Triconex

Pulse Input Module

8 pulse input channels
Voltage Range: 5–30 V DC
Standard: 0–10 kHz
Frequency Measurement: ±0.01% of reading
Channel-to-Channel Isolation: ≥ 1500 V AC/DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)
Humidity:
0–95% non-condensing

Pulse Input Baseplate

Frequency/Rate: Up to 10 kHz
Voltage Range: 5–30 V DC
Counting Resolution: 24-bit
Frequency Accuracy: ±0.01%
Channel-to-channel isolation: ≥ 1500 V AC/DC
Field-side Power: 24 V DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)

Communication module

Serial ports : 4
Network ports : 2
Port isolation : 500 VDC
Copper Ethernet ports : 10/100 Mbps
(Model 4353 supports only 100 Mbps)
Fiber Ethernet ports : 100 Mbps
Serial ports : up to 115.2 Kbps per port

I/O Bus Cable

4000056002
I/O Bus Cable
Operating Temperature Range:  -40°C to +70°C
Insulation Material: PVC
CABLE ASSEMBLY 6FEET

I/O ALARM MODULE

I/O ALARM MODULE
TRISEN TURBOSENTRY
16 DIGITAL OUTPUTS
OPERATING VOLTAGE: 24V DC
OPERATING TEMPERATURE RANGE: -40C TO 70C
DIMENSIONS: 12.5 X 4.5 X 5.5 INCHES

Remote Expansion Chassis

Power Supply:18 to 32 VDC
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Humidity: 5% to 95%, non-condensing
Output Channels: 16 or 32
Output Voltage: 32 VDC
Certifications: IEC 61508 SIL3

Communication Module

Input Voltage: Usually 24 VDC.
Operating Temperature: -20°C to 60°C.
Storage Temperature: -40°C to 85°C.
Humidity: 10% to 95% RH, non-condensing.
Ingress Protection (IP): Typically IP20

Communication Module

Tricon
TCM SERIES
2 X NET LINK PORTS
4 X 9 PIN SERIAL PORTS
1 X 9 PIN DEBUG PORT

Control Module

Nominal Voltage 24 VDC
Type Control Module
Output Signals  32, commoned
Voltage Range 16-32 VDC
Maximum Voltage 36 VDC
Voltage Drop < 2.8 VDC @ 1.7A, typical
Power Module Load < 13 watts

MAIN PROCESSOR MODULE

MAIN PROCESSOR MODULE
ENHANCED EMP II
24 VDC
LED INDICATORS

TRICON MAIN CHASSIS

81008
TRICON MAIN CHASSIS VERSION-8

CABLE ASSEMBLY 10FEET

4000098516
CABLE ASSEMBLY 10FEET

I/O cable

Part Number: 4000094-316
Type: I/O Cable
Compatibility: Compatible with TRICONEX safety systems, typically used with I/O modules and other system components for data transmission.
High-quality insulation for protection against environmental factors.
Designed to withstand high temperatures, vibration, and harsh industrial environments.
Reliable performance for continuous monitoring and control in critical processes.

Digital Output Module

Operating Voltage:380V AC
Input Frequency:50/60Hz
Processing Speed:120 MIPS
Memory Capacity:1MB RAM, 16MB Flash
Communication Interfaces:Ethernet, DeviceNet, FF

Communication module

Manufacturer: Triconex
Model: 7400195-210
Type: Communication Module
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +85°C (-40°F to 185°F)
Humidity Range: 5% to 95% RH

Dido Panel Module

Dido Panel
7400143-530
Rev A/ A1
Model: 9853-6xx
Volt: 4-20 Ma
8-320 Ma
3000400-530
Rev A
Typ/type: Umk-se 11,25-1
Weight : 150 Gm

Analog Output Module

Points:4, commoned-return, DC-coupled
Output current range:
4–20 mA output, controlled
0–22 mA over-range
0 mA output capability (step function <2 mA)
Type:TMR
Resolution:12 bits
Diagnostic:Forced-switch diagnostic (FSD)
Over-range protection:36 V DC, continuous

Main Processor (UMP) Module

Power consumption: Typically 15-30W
Operates on 24V DC
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% non-condensing
