General Electric

small form-factor pluggable scanner module

Type:Scanner module
Speed:100 Mbps
Material:Multi-mode fiber (MMF)
Length:2 Kilometers
SD Card:Supported
Power:3.3 to 5 Volts
Port Connectors:Two RJ-45 and two SFP cages.
LED Indicators:Yes

Terminal board

Series: GE Mark VIe Series
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤8 W
Voltage Range:0–30 V DC or 0–120 V AC
Range: 0–10 V DC, 4–20 mA
Resolution: 16-bit ADC
Type: Form-C contact relays (1 A at 30 V DC)
Operating Temperature: -40°C to +70°C
Relative Humidity: 5–95% (non-condensing)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Input: 24 V DC (±10%)
Isolation: ≥1.5 kV
Digital Inputs:0–30 V DC
Analog Resolution:16-bit ADC
Operating Temperature: -40°C to +70°C
Shock/Vibration: to 5 G (5–500 Hz)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Terminal Capacity: ≤32 AWG
Input Voltage: 24 V DC (±10%)
Power Consumption: <5 W
Galvanic Isolation: Up to 1.5 kV AC/DC
Voltage Range for Inputs: 0–120 V AC/DC
Digital Inputs (DI):30 V DC/120 V AC
Operating: -40°C to +70°C
Storage: -40°C to +85°C
Humidity Tolerance: 5–95% non-condensing

Turbine Emergency Trip Board

Series: GE Mark VIe
Dual Power Inputs: Isolated 24 V DC
Fail-safe relay contact rating: 2 A at 24 V DC
Input Voltage: 24 V DC (±10%)
Temperature Range: -40°C to +70°C (continuous operation)
Surge Protection: TVS diodes/SRC filters on I/O channels
Relative Humidity: 5–95% (non-condensing)

RTD Input terminal board

Operating Voltage:24 V DC ±10%
Power Consumption: <10 W
Types: 2-wire, 3-wire
Number of Inputs: 8 channels
Excitation Current:1 mA
Measurement Resolution: ≤0.1°C

Relay Output Terminal Board

Series: Mark VIe
Product Type: Relay Output Terminal Board
Number of channels: 16
Relay Type: SPDT
Relay Contact Rating: 10A
Input Voltage Range: 12V, 24V
Number of Relay Channels: 4, 8
Relay Switching Current: Max 10A
Mounting Type: DIN rail
Output Resolution: 12-bit
Output Impedance: 10 Ohm
Analog outputs: 0-20 mA

Vibration terminal board

Series: GE Mark VIe
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
Proximity Probes: 0–10 kHz
Accelerometers: Up to 20 kHz
IEPE sensor excitation:typically 18–24 V DC
Analog input: ±10 V peak
Operating Temperature: -40°C to +70°C.
Humidity Tolerance: 5–95% (non-condensing)

Transient Data Interface Module

Input Voltage: 24 V DC (±10%)
Power Consumption: Typically <20 W
Sampling Rate:Up to 25.6 kS/s
Voltage ranges (analog): Typically ±10 V DC
Analog Input: 16-bit
Operating Temperature: -40°C to +70°C
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5%–95% (non-condensing)

SERVO AMPLIFIER MODULE

A06B6290H106
SERVO DRIVE
SERVO AMP
SERVO AMPLIFIER MODULE AISV 180HV
SERVO DRIVE MODULE AISV 180HV-B
FOR 30I-B SERIES
CNC

I/O Pack processor board

Processor Type:Mark VI
Backplane Power: +5 VDC
Analog: ±10 V, 4–20 mA
Digital: 24 V DC
Processing Speed: 100–200 MHz
Non-Volatile Memory (Flash):16–64 MB

CPU RAM backup battery

AUXILARY BATTERY MODULE
15.0 AMP-HOURS
COMPATIBLE WITH ALL BATTERY
CONNECTORS ON IC693 POWER SUPPLIES
MEMORY BACKUP BATTERY

Ethernet network interface unit

RX3I NIU WITH TWO SERIAL PORTS
20K OF LOCAL LOGIC
MODULE REQUIRES UNIVERSAL BASE (IC695CHSXXX)
REQUIRES ETHERNET MODULE (IC695ETM001)
NIU SUPPORTS ALL RX3I I/O MODULES

Operator Interface

QUICKPANEL TEXT
LCD
COMMUNICATIONS OUTPUT

SCANNER MODULE

IC695PNS001
RX3I PROFINET SCANNER MODULE
10/100/1000 WITH FOUR PORTS
1.2AMP @ 3.3VDC
1.1AMP @ 5 VDC
SINGLE SLOT

PACSystems RX3i Universal Backplane

PACSystems RX3i Universal Backplane
(IC695 Series), occupies 1 slot
24 Vdc Nominal Operates 18Vdc to 30 Vdc
40 W Total, All Loads
14 AWG to 22 AWG, 1 wire per terminal
Power, P/S Fault, Overload, Overtemperature

Emergency Turbine Protection Module

Frame Rate Up to 100 Hz
MPU Pulse Rate Range 2 Hz to 20 kHz
Input supply: 125 V dc (70-145 V dc)
Output: 5 V dc and 28 V dc
Input Channels:4–20 mA

Industrial Circuit Board

Analog Inputs: 4–8 channels
Analog Outputs: 4–20 mA or ±10 V DC
Digital I/O: 24 V DC
Form Factor: 6U VME module
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Humidity: 5–95% RH (non-condensing).

VME Controller Board

System: Mark VI Turbine Control System
Clock Speed: ≥1 GHz
RAM: 1–2 GB DDR3
Flash Storage: 4–8 GB
Form Factor: 6U VME module
Voltage: 24 V DC (±10%)
Power Consumption: ≤25 W

VME Monitor Board

Analog: 4–20 mA, ±10 V DC
Digital: 24 V DC dry/wet contacts
Frequency: Vibration signals
Form Factor: 6U VME module
Data Acquisition:16-bit ADC resolution
Sampling rates up to 50 kS/s
Backplane: VME P1/J1 connectors for bus communication

Exciter DC Feedback Board

Voltage Feedback: 0–500 V DC
Current Feedback: 0–10 A DC
Accuracy: ±0.25% of full scale
Frequency Response: Up to 100 Hz
Signal-to-System Isolation: 1500 V AC
Common-Mode Rejection: >60 dB at 50/60 Hz
Analog Output: 4–20 mA or 0–10 V DC

RSTi-EP CPE100 Standalone Controller

Part Number:EPSCPE100
Storage:1MB
I/O:2k Bits Discrete I/O, 32k Words for Analog I/O
Media Redundancy Protocol (MRP)
SRTP Client/Server (Max 8 Connections)
Modbus TCP/IP (Max 8 Connections)
OPC-UA Server (Max 8 Clients)
EDG (Max 16 Exchanges)
PROFINET (Max 8 IO Devices)
Ethernet Port:1x 10/100, 1x 3-port switch 10/100

Power Supply module

Power Supply:40 Watts
Nominal Rated Voltage:120/240 VAC or 125 VDC
Input Voltage Range:18 to 30 VDC
Input Power:60 Watts maximum at full load
Outputs:3
Ripple:150 mV
Output Current:5.1 VDC
Noise:150 mV
Isolation None
Number of Daisy-Chained PSD140:Up to 4
Terminal Current:6 Amps

PACSystems RX7i controller

Application:Rx7i PLC System
Random Access Memory (RAM):64 MB
Operating Voltage:+5, +15, -12 Volt DC
Flash Memory:64 MB
Current Rating:3.4 Amps
Discrete I/O memory:32 K
Microprocessor:600 MHz Pentium M
Analog I/O memory:32 Kwords
CPU Memory:64 Megabytes
Compatible Memory storage:SRAM, Flash
User Memory:64 Megabytes
Processor speed:600 MHz
Max Program Block:512 Program Blocks

Control Module

Supply Voltage: 24 VDC
Isolation: 1500 VAC
Operating Temperature: -40°C to +70°C
Enclosure Rating: IP20
Backplane Compatibility: PACSystems RX3i racks
