SAIA

Output module

Number of outputs 16, electrically connected
Short circuit protection yes
Total current per module 8 A on 100 % duty cycle
Voltage drop ≤ 0,3 V at 0,5 A
Internal currentconsumption(from V+ bus)0 mA
External currentconsumptionLoad current
Operating mode Source operation
Voltage range 10…32 VDC, smoothed,max. 10 % residual ripple

CONTROL MODULE

AC: 24–240 VAC (50/60 Hz)
DC: 24–48 VDC.
Power Consumption: Typically ≤ 3 W
Switching Current: Up to 5–8 A
Voltage: 250 VAC/30 VDC max
Repeat accuracy: ±1%
Operating Temperature: –25°C to +55°C

PCD2M110
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
24VDC
128KB
8SOCKET

I/O Cable

PCD2K110
DISCONTINUED BY MANUFACTURER
PLC MODULE CABLE 3METER 10POLE

PCD2C100
DISCONTINUED BY MANUFACTURER
EXPANSION SUPPLY MODULE
24 VDC
8 SOCKET

Processor Unit

Architecture: 32-bit RISC CPU
Supply Voltage: 24 V DC ± 20 %
Power Consumption: 8 W typical
Galvanic Isolation: 500 V between supply
Retentive Memory: 128 kB FRAM
Processing Time: 0.1 µs / binary instruction
Real-Time Clock: ± 1 min / month @ 25 °C

PCD2F522
DISCONTINUED BY MANUFACTURER
I/O INTERFACE

Digital I/O Modul

PCD4B900
DISCONTINUED BY MANUFACTURER
I/O MODULE
24 VDC
0.5 AMP
32 PT
16 INPUTS
16 OUTPUTS
SMOOTH/PULSED
9 MS
