Ovation

RTD Input Module

RTD Input Module
10/100 Mbps Ethernet
16 analog input channels (4-20 mA)
24 VDC

Remote Node Controller EMOD

1C31203G01
REMOTE I/O NODE CONTROLLER
+5V power for the module

INPUT MODULE

5X00070G04
INPUT MODULE
EMOD ASSEMBLY
ANALOG INPUT
8CHANNEL
14BIT
MEDIUM/HIGH SPEED
20 / 50 / 100MV

Remote Node Transition Panel

1P00028G01
DISCONTINUED BY MANUFACTURER
LOCAL I/O TRANSITION PANEL
OVATION
REMOTE NODE

Valve Positioner Personality Module

VALVE POSITIONER CONTROL MODULE
1X LIM/SLIM PORT
1X RS-232 SERIAL PORT
1.25 AMP
250 V

5X00058G01
DISCONTINUED BY MANUFACTURER
INPUT MODULE ANALOG HART

Power Distribution Module

Nominal AC Input Voltage 100 - 240 VAC
AC Input Voltage Range 85 to 264 VAC
DC Input Voltage Range 90 to 375 VDC
Frequency 43 to 67 Hz
Nominal Current 3.2 – 1.0 A
Efficiency > 90% typ. (24 W)
Inrush Current (max) Typ. < 30 A
Power Factor Correction Active power factor correction to better than 0.92
Voltage Phase Type Single phase (AC voltage)

Control Base Assembly

CONTROLLER BASE RACK
4 SLOT
Distributed Control System
supports 8 to 16 I/O
24 VDC
Operating Temperature 0°C to 60°C
Storage Temperature -40°C to 85°C
Humidity 5% to 95% non-condensing

4-20mA Analog Input Module (EM), High Speed

5X00070G01
ANALOG INPUT MODULE
HIGH SPEED (5X00070G01)
4-20MA

4-20mA Analog Input EMOD

INPUT MODULE
ANALOG
8 CHANNEL
14 BIT
4 - 20 MA

1C31222G01:Relay Output Base - High Power 1C31219G01:Relay Output Logic Module

PLC RELAY OUTPUT
BASE
Current: 2A to 5A
Voltage: Up to 250V AC/DC or 24V DC
AC: Up to 250V AC, 5A
DC: Up to 30V DC, 5A
Operating Temperature Range -10°C to 60°C

PMOD ASSY, VALVE POSITIONER

Resolution 16-bit resolution
Operating Voltage 24 VDC
Operating Temperature  0°C to 60°C
Storage Temperature -40°C to 85°C
Humidity 5% to 95% non-condensing

Value Positioner

VALVE POSITIONER MODULE
Input Signal:4-20mA + HART
Supply Pressure:1.4-7 bar (20-100 psi)
Air Consumption:<0.01 Nm³/h (0.35 scfh)
Operating Range:0-100% stroke
Accuracy:±0.5% of span

8-Channel RTD Input PMOD

5X00121G01
DISCONTINUED BY MANUFACTURER
INPUT MODULE
8 CHANNEL
RTD

8-Channel RTD Input EMOD

Number of channels 8
Resolution 12 bits
Guaranteed accuracy
0.10%  [0.045 (Rcold/Rspan)]%
Temperature coefficient 10ppm/℃
Input impedance
100 M OHM50 K OHM in power down
Module power 3.6 W typical;
4.2 W maximum
Operating temperature range 0 to 60℃ (32℉to 140℉)
Storage temperature range -40℃ to 85℃ (-40℉ to 185℉)
Humidity (non-condensing) 0 to 95%
