Trusted CCoat Expan Proc Module

Supply Ratings:20 - 32 Vdc, 45 W
Backplane (IMB) Supply:20 Vdc to 32 Vdc
Power Dissipation:45 W Backplane Supply
Module Location:T8300 Expander Processor Slot
Fusing Not User Serviceable
Operating Temperature :0 °C to +60 °C (+32 °F to +140 °F)
Storage Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
Relative Humidity :10 % – 95 %, non-condensing

Trusted Power Distribution Unit

Visual indications of input power supply status.
Visual indication of individual fuse status.
Common alarm of fuse status via volt-free contact.
Link selectable supply voltage options

Trusted Power Distribution Unit

Voltage Range 22 Vdc to 28 Vdc
Input Current 60 A max
Conductor Clamping Range (LU10.16) 0.5 mm2 to 16 mm2
Max Switching Voltage 60 Vdc or 125 Vac
Operating Temperature 0 °C to +60 °C (+32 °F to +140 °F)
Non-operating Temperature -25 °C to +70 °C (-13 °F to +158 °F)

Trusted Output Power Distribution Unit

Supports up to three Trusted Sourcing Output Modules.
Dual stud power connection for either single or dual feed.
0 V module reference via BLZ 2-part connectors.

Power Shelf

POWER SHELF 4U MOUNTING KIT POWER PORT MAINS PLUGS
19 inch x 1U chassis
for up to 3 Power Packs.
Includes 4U fixing kit,
Power Port (with push fit BLZF3.5/10 connector),
mains plugs and retaining clips

Trusted TMR I/O SmartSlot Slot Cables

Cable Type: Multi-core shielded cable
Length: 2 meters
Voltage Rating: Typically rated for 300 V AC/DC
Current Capacity:4–20 mA analog
Operating Temperature: -40°C to +85°C

Trusted TMR I/O SmartSlot Slot Cable

Cable Type: Multi-core shielded cable
Length: 2 meters
Voltage Rating: Typically rated for 300 V AC/DC
Current Capacity:4–20 mA analog
Operating Temperature: -40°C to +85°C

Communications Cable

Communications Cable Assembly
From Communication Interface (T8151) to flying leads
Impedance: 100–120 Ω (for twisted-pair cables).
Voltage Rating: 300 V AC/DC (typical).
Data Rate: Up to 1 Gbps
Operating Temperature: -40°C to +85°C

EXPANDED MODULE TRUSTED FIBRE TX RX UNIT

Voltage: 100–240V AC (auto-ranging), 50/60 Hz.
Current: 10A (max at 100V AC)
Efficiency: ≥90%
Operating Temperature: -20°C to +70°C
Humidity: 5–95% non-condensing

Expander Processor

2 x 30 mm (1.2 in) Trusted Expander Processor Slots
12 x 30 mm (1.2 in) single width Trusted I/O Module Slots.
No user-serviceable parts inside.
Fast assembly.
Minimum tooling/parts.
32, 48, 64 and 96-way
DIN 41612 I/O port connector capability
Cable entry options.
Convection cooling of modules through the Chassis

Motor Control Board

Digital Inputs:24 Vdc
Analog Inputs: 0–10 V / 4–20 mA
Operating Temperature: -10°C to +50°C
Humidity: 5–95% non-condensing
Voltage: 24 Vdc (±10%)
Consumption: ≤ 10 W
Standards: CE, UL, cUL, RoHS

PCB Board

Operating Voltage: 24 Vdc (±10%).
Data Rate: 100 Mbps
Operating Temperature: -40°C to +70°C
Humidity: 5–95% non-condensing

Frequency Converter Board

IGCT MODULE
4500V
91MM
ALT PART NUMBER: 5SHY 3545L0016
DC Bus Voltage: 510–930 V DC
Output Current: Up to 600 A
Operating Temperature: -10°C to +50°C
Humidity: 5–95% non-condensing

Interconnect cable

Standard ArmoredInterconnect Cable
Stainless steel armor
overshielded 0.382 mm2 (22 AWG)
cable with a moistureresistant
female connector atthe transducer end
and ringlugs at the monitor end.
Temperature range -29 to121°C (-20 to 250°F)

SYNCHROTACT 4 multi motor

ABB SYNCHROTACT 4 multi motor
Voltage Inputs: 3-phase AC, 110–690 V
Frequency Range: 45–65 Hz
Frequency Matching: Precision ±0.01 Hz
Voltage Matching: ≤ ±1% deviation
Operating Temperature: -25°C to +55°C

ACS880 Power Board

ACS880 Power Board
Operating Voltage:  24 Vdc
Analog Inputs: 0–10 V or 4–20 mA
Operating Temperature: -10°C to +50°C
Humidity: 5–95% non-condensing

ACS880 frequency converter drive board

ACS880 frequency converter drive board
Operating Voltage:  24 Vdc
Analog Inputs: 0–10 V or 4–20 mA
Operating Temperature: -10°C to +50°C
Humidity: 5–95% non-condensing

Compact alternating current drives

Output Power: 160 kW (215 HP) at 400 V AC.
Output Current: 302 A
Input: 380–480 V AC, 3-phase (±10%), 50/60 Hz.
Output: 0–480 V AC
Efficiency: ≥97% (typical at full load)
Control I/O: 5x analog inputs (2x 0–10 V / 0–20 mA)
Switching Frequency: 1–8 kHz

VME Communications Board

Functional Abbreviation:VCMI
Indicator LEDs:Run, Fail, Status, Reset
Instruction Manual:GEH-6421
OEM:GE Energy
Series:Mark VI Control System
Part Number:IS215VCMIH2C
Product Type:VME Communication Card

3300 NSv Proximity Probes

3300 NSv Probe
M10 x 1 thread, withoutarmor
0 5 0.5 metre (20 in)
0 2 Miniature coaxial ClickLocconnector
standard cable
0 5 Multiple Approvals

3300 NSv Proximity Probes

3300 NSv Probe
1/4-28 UNF thread, withoutarmor
1 0 1.0 metre (39 in)
0 2 Miniature coaxial ClickLocconnector
standard cable
0 5 Multiple Approvals

3300 XL 11 mm Probe

3300 XL 11 mm Probe
M14 x 1.5 thread, witharmor
5 0 5.0 metres (16.4 feet)
0 2 Miniature coaxial ClickLocTMconnector
standard cable
0 0 Not required

3300 XL 8 mm Probe

3300 XL 8 mm Probe
3/8-24 UNF thread,without armor
1 0 1.0 metre (3.3 feet)
0 2 Miniature coaxial ClickLocTMconnector
standard cable
0 0 Not required

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread, witharmor
5 0 5.0 metres (16.4 feet)
0 2 Miniature coaxial ClickLocTMconnector,
standard cable
0 0 Not required

3300 XL 11 mm Proximity Probes

3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
5 0 5.0 metres (16.4 feet)
0 2 Miniature coaxial ClickLocTMconnector
standard cable
0 0 Not required
