GE PACSystems RX7i

PACSystems RX7i controller

Application:Rx7i PLC System
Random Access Memory (RAM):64 MB
Operating Voltage:+5, +15, -12 Volt DC
Flash Memory:64 MB
Current Rating:3.4 Amps
Discrete I/O memory:32 K
Microprocessor:600 MHz Pentium M
Analog I/O memory:32 Kwords
CPU Memory:64 Megabytes
Compatible Memory storage:SRAM, Flash
User Memory:64 Megabytes
Processor speed:600 MHz
Max Program Block:512 Program Blocks

Digital Input Module

DIGITAL INPUT MODULE
24VDC
SOURCE
64 POINT

Analog input module

Series:PACSystem RX7i
Module Type:Analog Input
Number of Inputs:8 single-ended or 4 differential input channels
Input signals, Current:0-20 mA; 4-20 mA; +/-20 mA;
Product Description Analog input module
Current Range:0-20 mA, 4-20 mA, +/-20 mA

Ethernet interface module

Compatible:System RX7i system
Part Number:IC698ETM001
Series:Rx7i PACsystem
Brand:GE Fanuc
Speed:200 MHz
Voltage:5 Volts DC
Current:1.2 Amperes
Connector:10 Base T/100 Base Tx, RJ 45
Maximum Number of IP Addresses:One

RX7i 9 Slot Rear Mount Rack

BUS CONTROLLER

BUS CONTROLLER
SINGLE SLOT
GENIUS
1 CHANNEL
GE RX7I BUS CONTROLLER
1.3 AMP
5 V DC

Power supply module

Series:Rx7i PACsystem
Manufacturer:GE Intelligent Platforms (Former); Emerson Automation (Current)
Part Number:IC698PSA100
Description:Power supply module
Ride through time:15 ms
Slot Assignment:Slot 0
Voltage:120/240 Volts AC, 125 Volts DC
Mounting:Leftmost slot
Input Voltage Range:85 to 264 VAC; 100-150VDC
Power Rating:125 Watts
Nominal Input frequency:120/240 VAC, 125VDC
Output Voltage:5/12, -12 Volts DC
AC Input Frequency:47-63 Hz
Power Factor:0.99 min
Isolation:1500 Volts
Holdup Time:5 ms
Ride Through:15 milliseconds

Power Supply module

Series:PACSystem RX7i
Manufacturer:GE Fanuc
Part Number:IC698PSA350
Nominal Rated Voltage:120/240 VAC, 125 VDC
Part Number:IC698PSA350
Power:100 watts
Input Voltage Range:85 to 264 VAC; 100-150VDC
AC Input Frequency:47-63 Hz
Temperature:0-60 degrees celsius
Ride through time:15 ms
Holdup time:5 ms
Slot Assignment:Slot 0
Product lifecycle:Active
GND Wire:12 AWG
Isolation:1500 Volts DC
Output Voltage:5.1 VDC; +12 VDC; - 12VDC

Auxiliary Smart Battery Module

Series:Rx7i PACsystem
Part Number:IC698ACC701
Description:Auxiliary Smart Battery Module
Application:RX7i System
Max Current Rating:15.0 Amps
Battery Content:5.1 Grams Lithium
