General Electric

Discrete input module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL645A
Rated Voltage:24 Volts DC (positive or negative logic)
No of Channels:Sixteen (16)
Input points:16 (1 group)
Wiring configuration:Positive / Negative Logic
Input Current:7 Milliamperes
Input signal range:0-30 VDC
Nominal Input voltage:24 VDC
Input current:7 mA per channel
Off state voltage:0 - +5 VDC
On state current:3.2 mA
Off state current:1.1 mA
On response time, typical:7 ms
On response time, maximum:7 ms
Product Lifecycle Status:Active

Analog input module

Series:PACSystem RX3i
Manufacturer:GE Intelligent Platform (GE IP); Emerson Automation (Current)
Part Number:IC694ALG221A
No of Channels:Four (4) input channels
Product Type:Input Module
Nominal Input signal:0-20 mA; 4-20 mA
Module Type:Analog
Channel update rate:2 ms
Product Description:Analog input module
Digital Resolution:12 bit
LED:1 Green "Module OK" LED
Common Mode Voltage:200 volts
Input Filter Response:325 Hz
Product Lifecycle Status:Active
Hot-Swapping:Not Supported
Accuracy:0.1 % full scale
Input filter response:325 Hz
Input impedance:250 ohms
Linearity:< 1 Least Significant Bit

Discrete input module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL645D
Rated Voltage:24 Volts DC (positive or negative logic)
No of Channels:Sixteen (16)
Input points:16 (1 group)
Wiring configuration:Positive / Negative Logic
Input Current:7 Milliamperes
Input signal range:0-30 VDC
Input Voltage Range:0 to 30 Volts DC
Nominal Input voltage:24 VDC
On State Voltage:11.5 - 30 VDC
Off state voltage:0 - +5 VDC
On state current:3.2 mA
Off state current:1.1 mA
On response time, typical:7 ms
On response time, maximum:7 ms
Product Lifecycle Status:Active

INPUT MODULE

IC600BF832
DISCONTINUED BY MANUFACTURER
INPUT MODULE
SERIES SIX
115 VAC
32 POINT

Discrete output module

Series:Series 90-30
Manufacturer:GE Fanuc; Emerson Automation (Current)
Part Number:IC693MDL741
Product type:Digital I/O
Compatibility:GE Fanuc 90-30 PLCs
Product Description:Discrete output module
Output points:16
No of Channels:Sixteen (16)
Peak module current draw:110 milliamps
No. of output groups:Two (2)
Module voltage input:5 Volts DC
Channels per group:Eight (8)
Rated voltage:12/ 24 Volts DC
Peak output voltage drop:0.5 Volts
Nominal output voltage:12 / 24 VDC
On response time, maximum:2 ms
Off response time, maximum:2 ms
Output Voltage Drop:0.5 volts, maximum
Off-state Leakage:1 mA maximum

VME Communications Board

Functional Abbreviation:VCMI
Indicator LEDs:Run, Fail, Status, Reset
Instruction Manual:GEH-6421
OEM:GE Energy
Series:Mark VI Control System
Part Number:IS215VCMIH2C
Product Type:VME Communication Card

DC power supply input module

Single Board Computer

Network: Dual Gigabit Ethernet ports.
USB: USB 2.0/3.0 ports for peripheral connectivity.
Serial: RS-232/422/485 interfaces.
Graphics: VGA, DVI, or DisplayPort for display output
Operating Temperature: -40°C to +85°C (ruggedized variants).
Certifications: MIL-STD-810 (shock/vibration), CE, RoHS.
Power Input: 5V or 12V DC

Bus Interface Unit

CPU module

Series:RX3i PacSystem
Part Number:IC695CPE330-AFAT
Product Type:CPU module
Processor Clock Speed:1.0 Ghz
RAM:64 MB
NVRAM:64MB
I/O Points:up to 32 K I/O
Controller Redundancy:Supported
Maximum Program Blocks:512
Maximum Block Size:128 kilobytes

I/O PACK

I/O PACK
SPEEDTRONIC GAS TURBINE CONTROL
MARK VI SERIES
TURBINE INPUT / OUTPUT
PRIMARY TURBINE PROTECTION
REGULATES HRSG (BOILER)

I/O Protection Module

Nominal: 24 V DC
Operating Range: 18–30 V DC
Channel-to-System: 1500 V AC/DC
ESD Protection: Up to ±8 kV
Digital Inputs: Accepts 24 V DC
Operating Temperature: -40°C to +70°C
Storage Temperature: -50°C to +85°C.
Humidity: 0–95% non-condensing.

PROFINET Controller Gateway Module

Series:Mark VIe/Mark VIeS
Product Type:PROFINET Gateway Module
Processor Type:1066 MHz EP80579 Intel
Operating Temperature:22 to 149°F
Manufacturer:General Electric

op Box A Module Board

Series: Mark VIe
Channels: Configurable for 16–32 analog/digital channels
Analog: 4–20 mA, 0–10 V, RTD
Digital: 24 VDC dry/wet contacts
Supply Voltage: 24 VDC nominal
Power Consumption: Typically ≤ 8 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F)

Top Box B Module

Series: Mark VI
Supply Voltage: Typically 24 VDC
Power Consumption: Varies by load
Operating Temperature: -40°C to +70°C
Humidity: 0–95% non-condensing

Analog Input Module

Series:Versamax
Part Number:IC200ALG263
Product Description :Analog Input Module
Number of Inputs:15, single-ended
Input Voltage:-10 Volts to 10 Volts
Input Impedance:100K Ohms minimum
Resolution:+/- 15 bits
Update Rate:7.5 ms
LED Indicators:OK LED

Input Terminal Board

Series: Mark VI
Model Number: IS200AEADH4ADA
Type: Input Terminal Board
Input Voltage:
Typically operates at 24V DC
Operating Temperature Range:
-40°C to +85°C (-40°F to +185°F)

CIRCUIT BOARD

Input Voltage:
Typically operates at 24V DC
Operating Temperature Range:
-40°C to +85°C (-40°F to +185°F)
Serial Communication: RS-232/RS-485

Printed circuit board

Input Voltage: Typically 24 V DC
Operating Temperature Range:
Typically -30°C to +70°C (-22°F to 158°F)
Storage Temperature Range:
 -40°C to +85°C (-40°F to 185°F)

Digital Input Module

DIGITAL INPUT MODULE
24VDC
SOURCE
64 POINT

Vibration Monitor I/O Pack

Ambient Temperature Range:-30 to 65 °C
Board Compatibility:Vibration Terminal Board (TVBA)
Channels Thirteen for Proximity and Vibration
Common Mode Voltage Min:5 VDC
Frame Rates:3.125, 6.25, 12.5, 25, 50, and 100 Hz
Functional Acronym/Abbreviation:PVIB
LED Indicators:4
Probe Power:-24 VDC, 12 mA load per transducer
Status LEDs:Attn, Pwr, Link, TxRx

Analog input module

Series:PACSystem RX7i
Module Type:Analog Input
Number of Inputs:8 single-ended or 4 differential input channels
Input signals, Current:0-20 mA; 4-20 mA; +/-20 mA;
Product Description Analog input module
Current Range:0-20 mA, 4-20 mA, +/-20 mA

Processor-based VME (VMEbus) single board computer

Up to 512MB PC133 SDRAM
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

PROFIBUS INTERFACE CARD

PROFIBUS INTERFACE CARD
1 PORT CHANNEL
Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital
