GE Mark VIe

Terminal board

Series: GE Mark VIe Series
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤8 W
Voltage Range:0–30 V DC or 0–120 V AC
Range: 0–10 V DC, 4–20 mA
Resolution: 16-bit ADC
Type: Form-C contact relays (1 A at 30 V DC)
Operating Temperature: -40°C to +70°C
Relative Humidity: 5–95% (non-condensing)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Input: 24 V DC (±10%)
Isolation: ≥1.5 kV
Digital Inputs:0–30 V DC
Analog Resolution:16-bit ADC
Operating Temperature: -40°C to +70°C
Shock/Vibration: to 5 G (5–500 Hz)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Terminal Capacity: ≤32 AWG
Input Voltage: 24 V DC (±10%)
Power Consumption: <5 W
Galvanic Isolation: Up to 1.5 kV AC/DC
Voltage Range for Inputs: 0–120 V AC/DC
Digital Inputs (DI):30 V DC/120 V AC
Operating: -40°C to +70°C
Storage: -40°C to +85°C
Humidity Tolerance: 5–95% non-condensing

Turbine Emergency Trip Board

Series: GE Mark VIe
Dual Power Inputs: Isolated 24 V DC
Fail-safe relay contact rating: 2 A at 24 V DC
Input Voltage: 24 V DC (±10%)
Temperature Range: -40°C to +70°C (continuous operation)
Surge Protection: TVS diodes/SRC filters on I/O channels
Relative Humidity: 5–95% (non-condensing)

RTD Input terminal board

Operating Voltage:24 V DC ±10%
Power Consumption: <10 W
Types: 2-wire, 3-wire
Number of Inputs: 8 channels
Excitation Current:1 mA
Measurement Resolution: ≤0.1°C

Relay Output Terminal Board

Series: Mark VIe
Product Type: Relay Output Terminal Board
Number of channels: 16
Relay Type: SPDT
Relay Contact Rating: 10A
Input Voltage Range: 12V, 24V
Number of Relay Channels: 4, 8
Relay Switching Current: Max 10A
Mounting Type: DIN rail
Output Resolution: 12-bit
Output Impedance: 10 Ohm
Analog outputs: 0-20 mA

Vibration terminal board

Series: GE Mark VIe
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
Proximity Probes: 0–10 kHz
Accelerometers: Up to 20 kHz
IEPE sensor excitation:typically 18–24 V DC
Analog input: ±10 V peak
Operating Temperature: -40°C to +70°C.
Humidity Tolerance: 5–95% (non-condensing)

Transient Data Interface Module

Input Voltage: 24 V DC (±10%)
Power Consumption: Typically <20 W
Sampling Rate:Up to 25.6 kS/s
Voltage ranges (analog): Typically ±10 V DC
Analog Input: 16-bit
Operating Temperature: -40°C to +70°C
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5%–95% (non-condensing)

I/O Pack processor board

Processor Type:Mark VI
Backplane Power: +5 VDC
Analog: ±10 V, 4–20 mA
Digital: 24 V DC
Processing Speed: 100–200 MHz
Non-Volatile Memory (Flash):16–64 MB

Emergency Turbine Protection Module

Frame Rate Up to 100 Hz
MPU Pulse Rate Range 2 Hz to 20 kHz
Input supply: 125 V dc (70-145 V dc)
Output: 5 V dc and 28 V dc
Input Channels:4–20 mA

Industrial Circuit Board

Analog Inputs: 4–8 channels
Analog Outputs: 4–20 mA or ±10 V DC
Digital I/O: 24 V DC
Form Factor: 6U VME module
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Humidity: 5–95% RH (non-condensing).

VME Controller Board

System: Mark VI Turbine Control System
Clock Speed: ≥1 GHz
RAM: 1–2 GB DDR3
Flash Storage: 4–8 GB
Form Factor: 6U VME module
Voltage: 24 V DC (±10%)
Power Consumption: ≤25 W

VME Monitor Board

Analog: 4–20 mA, ±10 V DC
Digital: 24 V DC dry/wet contacts
Frequency: Vibration signals
Form Factor: 6U VME module
Data Acquisition:16-bit ADC resolution
Sampling rates up to 50 kS/s
Backplane: VME P1/J1 connectors for bus communication

Exciter DC Feedback Board

Voltage Feedback: 0–500 V DC
Current Feedback: 0–10 A DC
Accuracy: ±0.25% of full scale
Frequency Response: Up to 100 Hz
Signal-to-System Isolation: 1500 V AC
Common-Mode Rejection: >60 dB at 50/60 Hz
Analog Output: 4–20 mA or 0–10 V DC

Control Module

Supply Voltage: 24 VDC
Isolation: 1500 VAC
Operating Temperature: -40°C to +70°C
Enclosure Rating: IP20
Backplane Compatibility: PACSystems RX3i racks

Digital input module

Sinking or Sourcing: 24 VDC
Isolation:1500 VAC
Input Current: 24 VDC
Operating Temperature: -40°C to +70°C
VersaMax I/O: Installed in IC200 or IC600 racks

Control Circuit Board

30 NM Power Converter ACB AAA
Power Converter (30 NM ACB AAA
Input Voltage: Likely 480 VAC
Output Power: Estimated 30 kW
Efficiency: ≥95%
Voltage Levels: 5 VDC, 24 VDC
Operating Temperature:-20°C to +60°C
Humidity:5–95% RH (non-condensing)

Printed circuit board

Series: Mark VIe
Product type: Printed Circuit Board
COM Ports: 3; COM1, COM2, and micro-miniature 9-pin socket D connector
Ethernet Interfaces: 10BaseT/AUI connector
Manual: GEP-9145
Relative Humidity: 10-95%, non-condensing
Shock: maximum 10G, non-operating
Female Plug Connectors: 2
No.of Metal Oxide Varistors: 4
Power Supply Rating: 125 VDC

Printed circuit board

Power Supply:24 VDC
Signal Handling:4–20 mA, 0–10 VDC
digital signals:24 VDC logic
Resolution:16-bit ADC/DAC resolution
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Wind Turbine Board

Manufacturer:GE Energy
Series:Mark VIe Speedtronic
Part Number:IS200WEORG1A
Functional Acronym:WEOR
Functional Description:GE Printed Circuit Board
PCB Coating:Normal Coating

Printed circuit board

Power Supply: 24 VDC
analog inputs/outputs:4–20 mA, 0–10 VDC
Resolution:16-bit ADC/DAC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Printed circuit board

Manufacturer:GE Energy
Series:Mark VIe Wind
Part Number:IS210AEBIH3B
Functional Acronym:AEBI
Functional Description:Alternative Energy Bridge Interface
PCB Coating:Conformal Coating
AEBI:CARD GE WIND TURBINE
Input Voltage: 24V DC
Operating Temperature: Typically between -30°C to +65°C
Humidity: Typically 0-95% (non-condensing)

I/O EXPANSION BOARD

Power Supply:24 VDC
I/O Channels: 4–20 mA, ±10 VDC
Typical expansion capacity: 16–32 channels
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Input terminal board

Series: EX2100
Product Type: Alternative Energy Application D
Number of channels: 6
Input Span: 1-5 V dc
Outputs: 24 V outputs
Technology: Surface Mount
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C

Multiple Application Converter Control Board

Input Voltage:Typically 24 VDC
Signal Compatibility:
Analog: 4–20 mA, 0–10 VDC
Digital: 24 VDC logic
Analog resolution: 12-bit to 16-bit
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity
