Technical specifications for MVI56E-MNETXT
-
Product ModelMVI56E-MNETXT
-
Product ParametersNETWORK INTERFACE MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size3.5x14.3x14.5cm
-
ManufacturerProSoft
-
Weight0.25 kg
-
Backplane Current Load800 mA @ 5 VDC/3 mA @ 24 VDC
-
Operating Temperature-25°C to 70°C (-13°F to 158°F)
-
Storage Temperature-40°C to 85°C (-40°F to 185°F)
-
Relative Humidity5% to 95% RH, with no condensation
-
Ethernet Port10/100 Base-T, RJ45 Connector, for CAT5 cable Link and Activity LED indicators Auto-crossover cable detection
-
Shipped with Unit5-foot Ethernet straight-through cable
Description
MVI56EMNETXT
NETWORK INTERFACE MODULE
MODBUS
TCP/IP
800 MA @ 5 V DC
3 MA @ 24 V DC
NETWORK INTERFACE MODULE
MODBUS
TCP/IP
800 MA @ 5 V DC
3 MA @ 24 V DC
Information
Overview
Manuals
Technical notes
Product Applications
Comparison with Related Models
Features:
- Backward compatible with previous MVI56-MNET
- Single-slot 1756 ControlLogix backplane compatible
- 10/100 Mbps auto-crossover Ethernet ports
- User-definable memory mapping up to 5000 registers
- CIPconnect-enabled diagnostics via ControlLogix modules
- ProSoft Configuration Builder (PCB) software supported
- Sample ladder logic & AOI for data transfer
- 4-character LED display with plain English status
- ProSoft Discovery Service (PDS) for IP assignment
- Personality module (CF card) for quick field replacement
- Non-volatile CF stores network & module config
The MVI56E-MNETXT ProSoft Network Interface Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ProSoft MVI56E-MNETXT Network Interface Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
XT series for Extreme Environments: The MVI56E-MNETXT is part of the new XTseries, designed to work at extreme temperatures and in harsh or causticenvironments. XT series modules operate over a wider temperature range than thestandard MVI56E series. The XT series also comes with conformal coating to protectmodule components from corrosive environmental elements.
The MVI56E-MNET module communicates directly over the ControlLogix backplane.Data is paged between the module and the ControlLogix processor across thebackplane using the module's input and output images. The update frequency of theimages is determined by the scheduled scan rate defined by the user for the module andthe communication load on the module. Typical update times range from 1 to 10milliseconds.This bi-directional transfer of data is accomplished by the module putting data in theinput image to send to the processor. Data in the input image is placed in theprocessor's controller tags by ladder logic. The input image is set to 250 words.Processor logic inserts data to the output image to be transferred to the module. Themodule's firmware program extracts the data and places it in the module's internaldatabase. The output image is set to 248 words.
The MVI56E-MNET module communicates directly over the ControlLogix backplane.Data is paged between the module and the ControlLogix processor across thebackplane using the module's input and output images. The update frequency of theimages is determined by the scheduled scan rate defined by the user for the module andthe communication load on the module. Typical update times range from 1 to 10milliseconds.This bi-directional transfer of data is accomplished by the module putting data in theinput image to send to the processor. Data in the input image is placed in theprocessor's controller tags by ladder logic. The input image is set to 250 words.Processor logic inserts data to the output image to be transferred to the module. Themodule's firmware program extracts the data and places it in the module's internaldatabase. The output image is set to 248 words.
- Flow Meters & Level Sensors:Integrates liquid/gas measurements into control logic
- Temperature Controllers:Manages industrial ovens, furnaces & cooling systems
- Weight Scales:Interfaces with digital weighing for batching or packaging
- Modicon PACs/PLCs:Bridges communication with Schneider Electric hardware
- DCS & SCADA Systems:Gateway to larger plant-wide monitoring systems
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
XT series for Extreme Environments: The MVI56E-MNETXT is part of the new XTseries, designed to work at extreme temperatures and in harsh or causticenvironments. XT series modules operate over a wider temperature range than thestandard MVI56E series. The XT series also comes with conformal coating to protectmodule components from corrosive environmental elements.
The MVI56E-MNET and MVI56E-MNETXT are functionally the same. The MVI56EMNET is designed for standard process applications. The MVI56E-MNETXT is designedfor the Logix-XT™ control platform, allowing it to operate in extreme environments andat higher operating temperatures. It has a conformal coating to protect it from harsh orcaustic conditions.
FAQs
-
What is MVI56E-MNETXT ?
+The ProSoft Technology MVI56E-MNET and MVI56E-MNETXT are Enhanced Modbus TCP/IP Communication Modules designed for Rockwell Automation ControlLogix processors. -
What is the difference between MVI56E-MNET and MVI56E-MNETXT?
+The modules are functionally identical. However, the MNETXT version is built for extreme environments with an operating temperature range of -25°C to 70°C (-13°F to 158°F), whereas the standard MNET ranges from 0°C to 60°C -
What are the power requirements of the MVI56E-MNETXT?
+This module draws 800mA at 5V DC and 3mA at 24V DC from the ControlLogix backplane. -
What do the LEDs indicate?
+The module features a 4-character scrolling LED display that provides status, version, IP address, and diagnostic information in plain English.
