I/O module
Head module for CANopen slave stations
Up to 30 I/O modules per slave station
Optional integrated power supply
Transfer rate 10 Kbaud to 1 Mbaud
Bus length to 5000 m (signal repeater required)
Two internally connected CAN interfaces for loop-through of the cable
Galvanic isolation between CAN interfaces and control electronics
Node address can be set via rotary switch
Analog In/Output Module
8 analog inputs
8 analog outputs
Connection possibility single-ended or differential
Power supply for up to 4 potentiometers
Temperature inputs for up to 4 Pt100/Pt1000 sensors
2-wire or 4-wire inputs for Pt100/Pt1000 sensors
Wire break detection for the inputs (for voltage and temperature)
Short circuit proof outputs
Digital I/O module
compact CAN slave module
16/32 channels can be freely configured as input or output
Digital outputs each with 1 A continuous current
Two internally connected CAN interfaces for loop-through of the cable
Galvanic isolation between CAN interfaces and control electronics
Baud rate and node ID can be set via rotary switch
Supply voltage 18 to 34 VDC
Operating range 0 to +60°C without additional cooling
Full wiring without additional backplanes
pulse width modulation module
2 pulse-width modulated output channels
2 shielded DSub connectors
for output channels
LED (green) per output
Choice of high-power or TTL output level
Monitoring of the load current
Monitoring of the external supply voltage
Monitoring of the internal temperature
Analog In/Output Module
2 input channels
for incremental and SSI encoders
Full 32 bit counter
2 analog outputs (14 bit)
4 fast digital input channels for initiator and trigger
Position measurement / position storage can be initiated via triggers
Virtual for use in applications:
zero pulse, speed, etc.
Synchronization via SYNC/PreSYNC
Operator Panel
Industrial Processor at up to 433 MHz
Priority scheduled Multitasking
256 MB RAM
512 kB remanent memory (Retain)
64 MB internal memory device 1)
CompactFlash card slot for removable media
Front side PC-Card slot
2x Ethernet 10/100 Mbit/s
FASTBUS-Modules
FASTBUS master modules with 1 or 2 FO interfaces
FASTBUS slave modules with 1 or 2 FO interfaces
FASTBUS slave modules with integrated power supply
Up to 15 distributed substations
Distances to between 2 stations:
40 m for POF cables
150 m for HCS cables
180 m for special HCS cables
Status display (RUN/ERR) and display for fiber type
Minimal signal delay
Serial Interface Module
4 interfaces on one module
Any number of interfaces possible per controller
RS232 / RS422 / RS485 can be combined
High speed interfaces with up to 1.5 Mbaud
Auto-flow control for automatic handshake
Integrated terminating resistors (connect/disconnect)
Interfaces galvanically isolated
Galvanic isolation from system and between interfaces 500 V
OPERATOR INTERFACE
WT205LX800DD512CF512VX
DISCONTINUED BY MANUFACTURER
OPERATOR INTERFACE
TEXT PANEL
