Processor Module

Software designation:PL7 Junior/Pro
Number of racks:6 4/6/8 slots;8 12 slots
Discrete I/O processor:1024 I/O
Number of application specific channel:32
Current consumption：1360 mA at 5 V DC
Module format：Double
Operating altitude：0...2000 m

Processor Module

Input Voltage: 24 V DC
Input Range: 10–30 V DC
Number of Input Points: 32 points
Input Current: 3–5 mA per point
Isolation: 1500 V AC
Backplane Power: 5 V DC
Field Power: External 24 V DC supply for I/O
Input Delay: ≤ 1 ms

Digital Input Module

Extensive internal diagnostics for data integrity
NO Open wire detection
Optional redundancy
On board excitation power
Supplies Non-incendive field power
Direct / Reverse Input Indication
Galvanic isolation
Internal or external field power selection

Analog input module

SIMATIC S7-1500
Analog input module AI 8xU/I HS
16 bit resolution,
Accuracy 0.3% 8 channels in groups of 8
Common mode voltage 10 V
Diagnostics; Hardware interrupts 8 channels in 0.0625 ms Oversampling;
Delivery including infeed element

Cooling Fan

ZIEHL-ABEGG FB063-6EQ.4I.V4L
230V 2.3A 0.47KW Cooling Fan
ZIEHL-ABEGG substitute
without enclosure and grille
AC/DC:AC
Size :630 mm x 630 mm x mm
Current:2.3A
Power:0.47KW
Voltage:230V

8mm Eddy Current Sensor

Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor (ISF):
ISO: 8 V/mm (203.2 mV/mil) ± 5%
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)
temperature range 0 to 45°C(+32 to +113°F)

8mm Eddy Current Sensor

Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor (ISF):
ISO: 8 V/mm (203.2 mV/mil) ± 5%
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)
temperature range 0 to 45°C(+32 to +113°F)

Analog input module

Function:4 AI: U, I
Number of Analog Configurable I/Os:0
Analog Inputs:4
Input Signal:U, I
Resolution:Analog Input 12 bit
Connection Type:Pluggable
Degree of Protection:Housing IP20
Ambient Air Temperature:
Operation 0 ... +60 °C
Storage -40 ... +70 °C

RSTi-EP CPE100 Standalone Controller

Part Number:EPSCPE100
Storage:1MB
I/O:2k Bits Discrete I/O, 32k Words for Analog I/O
Media Redundancy Protocol (MRP)
SRTP Client/Server (Max 8 Connections)
Modbus TCP/IP (Max 8 Connections)
OPC-UA Server (Max 8 Clients)
EDG (Max 16 Exchanges)
PROFINET (Max 8 IO Devices)
Ethernet Port:1x 10/100, 1x 3-port switch 10/100

Digital Output Module

Output Channels:32
Load Voltage:30 VDC Maximum
Load Current :0.1 A per channel
Galvanic Isolation :1000 VAC RMS for System3
Off-State Voltage:24 V
Off-State Leak Current:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

COMMUNICATIONS MODULE

Product Type:Gas & Liquid Flow Computer
Slot(s):1
Rack Type:Local or Remote
Data Transfer Type:Ladder Logic
RAM:128 MB min
Hard Drive Space:100 MB min
Pentium PC:100 mHz or faster
Backplane Current Load:800 mA @ 5V DC

Power Supply module

Power Supply:40 Watts
Nominal Rated Voltage:120/240 VAC or 125 VDC
Input Voltage Range:18 to 30 VDC
Input Power:60 Watts maximum at full load
Outputs:3
Ripple:150 mV
Output Current:5.1 VDC
Noise:150 mV
Isolation None
Number of Daisy-Chained PSD140:Up to 4
Terminal Current:6 Amps

CPU module

Memory Main:256 MB with ECC
Static RAM:2 MB with ECC, backed up by battery
1 GB on-boad flash memory
2 Ethernet ports : RJ45 modular jacks
SB bus (duplex)
Supply voltage:5 V DC ±5 %
Current consumption:Max.1200 mA

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Probe

3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
040 4.0 meters (13.1 feet)
03 Armored cable with connectorprotector
05 Multiple Approvals

3300 XL 11 mm Probe

3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
M10 x 1 thread,without armor
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 CSA, ATEX, IECEx  Approvals

Interconnect Cable

Impedance:typically 50 Ω or
Voltage Rating: 250 VAC/VDC
Length: Often denoted by the suffix "-65"
Temperature Range: -40°C to +85°C

3300 NSv Proximity Probes

3300 NSv Probe
1/4-28 UNF thread,without armor
70 7.0 meters (23.0 feet)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread,with armor
15 1.5 meter (4.9 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread,with armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Proximity Probes

3300 NSv Probe
M10X1 thread,without armor
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

Ethernet/IP Communication Module

24 VDC nominal
18 to 32 VDC allowed
Positive, Negative, GND Terminals
2.5 mm screwdriver blade
500 mA max@ 32 VDC max
Acyclic communications (DPV1), Read and Write
Alarm Handling (DPV1)
Supports Sync and Freeze commands

PACSystems RX7i controller

Application:Rx7i PLC System
Random Access Memory (RAM):64 MB
Operating Voltage:+5, +15, -12 Volt DC
Flash Memory:64 MB
Current Rating:3.4 Amps
Discrete I/O memory:32 K
Microprocessor:600 MHz Pentium M
Analog I/O memory:32 Kwords
CPU Memory:64 Megabytes
Compatible Memory storage:SRAM, Flash
User Memory:64 Megabytes
Processor speed:600 MHz
Max Program Block:512 Program Blocks
