Bus module
Bus module for ET 200PA SMART
for holding two 40 mm wide I/Omodules
for insertion and removal function
Double format PL7 processor
TSXP57303AM
PROCESSOR
PL7 DOUBLE-FORMAT
1000 MA
5 VDC
IP20
SYNCHLINK BASE BLOCK
1751SLBA
SYNCHLINK BASE BLOCK
CONVERTS SYNCHLINK TO ELECTRICAL SIGNALS
TO INTERFACE UP TO 4 FIBER 4-PORT SPLITTER BLOCKS
1.2 AMP
600 MA
24 VDC
OPEN STYLE
MOUNTABLE
Digital output module
1769OG16
OUTPUT MODULE
COMPACTLOGIX
DC DIGITAL
4.5-5.5VDC
TTL OUTPUT
16 POINT
16 CURRENT SINKING (LOW TRUE) POINT
SynchLink Block
1751SL4SP
SYNCHLINK
4 PORT SPLITTER BLOCK
CONVERTS ELECTRICAL
SIGNALS FROM SYNCHLINK BASE
BLOCK TO 4 FIBER
OPTIC
PORTS
I/O SCANNER
900S75S0460
I/O SCANNER
2 PORT
1 PER I/O RACK
Input Voltage: 24 V DC (±10%)
Current Consumption: ≤100 mA
Power Isolation: 1500 V AC
POWER STATUS MODULE
900PSM0200
POWER STATUS MODULE. 5 VDC
22 MA MAX
Operating Voltage: 5 V DC (±10%)
Power SupplyLoading:5V; 22mA max
Current Consumption: ≤22 mA (max)
ANALOG OUTPUT MODULE
1444AOFX0004RB
ANALOG OUTPUT MODULE
5 AMP MAX
18-32 VDC
20 MA OUTPUT
DISSIPATION: 3.6 W
OPERATING TEMPERATURE: -40 TO +105 DEGREES C
Flex I/O Relay Output Module
1794OW8XT
OUTPUT MODULE
FLEX I/O
DISCRETE
CONTACT
8 POINTS FORM A RELAY CONTACTS OUTPUT
EXTENDED TEMPERATURE -20 TO +70 DEG
OPEN STYLE
DINMOUNT
IP20
Expansion Relay Module
1444RELX0004RB
EXPANSION RELAY MODULE
4 SINGLE POLE DOUBLE THROW RELAYS
CONNECT UP TO THREE TO
ONE 1444-DYN04-01RA
DYNAMIC MEASUREMENTMODULE.
REQUIRES 1444-TB-B BASE
AND 1444-REL-RPC- CONNECTOR SET
Double format PL7 processor
Current consumption:1110 mA 5 V DC
Module format:Double
Operating altitude:0...6561.68 ft (0...2000 m)
Protective treatment:TC
Analogue I/O processor:80 I/O
Discrete I/O processor:1024 I/O
Concept:Transparent Ready
Software Designation:PL7 Junior/Pro
Panelview Plus 1000 Operator Terminal
Display Size:10.4 in
Manufacturer:Rockwell Automation
Product Family:PanelView Plus Operator Terminals
Operator Input:Touch
Resolution:640 x 480
Toiuchscreen:1 million presses
Input Voltage range:18-32VDC
Communication:Ethernet and RS-232
Input Power:18 to 32 VDC
Memory:64 MB
Motor
Motor for circuit-breaker
springs charging M-MS-MAS aux
voltage 110-132Vdc
110-127Vac for HD4
VD4/R ESH
Voted EODS Relay Module
1440REX0304RG
RELAY MODULE
OVER SPEED
XM 442
OPEN STYLE
MOUNTABLE
TEMP CONTROLLER
Relay:SPDT, rated 5 A @ 250 V AC
Solid-State Relay (SSR) Driver:12 V DC, 30 mA
Analog Output:0–10 V DC or 4–20 mA
Accuracy: ±0.2% of full scale
Display Type: Backlit LED or LCD
Voltage: 100–240 V AC
Power Consumption: ≤ 5 W
COMMUNICATION MODULE
Input Voltage: 24 V DC
Range: 18–32 V DC
Power Consumption: Typically ≤ 10 W
Isolation Voltage: 1500 V AC
Serial Ports: RS-232/RS-485 (configurable).
Ethernet: 10/100 Mbps RJ45 (TCP/IP)
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -50°C to +85°C (-58°F to +185°F)
Processor Module
Software designation:PL7 Junior/Pro
Number of racks:6 4/6/8 slots;8 12 slots
Discrete I/O processor:1024 I/O
Number of application specific channel:32
Current consumption:1360 mA at 5 V DC
Module format:Double
Operating altitude:0...2000 m
Processor Module
Input Voltage: 24 V DC
Input Range: 10–30 V DC
Number of Input Points: 32 points
Input Current: 3–5 mA per point
Isolation: 1500 V AC
Backplane Power: 5 V DC
Field Power: External 24 V DC supply for I/O
Input Delay: ≤ 1 ms
Digital Input Module
Extensive internal diagnostics for data integrity
NO Open wire detection
Optional redundancy
On board excitation power
Supplies Non-incendive field power
Direct / Reverse Input Indication
Galvanic isolation
Internal or external field power selection
Analog input module
SIMATIC S7-1500
Analog input module AI 8xU/I HS
16 bit resolution,
Accuracy 0.3% 8 channels in groups of 8
Common mode voltage 10 V
Diagnostics; Hardware interrupts 8 channels in 0.0625 ms Oversampling;
Delivery including infeed element
Cooling Fan
ZIEHL-ABEGG FB063-6EQ.4I.V4L
230V 2.3A 0.47KW Cooling Fan
ZIEHL-ABEGG substitute
without enclosure and grille
AC/DC:AC
Size :630 mm x 630 mm x mm
Current:2.3A
Power:0.47KW
Voltage:230V
8mm Eddy Current Sensor
Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor (ISF):
ISO: 8 V/mm (203.2 mV/mil) ± 5%
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)
temperature range 0 to 45°C(+32 to +113°F)
8mm Eddy Current Sensor
Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor (ISF):
ISO: 8 V/mm (203.2 mV/mil) ± 5%
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)
temperature range 0 to 45°C(+32 to +113°F)
