GE VMIC

Single Board Computer

VME-7807 Series
SINGLE PCB BOARD
PROCESSOR: 1.8GHZ PENTIUM M DDR
SDRAM: 1 GB L2 CACHE: 2MB
FLASH: 512 KB 1101.10
FRONT PANELSCAN DISK 2GBITES

Processor-based VME (VMEbus) single board computer

Up to 512MB PC133 SDRAM
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

PROFIBUS INTERFACE CARD

PROFIBUS INTERFACE CARD
1 PORT CHANNEL
Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital

I/O Expansion Unit

Power Supply:DC 24V
Digital Input: Typically 24V DC
Operating Temperature:
Typically 0 to 50°C (32°F to 122°F)
Storage Temperature:
Typically -20°C to 70°C (-4°F to 158°F)
Humidity: 30% to 85% RH, non-condensing

Embedded Single Board

Up to 512MB PC100 SDRAM
(PC133 stepped down to 100 MHz)
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

Multifunctional Serial Input/Output Board

A16:D8
Four Full-Duplex Channels
Fully Programmable Synchronous
Asynchronous Operation
RS-232C, RS-423, RS-422A,
and RS-485 Compatible
0 to 1 Mbaud Data Rate
Self-Test Capability
Programmable Interrupt Capability
Modem Control Lines for Each Channel
Uses Four Industry-Standard 25-Pin Subminiature D Connectors
Double Eurocard Form Factor
Four Programmable Baud Rate Generators

Analog I/O Board

(8) Sample-and-Hold
Analog Input Channels
12-Bit A/D Converter
PGA Provides Program-Controlled
Gains of x1, x2, x4, x8 and x16
125 kHz Maximum Scan Rate (Gain = x1)
Dual 128 KB Data Buffers for Analog Inputs / Outputs
Analog Function Generation

Single Board

(4) USB Front Connectors
Reset Button
(1) SATA Port
(4) Ethernet Ports

Embedded Single Board

Up to 512MB PC100 SDRAM
(PC133 stepped down to 100 MHz)
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

ARD DRIVE MODULE W/ FLOPPY DRIVE

Series: Fanuc
Dimensions: Standard VME 6U Single Slot Form Factor
3.5-inch 1.44 MB Floppy Drive
Power consumption: Low Power
Number of Channels: 24
Inputs: 125 V dc, 15A
Input Impedance: 4-20 mA

Single Board Computer

Front Panel USB Ports
Front Access Reset Switch
15-Pin SVGA Port
Freescale (NXP) MPC7448 processor @ 1.0-1.7 GHz
DDR2 SDRAM: Up to 2GB
L2 Cache: Typically 1MB

Dual Channel To Synchro/Resolver Converter Board
