Fanuc CNC

INPUT MODULE

IC600BF832
DISCONTINUED BY MANUFACTURER
INPUT MODULE
SERIES SIX
115 VAC
32 POINT

Discrete output module

Series:Series 90-30
Manufacturer:GE Fanuc; Emerson Automation (Current)
Part Number:IC693MDL741
Product type:Digital I/O
Compatibility:GE Fanuc 90-30 PLCs
Product Description:Discrete output module
Output points:16
No of Channels:Sixteen (16)
Peak module current draw:110 milliamps
No. of output groups:Two (2)
Module voltage input:5 Volts DC
Channels per group:Eight (8)
Rated voltage:12/ 24 Volts DC
Peak output voltage drop:0.5 Volts
Nominal output voltage:12 / 24 VDC
On response time, maximum:2 ms
Off response time, maximum:2 ms
Output Voltage Drop:0.5 volts, maximum
Off-state Leakage:1 mA maximum

Single Board Computer

Network: Dual Gigabit Ethernet ports.
USB: USB 2.0/3.0 ports for peripheral connectivity.
Serial: RS-232/422/485 interfaces.
Graphics: VGA, DVI, or DisplayPort for display output
Operating Temperature: -40°C to +85°C (ruggedized variants).
Certifications: MIL-STD-810 (shock/vibration), CE, RoHS.
Power Input: 5V or 12V DC

Bus Interface Unit

Reflective Memory interface Module

Memory Size:8 MB, 16 MB, or 32 MB
Data Transfer Rate:Up to 43 MB/s
Node Support:Supports up to 256 nodes
Connectors:
ST-style fiber-optic connectors
Power Requirements:+5 VDC
Storage Temperature:-40°C to +85°C
Operating Temperature:0°C to +60°C

Expansion Unit

EXPANSION MODULE
PLC 90-10A
ADDITIONAL UNIT 1/056

Relay Output module

Series:Series 90-30
Manufacturer:GE Fanuc
Part Number:IC693MDL930
Product Description:Discrete output module
Product type:Digital I/O
Relay outputs:8
1500 volts between field side and logic side; 500 volts between groups:Output voltage range
Product Description:Relay Output module
Output switching capacity:4 Amps
5 to 30 volts DC 5 to 250 volts AC, 50/60 Hz
No of Channels:Eight (8)
Minimum load:10 mA
Maximum inrush current:5 Amperes
Response time:15 ms
Operating voltages:5-30 / 5-250 VAC
On response time, maximum:15 ms
Switching Frequency:20 Cycles per minute
Off response time, maximum:15 ms
Module width:Single slot
Product Lifecycle Status:Discontinued/Obsolete
Product lifecycle:Obsolete

12/24 VDC 32-Circuit Source I/O Block

Rated Voltage:12/24 VDC
# of Points:32
Input Range:18-30 VDC
Load Current:0.5
Operating Voltage:10-30 VDC
Points per Common:One group of 32

FIP Bus Controller Module

Brand:GE Fanuc
Series:Series 90-30
Part Number:IC693BEM340
Module type:Series 90-30 PLC communication module
Typical current consumption:800mA

17-Slot Rear Mount Rack

Brand:GE Fanuc
Series:Rx7i PACsystem
Part Number:IC698CHS117
Description:PACSystems RX7i I/O Rack
Application:Rx7i System
Operating Voltage:5 to 12 Volts DC
Power Supply:350 Watts
I/O Capacity:18 I/O Slots
Fan Assembly:Optional

Rack Fan Assembly

Brand:GE Fanuc
Series:Series 90-70
Part Number:IC697ACC724
Product Description:Rack Fan Assembly
Operating Voltage:240 Volts AC
Input Power:16 to 17 Watts
Line Amps:0.09 to 0.10 Amps
Nominal Air Flow:71 CFM
Weight:5.94 Pounds

9 slot plus power supply

Series:Series 90-70
Manufacturer:GE Fanuc (Former); Emerson Automation (Current)
Product Description:9-slot , rear mount, rack
Part Number:IC697CHS790
No. of I/O slots:9 slot plus power supply
Voltage:5 Volts DC
Product Description:Standard PLC Rack
Mounting:Panel mounting
Current:20 Amperes
VME System:VME standard C.1
Compatible modules:All IC697 modules
Product lifecycle:Discontinued
Dimension:7.5 x 19 x 11.5 inches
Rear mounting:10" (255 mm) enclosure
Rack extension:Supported
Standard:VME
Front Mounting:19" Standard rack
Supported:Two (2)
Number of Slots:9
Current Required from I/O Bus:0.5 amps
Enclosure Depth:10 inches

Discrete output module

Series:Series 90-70
Manufacturer:GE Fanuc; Emerson Automation (Current)
Part Number:IC697MDL750
Rated voltage:24 to 48 Volts DC
No of Channels:Thirty-Two (32)
No. of output groups:Four (4)
Channels per group:Eight (8)
Current draw:0.25 A
Required current:0.25 Amps
Wiring configuration:Positive Logic
Output voltage range:20-60 VDC
Number of outputs:32
On response time, maximum:1 ms
Off response time, maximum:1 ms
Output signal range:20 - 60 VDC
Isolation voltage:1500 Volts

Discrete input module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL240
Description:Input module
No of Channels:Sixteen (16)
Points:16
Input signal range:0-132 VAC
Voltage:120 Volts AC
Nominal Input voltage:0-120 VAC
Current:7 milliamps
Input Frequency:47-63 Hz
Power consumption:90 milliamps
Input current:12mA per channel
Input current:12 mA
Bus voltage:5 Volts
Current draw:90 mA (all inputs active)
Off response time, maximum:45 ms
On state current:6 mA
On response time, maximum:30 ms
Product Lifecycle Status:Active
Off state current:2.2 mA
On–state Current:6mA minimum
On response time, typical:30 ms

Power Transducer Module

Series:Series 90-30
Manufacturer:GE Fanuc (Former); Emerson Automation (Current)
Part Number:IC663PTM101
Description:Power Transducer module
Voltage:10-120 Volts AC
Mounting:Any Series 90-30 Baseplate
Current:0-7.5 Amperes
Compatible Series 90-30 CPU:Any CPU module
Dissipation:4 Watts
Frequency:35-70 Hertz
Resolution:14-bit
Total Power Dissipation:4W max
Backplane isolation Voltage:1500 Volts
Product Lifecycle Status:Discontinued/Obsolete

Discrete output module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL940
Product Description:Relay output module
Description:Relay Output Module
Response time:15 ms
Product Lifecycle Status:Active
No. of channels:Eight (8)
No. of groups:Four (4)
Switching current:2.0 Amps
No. of channels per group:Four (4)
Output voltage, range:5 - 30 VDC; 5 - 250VAC (50/60 Hz);
Max. Backplane Draw:135 Milliamps
Rated voltage:24 VDC; 120/240 VAC
Inrush Rating:5.0 Amps
Max. Response Time:15 Milliseconds
Minimum load:10 mA
Location:PacSystems PLC I/O Slots
Maximum inrush:5:00 AM

Relay Output module

Series:Series 90-70
Manufacturer:GE Fanuc
Part number:IC697MDL940
Current draw:750 mA
Switching frequency:20 Cycles per minute
Response time:10 ms
Number of outputs:16
No. of groups:Two (2) Groups of Form A
No of Channels:Sixteen (16) Relay outputs
Required current:750 milliAmps
Minimum load:10 mA
Isolation voltage:1500 Volts

Profinet network interface unit

Series:Versamax
Manufacturer:Emerson Automation / GE Fanuc (former)
Part Number:IC200PNS001
Series:VersaMax
Part Number:IC200PNS001
Power Consumption:0.60 Amperes at 5 Volts DC
Product type:Remote I/O Profinet Network Interface Unit
Supported protocol:PROFINET version Version 2.2 Class A IO-Device
Proficy Machine Edition Version Required:Version 7.0 or later
Supported topologies:Linear, Star, Ring (redundant)
No. of Ports:Two (2) RJ45ports
Mounting:DIN Rail

Output Module

Brand:GE Intelligent Platforms/GE Fanuc
Series:Series 90-70
Part Number:IC697MDL340
Product Type:Output Module
Rated Voltage:120 V AC
Outputs:16
DC Power:No
AC Power:Yes
LED Indicators:Yes

INPUT MODULE

IC600BF841
DISCONTINUED BY MANUFACTURER
INPUT MODULE
SERIES SIX
4POINT
ANALOG
0-10VDC

Output module

Brand:GE Fanuc
Series:RX3i PacSystem
Part Number:IC694MDL742
Type:Output module
Rated Voltage:12/24V DC
Isolation:250V AC continuous;
Electronic Short-Circuit Protection (ESCP):Yes
LEDs:Yes
Hot Insertion and Removal:Yes

INTERFACE MODULE

Brand:GE Fanuc
Series:Versamax
Part Number:IC200PBI001
I/O Modules:64
Network Address:1-125
User Diagnostics Data:5 bytes
Connector:9 Pin D-sub

CPU MODULE

Manufacturer:GE Fanuc
Series:RX3i PACSystem
Part Number:IC698CRE030
Product Type:CPU
User Memory:64 MB
CPU:Redundancy CPU

Programmable Coprocessor Module

Programmable Coprocessor Module
