Honeywell DCS

Hpm I/o Link Pc Board

I/O Type:Digital or analog I/O
Voltage Range:24 VDC (±10%)
Isolation:1500 VAC typical
Environmental Rating:Operates in -40°C to +70°C

Analog Input Module

Input Type Current (2-wire or self-powered transmitters)
Input Channels 16 Channels (16 Single Ended)
Common Mode Rejection Ratio, dc to 60 Hz 70 dB
A/D Converter Resolution 16 bits
Input Range 4-20 mA (through 200 Ω)
Normal Mode Rejection Ratio, at 60 Hz 20 dB
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.0 Hz
Maximum Normal Mode Input ± 30 Volts

Hlai/sti galvanic isolator module

Description : HLAI/STI FTA, GI/IS MC-GAIH13
CE compliant, conformally coated
Redundancy
Channels : 16
Galvanically Isolated
Terminals : Compression
Size B : 12 inches (307 mm)

PROBE LOW TEMP 20FT PH

Measuring Range: 0–14 pH.
Process Fluid: 0°C to 50°C (32°F to 122°F)
Response Time: ≤30 seconds
Cable: 20 feet shielded, UV-resistant
Pressure Rating: ≤5 bar (72.5 psi)
Calibration: 2–3 point calibration

Universal Input Output IOTA

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Universal Input Output IOTA Red

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Digital Output Module

Output Channels:32
Output Type:SINK (Open Drain)
Load Voltage:15 30 VDC Maximum
Load Current:0.1 A per channel (Max)
On-State Voltage:0v VDC
Off-State Voltage:24 V (typ)
Off-State Leak Curren:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

IOL FOE PM VIOLET - 0.5M

Cable Type: Fiber Optic Ethernet.
Connector Type: IOL (Input/Output Link) connectors.
Length: 0.5 meters
Operating Voltage: 24 VDC.
Operating Current: 0.5 A.
Maximum Power Consumption: 12 W

ACCELEROMETER

Acceleration Range: ±2g, ±5g, ±10g, or ±50g
Voltage output, typically 0-5V or 0-10V
Supply Voltage:  5V DC or 12V DC
Operating Temperature: -40°C to +85°C

Safety Manager SC Hardware

Input Channels 16 or more digital inputs,
Output Channels 16 or more digital outputs
Operating Voltage 24 VDC (nominal)
Power Consumption Typically <20 W
Operating Temperature -10°C to +60°C
Storage Temperature -40°C to +85°C
Mounting Type DIN rail or panel mount
Communication Protocols Modbus TCP, Profibus,
EtherCAT, CANopen, and other industrial protocols

SC IOTA PDIO Redundant Module

Operating Voltage 24 VDC
Power Consumption Typically <20 W
Communication Protocols Modbus TCP,
Profibus, EtherCAT, CANopen,
and other standard industrial protocols
Operating Temperature -10°C to +60°C
Storage Temperature -40°C to +85°C

SC S300 IOTA CONTROLLER REDUNDANT

Safety Standard Compliance
IEC 61508 SIL3, ISO 13849-1
and other relevant safety standards
Input Channels Configurable digital and analog inputs
Output Channels Digital and relay outputs
tailored for controlling safety-critical systems
Communication Protocols
Modbus TCP, Profibus,
EtherCAT, CANopen, and
other standard industrial protocols

Earth Fault Monitor

Temperature -40°C to +75°C
(-40°F to +167°F )
Approvals CE, TUV
DIN EN rails: TS32 / TS35 x 7.5
Input voltage:24 VDC +30/-15%
Input current:10 mA maximum 25 mA
Voltage typically +4.1 VDC
Resistor (R)approximately 2.8 kOhm

PWA / I/O LINK MODULE

Module Type I/O Link Module
Power Supply 24 VDC
Operating Temperature -20°C to +60°C
Storage Temperature -40°C to +85°C
Humidity 5% to 95% non-condensing

Interface Board

TDC3000
TDC3000 framework
5 VDC
Approx. 1.5 W
300 mA (nominal)
TDC-specific protocols for
data transfer and communication

WSI2 Unix coprocessor card

100 MHz
without graphics
used in the UxS and AxM.
with 32, 64, or 128 MB of RAM memory

Interface Converter Board

24V DC internal power supply
within the system
-20 ° C to 70 ° C
5% to 95%, no condensation
Multiple digital/analog input/output interfaces
DIN rail installation or rack mounted installation

Power Supply

51198947100
DISCONTINUED BY MANUFACTURER
POWER SUPPLY
115/240 VAC INPUT
50/60 HZ
25 VDC OUTPUT
10 AMP LOAD
550 WATT POWER

PROCESSOR BOARD

51401551300
PROCESSOR BOARD
HIGH PERFORMANCE/DENSITY
(K2LCN-3)

CONTROL BOARD

51401551301
CONTROL BOARD
K2LCN-3
MULTI INPUT/OUTPUT
PANEL MOUNT
SINGLE SLOT

Safe digital input module (48 Vdc, 16 channels) (conformal coated)

Mounting Carrier

A metal profile
A plastic cover plate
A ground rail with 16 ground connection screws
Two power rails with M5 holes (+24V and 0V)
Four mounting holes (6.35 mm diameter)
Operating temperature: -40 .. +70°C (-40 .. +158°F)
Storage temperature: -40 .. +85°C (-40 .. +185°F)
Relative humidity: 10..95% (non condensing)
Supply voltage: 24 V DC -15%..+30%
Supply rail current: max. 40 A
24V supply: 2 x M5

Analog Input Module

Input Channels:16 Channels
A/D Converter Resolution:16 bits
Input Range:4-20 mA
Normal Mode Rejection Ratio, at 60 Hz:19 dB
Normal Mode Filter Response:Single-pole RC, -3 dB @ 6.5 Hz
Crosstalk, dc to 60 Hz:-60 dB
Maximum Input Voltage:± 30 Volts
Input Scan:Rate 50 ms

Digital Input Module

Normal (20ms PV scan)
Low Latency (5ms PV scan)
Extensive internal diagnostics for data integrity
Open Wire Detection (in Normal mode only)
Optional redundancy
Internal or external field power selection
On board excitation power (no need formarshalling power)
Supplies Non-incendive field power
Direct / Reverse Input Indication

UCN PM Power Supply

Isolated Output: 4–20 mA (HART-enabled)
Load Capacity: ≤600 Ω
Accuracy: ±0.05% of span (typical)
Input Impedance: ≤250 Ω
Channel-to-Channel: 300V AC
Humidity: 5–95% non-condensing
