Softstarter
Product No. : PSTX300-600-70
Product Type : Softstarter
Current Rating : 300 - 300A
Main Voltage : 600 - 208 - 600V 50/60 Hz
Supply Voltage : 70 - 100 - 250V 50/60 Hz
SwitchLine
220 V AC OETL
ZT 80 A220AC
1SCA022079R9050
OETLZT 80_/_ Un /R
110VAC/1000Ω, 230VAC/3900Ω
24VDC/48Ω, 48VDC/190Ω
60VDC/300Ω,110VDC/1000Ω
220VDC/3900Ω, U=0.7...1.1*Un
PDC=15 W, PAC = 30VA
Power supply
Series: CP-C
Model: 24/20.0
Type: Industrial switching power supply
Power Rating: 480W
Output Voltage: 24V DC ±1%
Input Voltage Range:100-240V AC (47-63Hz)
Inrush Current: <20A
Power Factor: >0.95 at full load
Efficiency: Up to 93%
Transformer Protection
Supply Voltage:24V DC (±10%)
Power Consumption:3W (typical)
Isolation :1500V AC
Protocol:PROFIBUS DP-V1
Data Rate:9.6kbps
Max Nodes:32 per segment
Transformer Protection
Rated Current:1A or 5A
Voltage Inputs:100-240V AC
Burden:<0.2VA (current)
Current (0.1-40In):±0.5%
Voltage:±0.2%
Frequency:±0.01Hz
Operating range: 1.05-1.4 pu V/Hz
