Honewell FSC

Revision C IO Link Cable

Type: IO Link Cable
Part Number: 51202341-102 Revision C
Country of Origin: USA
Cable Length: 1 meter
Shielding: Shielded

HORIZONTAL BACK PLANE PWA

Operating Voltage: 24 V DC
Input Current: 1 A
Output Power: 20 W
Bus Interface: RS-485
Operating Temperature: -20°C to +70°C
Humidity Range: 5% to 95% non-condensing
Certifications: CE, UL, ISO 9001

Digital Input Module

PC BOARD
LOGIC CARD
NON-REDUNDANT
IOTA
9 INCH

DIGITAL INPUT MODULE

Approvals: CE, TUV, UL, CSA, FM
Number of input channels: 16
Input type: According to DIN (=NAMUR)
Switch level: 1.4-1.9 mA
Hysteresis: 0.2 mA ± 0.05 mA
Field wire resistance: Max. 50 Ω
output voltage 7.9-8.7 V
output current 170 mA (short-circuitproof)3
Maximum load capacitance: 100 nF
Test current: Typically 0.5 mA
Output voltage: Typically 0.5 V DC
Field fault voltage: Max. 250 V AC

Digital Output IOTA Redundant

Output Channels:32
Output Type SINK: (Open Drain)
Load Current :0.1 A per channel (Max)
On-State Voltage 0v VDC (load current @:0.1A max
Off-State Voltage:24 V (typ),
Off-State Leak Current:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

Digital Input IOTA Redundant

Power supply:24V DC
Rated Current:55mA at 24V
Power Consumption:1.32W at 20mA
Power/DCS to Field:1500 VAC
DCS side connections:
37 pin DSUB connector on CC-UGIA01
Voltage Input:24V DC
Interface to DCS:4 to 20mA with HART

Analog Output IOTA Redundant

Power supply 24V DC
Rated Current 55mA at 24V
Power Consumption 1.32W
Power/DCS to Field 1500 VAC
DCS side connections 37 pin
DSUB connector on CC-UGIA01
Voltage Input 24V DC
Current Input 4 to 20mA with HART,
CC-UGAI01 in sink mode.
Open wire current <150uA

Digital module

Channels: 16 digital channels
Input Type: 24 VDC
Isolation:500 VDC
Update Rate: ≤10 ms
Power Consumption: ≤5 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing.

SC S300 SAFETY CONTROLLER SIL3

Input Voltage: 24 VDC (±10%)
Output Voltage: 24 VDC
Current Capacity: Typically up to 5A
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing

SC S300 SAFETY CONTROLLER SIL3

Digital Inputs:24 VDC
Cycle Time: <10 ms
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Contact Rating: 5A @ 250VAC
Operating Force: 1.8N minimum
Release Force: 0.1N minimum
Pre-travel: 1.5mm maximum

Redundant Net Interface Module

REDUNDANT NET INTERFACE MODULE
CAGE CARD
24 VDC
(PN-14251 / 14251)

ANALOG OUTPUT MODULE

I/O LINK INTERFACE
FIBER OPTIC CONVERTER
9 PORTS
ANALOG OUTPUT MODULE

Enhanced Logic Manager Module

Input Voltage:Typically 24 VDC
Power Consumption:Around 25 W
Operating Temperature Range:Typically -20°C to 60°C
Storage Temperature Range:-40°C to 85°C.
Relative Humidity:5% to 95% non-condensing.

Power Supply

POWER SUPPLY
230 VAC

ACTUATOR

MODUTROL IV MOTOR
NON-SPRING RETURN
FOOT MOUNTED
4-20 MA MODULATING CONTROL SIGNAL
160 DEGREE STROKE
15-30 SECONDS TIMING
8.5 NM / 75 LB-IN TORQUE RATING
15 VA
120 VAC
50/60 HZ

Power Supply Module

Rated inputvoltage:220 VAC
Input voltagerange:176V~264VAC
Input frequency:50 / 60 Hz (47 ~ 63 Hz)
Max. input power:110 VA / 42 W
Inrush current:20A peak and lower (within8 ㎳ )
Efficiency:65% or higher
Output voltage:5VDC (±2%)
Output current:8.5A
Output power:46.75W @ 55℃
Rated switchingvoltage/current:24VDC, 0.5A

Analog Output module

Current Output: 4 channels
DC 4 ~ 20mA / 0 ~ 20mA

Analog Input module

Current Input: 8 channels
DC 4 ~ 20mA / 0 ~ 20mA

POWER SUPPLY MODULE

Rated inputvoltage:110 VAC
Input voltagerange:85V~132VAC
Input frequency:50 / 60 Hz (47 ~ 63 Hz)
Max. input power:110 VA / 42 W
Inrush current:20A peak and lower (within8 ㎳ )
Efficiency:65% or higher
Output voltage:5VDC (±2%)
Output current:5.5A
Output power:27.5W @ 55℃
Over currentprotection:6.0 A ~ 13.0 A

POWER SUPPLY MODULE

Rated inputvoltage:110 VAC
Input voltagerange:85V~132VAC
Input frequency:50 / 60 Hz (47 ~ 63 Hz)
Max. input power:110 VA / 42 W
Inrush current:20A peak and lower (within8 ㎳ )
Efficiency:65% or higher
Output voltage:5VDC (±2%)
Output current:5.5A
Output power:27.5W @ 55℃
Over currentprotection:6.0 A ~ 13.0 A

Fast Ethernet Module

Fast Ethernet
100/100Mbps
RJ-45 (Electric)
Protocol TCP-IP, UDP-IP
Network Control Protocol(Access Method) CSMA/CD
Transmission Speed: 100 Mbps
Max # of nodes 64

Power Supply Module

AmbientTemp. 0 ~ 55°C
StorageTemp. −25 ~ +70°C
Ambienthumidity 5 ~ 95%RH (Non-condensing)
Peak acceleration: 147m/s2
Duration: 11ms(15G)
Pulse wave type: Half-sine
Square waveimpulse noise ±1,500V
Electrostaticdischarge Voltage: 4kV

memory backup module

C300v5 controller
memory backup module
C300 Memory Backup Assembly
Power Requirements: 24 V DC
Current Draw: 150 mA
Operating Temperature Range: 0°C to 70°C

Open Plant Controller

ComfortPoint™ Open solution
fully programable
BACnet-Building Controller (B-BC)
for AHU, RTU and Central Plant applications
CPO-Studio compatible

CPO-Room Controller

ROOM CONTROLLER
CONTROLPOINT
BACNET
MS/TP
6 ANALOG OUTPUTS
4 RELAYS
4 TRIACS
230 VAC
