply: 0.5A per rail (±2% regulation)
Standby 5VDC: 2A
Total Efficiency (85% load): ≥88%
Operating Temp: -25°C to +70°C
R9 Input Spare Kit
Low Voltage (LV): 380–480V AC
Optional High Voltage (HV):500–690V AC
Short-Circuit Current Rating (I_SC): ≤100 kA
Inrush Current Limit: ≤150% × rated input current
Isolation: ≥2.5 kV
Dynamic braking fuses:690V AC, 100–800A
Ambient Temp Range: -15°C to +45°C
Storage Humidity: ≤95% non-condensing
IGBT ASSEMBLY KIT
Category: Replacement IGBT Assembly Kit
Nominal Voltage (V_CE): 500V
Insulation Voltage: 2500V
Tjmax (ΔT over case): 70K
IGCT controller module
Reverse Voltage:4500V+
Forward Current:250–5000A
Switching Speed:<100 μC
Trigger Voltage/Current:+15/-15V pulses
Turn-On/Off Time:300–500 ns
THYRISTOR/DIODE MODULE
R8 SINGLE MODULE SP KIT
Forward Voltage: 1200–2500V range
Average On-State Current:500–2000A
Surge Current :10–50 kA
Isolation: ≥2000 V AC
Junction Temperature:>125°C
EXPANSION MODULE
EXPANSION MODULE
CONTROL BOARD MODULE
ZCU-14 PACKED CONTROL UNIT
REPLACES OBS MODEL 3AXD50000005164
SPAREPART KIT IGBT MODULE 900A
Voltage Class: 1200V
Continuous: 900A
Continuous: 900A
Switching Frequency: Optimized for ≤3–8 kHz
Conduction Losses: 1.8–2.5V
Isolation Voltage: ≥3000 V
Thermal Resistance:0.03–0.07 K/W
operating temperature: -40°C to +125°C
IGBT MODULE
Voltage Class:1200V
Continuous Current : 650A
Maximum Current: Up to 1300A
Collector-Emitter Saturation Voltage : 2.0–3.0V
Isolation: ≥2500 V DC
Thermal Resistance <0.1°C/W
Voltage: +15V/-8V gate control
Operating Temperature: -40°C to +125°C
IGBT MODULE
Voltage Class: 1200V, 1700V
Continuous Current: 1400A
Pulsed Current : 1400A
Saturation Voltage:1.5–3.0V
Isolation Voltage: ≥ 2.5 kV
Operating Voltage: 15–25V DC
Turn-on/off voltage: +/-15V gate control
Fieldbus Communication Interface
CI810B AF100 Fieldbus Communication Interface
2*AF100 Twisted Pair Modems.
Including:
1 pce Power Supply Connector 3BSC840098R1
1 pce TB807 Modulebus Terminator 3BSE008538R1
2 pcs Terminal Blocks 3BSC840098R1
The basic system software version 1.5 loaded.
AF100 Connector 3BSC840105R1
Processor module
AC500-eCo Processor module
Memory 4MB
12 DI 24 VDC. 6 DO-Relay
2 DC 24 VDC
Ethernet interface
3 option slots
LV AC industrial single drive module
ACS880-04 drives
3AXD10000497831
LV AC industrial single drive module
IEC: Pn 500 kW, 715 A, 500 V
UL: Pld 600 Hp, 705 A, 460 V
Number of Phases:3-phase
Enclosure Type NEMA:Open Type
Operating Humidity (RHamb):5 ... 95
Sound dB (A):72 dB(A
Frequency (f): 47.5 ... 63 Hz
Frame Size: R11
Input Voltage (Uin):380 ... 500 V
LV AC servo drive
MotiFlex e180
MFE180-04AN-05A0-4+L518+N8020
3P, 380 VAC
IN: 5 A, HALL incremental encode
A free Mint programming license
easy positioning tasks
drive supports various feedback types
Drive Module
DRIVE
INPUT: 179-19.8 AMP 3 PHASE 380-480 VAC 48-63 HZ
OUTPUT: 15.5-18 AMP 0-280-480 VAC 0-500 HZ
7.5 KW / 10 HP
IP20
(3AUA0000014470)
