RX3i power supply
Rated Voltage:120/240 VAC or 125 VDC
Input Voltage Range:
85 to 264 VAC or 100 to 300 VDC
Number of Slots:2
Output Power: 40 Watts max
Output Voltage:24 VDC, 5.1 VDC or 3.3 VDC
Output Current:0-1.6 A, 0-6 A, or 0-9 Amps
Feeder Distribution Protection Relay
Ambient Storage
Temperature Range -40°F to +176°F
Frequency 25 to 60 Hz nominal
Insulation Voltage 300 V
Manual 1601-0120-AE
Operating Temperature Range -40°F to +140°F
Series: Mark VIe
Product Type: Controller Card
Microprocessor: Intel Pentium M Processor 1.6 GHz
Memory: 256 MB
Operating System: QNX Neutrino
Motor Management Relay
non-isolated RS232 port, RS485 port
<200 ms
2000 m (max)
-40°F (-40°C) to +140°F (+60°C)
1 A and 5 A secondary
INPUT MODULE
INPUT MODULE
32POINT
LOGIC
SERIES 90-30
POSITIVE/NEGATIVE
7 AMP MAX
24 VDC
OUTPUT MODULE
IC693ALG390
OUTPUT MODULE
ANALOG
90-30 SERIES
2 CHANNEL
24 VDC 5 MA
120 MA
SCREW TYPE TERMINAL
CPU ENERGY PACK MODULE
IC695ACC400
CPU ENERGY PACK MODULE
INTENDED FOR USE WITH RX3I CPE305 OR CPE310 CONTROLLER CPU
I/O MODULE
IC693MDL930
I/O MODULE
DISCRETE
8 POINT
AC/DC OUTPUT
120/240 VAC
5/24/125 VDC
RELAY
NORMALLY OPEN
4 AMP
ISOLATED
8 CHANNEL RELAY OUTPUT MODULE
90-30 SERIES
ANALOG INPUT MODULE
IC695ALG600
ANALOG INPUT MODULE
UNIVERSAL
CONFIGURABLE FOR THERMOCOUPLE
RTD
RESISTIVE
CURRENT OR VOLTAGE
8 CHANNEL GENERAL PURPOSE
2 ISOLATED GROUPS: 4 CHANNELS PER GROUP
2CJC CHANNELS
COLD JUNTION COMPENSATION
OUTPUT MODULE
OUTPUT MODULE
12/24 VDC
POSITIVE LOGIC
32 POINTS
INTERFACE USES FUJITSU CONNECTOR
CENTRAL PROCESSING UNIT
CENTRAL PROCESSING UNIT
300 MHZ
10 MB MEMORY
2 SERIAL PORTS
2 SLOT
CONTROL MODULE
CONTROL MODULE
RX3I CPU
1 GHZ PROCESSOR
2 SERIAL PORTS
RS-485 / RS-232
20 MB USER MEMORY
printed circuit board
IS200WETAH1ABR2
DISCONTINUED BY MANUFACTURER
printed circuit board
Single Board
(4) USB Front Connectors
Reset Button
(1) SATA Port
(4) Ethernet Ports
CPU module
Product type CPU module
Compatibility GE Fanuc 90-70 PLCs
RAM 1 MB
NV-RAM 256 KB
Microprocessor 80486DX4
Clock speed 96 megahertz
Analog Input Module
Channels Four 3-wire and/or 4-wire RTDs
Backplane currentconsumption5V output: 125mA maximum. 3.3V output: 125mA
Normal mode rejection 60dB, at 50/60 Hz, 100% span
Common mode rejection 120 dB at 50/60Hz, 100 ohm imbalance
Common mode voltage 3V maximum
Normal mode voltage 5V maximum
Digital Resolution 15 bits plus sign
Maximum lead resistance 50 ohms per lead
Analog Input Thermocouple Module
Thermocouple types J, K, T, S, R, none (used for mV inputs)
Spans (+/–) 19.5mV, 39mV, 78.125mV, 156.25mV, 312.5mV,625mV
Converter resolution 15 bits + sign
Conformity error +/–0.3 degree Celsius, +/–0.5 degree Fahrenheit.
Normal mode rejection 60dB, at 50/60 Hz, 100% span
Common mode rejection 120 dB at 50/60Hz, 100 ohm imbalance
Common mode voltage 3 VDC maximum
Analog Output module
No. of channels: 4 single-ended, one group
Voltage Range: 18 - 30 VDC
Current Range: 4 - 20 mA
Update Rate: 0.3 ms
LED Indicators: FLD PWR, OK
Power Consumption: 50 mA from +5V bus
