Invensys

CABLE ASSEMBLY

P0916FH
DISCONTINUED BY MANUFACTURER
CABLE ASSEMBLY
TYPE 4
1 METER LENGTH
FBM2XX
TERMINAL CABLE

Relay Output Module

Communication Protocol:Modbus TCP/IP, DeviceNet
Data Rate:Up to 1 Mbps
Power Consumption:L ess than 4W
Operating Temperature:-40C to +70°C
Mounting Type:Panel Mount

Analog Output Module

Points:4, commoned-return, DC-coupled
Output current range:
4–20 mA output, controlled
0–22 mA over-range
0 mA output capability (step function <2 mA)
Type:TMR
Resolution:12 bits
Diagnostic:Forced-switch diagnostic (FSD)
Over-range protection:36 V DC, continuous

Main Processor (UMP) Module

Power consumption: Typically 15-30W
Operates on 24V DC
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% non-condensing

Input Module

Input16 group isolated and independent channels
Input Range (each channel)0 to 20.4 mA DC (each channel current limited to33 mA)
Accuracy (includes linearity)±0.03% of span
Accuracy temperature coefficient: ±50 ppm/° C
Common Mode Rejection>100 db at 50 or 60 Hz
Normal Mode Rejection>35 db at 50 or 60 Hz
Input Channel Impedance61.9 Ω nominal
INPUT VOLTAGE RANGE (REDUNDANT)24 V DC +5%, -10%
CONSUMPTION7 W (maximum) at 24 V DC11 W (maximum) at 24 V DC with all inputs at20.4 mA (internal power)

Digital Relay Output Module

3636T
DIGITAL RELAY OUTPUT MODULE
32 POINT
2 AMP
125 VAC/DC
1900 VDC POINT ISOLATION
NON-TRIPLICATED

Analog Input Baseplate

Fault current130 mA,
typical200 mA, maximum
Current Input: 4–20 mA, 0–20 mA.
Voltage Input: 0–10 V DC, ±10 V DC
Resolution:16-bit resolution
Accuracy:±0.1% of full scale
Channel-to-channel isolation: 1500 V AC/DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)

POWER MODULE

Support for 10 Mbps Ethernet trunk Fieldbus
Support for DIN rail mounted FBMs
Optional redundancy
Compact, rugged design
Easy to install and configure
