Schneider Electric

Variable speed drive

Range of product:Easy Altivar 610
Product or component type:Variable speed drive
Device short name:ATV610
Variant:Standard version
type of cooling:Forced convection
Supply frequency:50...60 Hz +/-5 %
Network number of phases:3 phases
rated supply voltage:380...460 V - 15...10 %

Variable speed drive

Easy Altivar 610
Variable speed drive
Fan, pump, compressor, conveyor
ATV610
Standard version
Cabinet mount

Modbus Plus option adaptor

Communication port protocol:Modbus Plus
Communication port type:Single
rated supply voltage:5 V DC
Input voltage tolerance:+/- 5 %
Supply:Via I/O base
Clock drift+/- 13 s/day accuracy
Battery size2/3 AA

Backplane extension cable

Accessory:Connection accessories
Product compatibility
BMXXBE1000
To chain rack and transport local bus signal
2 male connectors SUB-D 9
0.8 m

USB Data Transfer Cable

Rated Voltage:5V DC
PowerConsumption:0.7W (Max)
AmbientTemperature:0oC to 50oC
StorageTemperature:-10oC to +60oC
TRANSFER/PROGRAMMING CABLE
USB: HMI USB
TYPE A
PORT TO PC USB TYPE A PORT

VDC Logic I/O Module

I/O Type: 32-channel
Nominal: 24 VDC
Operating Range: 19.2–30 VDC
Field-to-Logic Isolation: 1500 VAC
Backplane Power: 120 mA @ 5 VDC (typical).
Field Power: 32 x 7 mA = ~224 mA @ 24 VDC (max).

Counter module

Counter modules
Modicon Premium
2 channels modularity
thermal tripping protection
4.5 to 6W, 40kHz

PROCESSOR MODULE

Double format PL7 processor,
Modicon Premium,
Internal RAM
48Kwords program & data
PL7 Junior/Pro

Counter module

Counter modules
Modicon Premium
4 channels modularity
current limiter protection
8 to 11.5W
40kHz

Analog output module

Analog input module
Modicon Premium
4 high level fast inputs
16 bits conversion
500mA at 5VDC

Analog output module

Analog output module
Modicon Premium
4 outputs
12 bits coversion
900mA at 5VDC
Maximum load inductance:300 µH
Maximum load capacitance:0.1 µF

Communication module

Range of product:Altivar
Product or component type:Communication module
Communication port protocol:Profibus DP V1
Electrical connection:1 female connector SUB-D 9
Transmission rate:9.6 kbps...12 Mbps

PROCESSOR MODULE

Range of Product:Modicon Premium Automation platform
Product or Component Type:Double-format PL7 processor
Software Designation:PL7 Junior/Pro
Number of racks:16 4/6/8 slots/8 12 slots
Discrete I/O processor capacity:1024 I/O
Analogue I/O processor capacity:128 I/O
Number of application specific channel:32

Measurement and counter module

Measurement and counter module
Modicon Premum
2 channels modularity
thermal tripping protection
7 to 10W
10kHz

Power supply module

Power supply module
Modicon Premium
input current of 300mA
secondary power of 26W
85 to 264VAC

TSXDEY16A5

Modicon Premium
16 inputs
compatible with
2/3 wires proximity sensors
0.83W, 15mA

MBUS+ PROG BRIDGE

Communication port protocol:Modbus Plus
Communication port support:RS232
Modbus Plus bridges and repeaters
characteristics:Programmable
Bridge
Mounting support:Panel Enclosure
Number of port:4
Rated supply voltage:115...220 V AC 24 V DC

Contactor

Contactor
TeSys Deca
3P(3NO), AC-3/AC-3e
440V, 95A
110V AC 50/60Hz coil
screw clamp terminals

TeSys Deca contactor

LC1D11500F7C
Telemecanique,
Schneider Electric
TeSys D  Series
non-reversing contactor
type LC1D, 3P, 3PH, 250A
600V, 30kW @ 220V, 55kW @ 380V
60kW @ 600V,complete with 110V AC coil
AC magnetic contactor
suitable for use with
LC1-D series motor control systems

Network switch

Concept:Transparent Ready
Port Ethernet:10/100BASE-TX - 8 port(s) copper cable
Supply voltage limits:9.6…32 V DC SELV
Power consumption in W:6 W
Alarm output:1 voltfree contact 1 A
Ambient air temperature for operation:0…60 °C
rated supply voltage:12...24 V

Chipset type:Intel 945GME at 533 MHz
Display size:15 inch
Display colour:16 million colours
Luminance:350 cd/m²
Supply voltage limits:85…265 V
Inrush current:40 A
Power consumption in W:130 W
Material:Treated steel

Vigilohm Digital Insulation Monitoring

Voltage:Standard 500 V DC
Accuracy: ±5% of reading
Operating Temperature:Typically -10°C to +55°C
Storage Temperature:-20°C to +70°C
Relative Humidity:10% to 95%, non-condensing
Input Voltage:24 V DC or 230 V AC

Variable Speed Drive

Product specific application:Complex machines
Format of the drive:Compact
Mounting mode:Wall mount
rated supply voltage:380...500 V - 15...10 %
Nominal output current:5.5 A
Motor power kW:2.2 kW for heavy duty
Discrete input number:7
Transient overtorque:170…200 % of nominal motor torque

Variable speed drive

Range of Product:Altivar 312
Motor power kW:0.37 kW
Maximum Horse Power Rating:0.5 hp
Supply frequency:50...60 Hz - 5...5 %
EMC filter:Integrated
Apparent power:1 kVA
Maximum transient current:5 A 60 s
Power dissipation in W:41 W at nominal load
Speed range:1…50

PROFINET fieldbus module

Product or component type:Communication module
Product compatibility:Lexium 32M
Accessory / separate part destination:Servo drive
Number of addresses:256
Electrical connection:2 connectors RJ45
4 LEDs (green/red) for communication status
