PC Control

Intel Atom E3800 processors (Bay Trail)
Up to quad-core CPU performance
Powerful graphics (Intel HD graphics)
Compact dimensions
2x Gigabit Ethernet
SDL/DVI or SDL3
1x USB 3.0, 1x USB 2.0
1x CFast slot
 1x slot for interface options
Fanless operation

CONTROL UNIT

Processor:32-bit/64-bit microprocessor
Clock Speed: 500 MHz to 1 GHz
RAM: 512 MB – 2 GB
Flash Storage: 1–4 GB
Max I/O Points: Configurable up to 1,000+ points
Fieldbus: PROFIBUS DP
Standard: -25°C to +70°C (-13°F to +158°F)

Digital output module

SIMATIC ET 200SP
Digital output module
DQ 8x 24V DC/0,5A Basic
Sourceoutput (PNP,P-switching)
fits to BU-type A0, Colour CodeCC02
substitute value output
module diagnostics for: supply voltage

Analog Input Module

Input Type Current (2-wire or self-powered transmitters)
Input Channels 16 Channels (16 Single Ended)
Common Mode Rejection Ratio, dc to 60 Hz 70 dB
A/D Converter Resolution 16 bits
Input Range 4-20 mA (through 200 Ω)
Normal Mode Rejection Ratio, at 60 Hz 20 dB
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.0 Hz
Maximum Normal Mode Input ± 30 Volts

Interface board

Power Supply: 24 VDC (±10%) or 110–240 VAC
1–2 x RJ45 Ethernet ports.
Serial ports (RS-232/485) for legacy devices
Fiber-optic or coaxial connectors
Operating Temperature: -20°C to +60°C
Humidity: 5–95% non-condensing

3300 NSv Proximity Probes

3300 NSv Probe
3/8-24 UNF thread,without armor
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

Velomitor CT Transducer

1 0Plate Stud M6x1 to
M6x1with 3/8-in 24 adapter
Sensitivity:3.94 mV/mm/s (100 mV/in/s)±5%
Amplitude Linearity:±2% to 63.5 mm/s pk(2.5 in/s pk)
Dynamic OutputIm pedance:<400 Ω typical

Proximity Probe Housing Assemblies

A dome cover that screws into the body of the housingn
Threaded ports for conduit connectionsn
A probe sleeve of optional lengthn 0-ringsn
A reverse mount proximity proben
A thread sealn Optional conduit fittingsn
An optional standoff adapter

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Proximity Probes

3300 XL 11 mm Probe
1/2-20 UNFthread, with armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
15 1.5 meter (4.9 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Proximity Probes

3300 NSv Probe
M8X1 thread, witharmor
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 NSv Extension Cable

040 4.0 meters (13.1 feet)
05With stainless steel armor
without FEP jacket, withconnector protector
05 Multiple Approvals

Digital input module

Input Type:24V DC
Number of Channels:16 channels per module
Input Voltage Range:ON State: 15–35V DC
OFF State: 0–5V DC
Input Current: Typical: 3–7 mA
Update Rate: ≤ 10 ms
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)

MICROLOGIX 1200

MICROLOGIX 1200
24V DC POWER
(20) STANDARD 24V DC AND (4) FAST 24V DC DIGITAL INPUTS
(8) RELAY OUTPUTS
(7) STANDARD 24V DC FETOUTPUTS
(1) FAST 24V DC FET OUTPUT

S7-400 rack

SIMATIC PCS 7-400
UR2-H XTR S7-400 rack
central and distributed with 2 x 9 slots,
2 x 2 redundant PS can be plugged in
for extended temperature range
and with conformal coating

Control Circuit Board

30 NM Power Converter ACB AAA
Power Converter (30 NM ACB AAA
Input Voltage: Likely 480 VAC
Output Power: Estimated 30 kW
Efficiency: ≥95%
Voltage Levels: 5 VDC, 24 VDC
Operating Temperature:-20°C to +60°C
Humidity:5–95% RH (non-condensing)

Printed circuit board

Series: Mark VIe
Product type: Printed Circuit Board
COM Ports: 3; COM1, COM2, and micro-miniature 9-pin socket D connector
Ethernet Interfaces: 10BaseT/AUI connector
Manual: GEP-9145
Relative Humidity: 10-95%, non-condensing
Shock: maximum 10G, non-operating
Female Plug Connectors: 2
No.of Metal Oxide Varistors: 4
Power Supply Rating: 125 VDC

Printed circuit board

Power Supply:24 VDC
Signal Handling:4–20 mA, 0–10 VDC
digital signals:24 VDC logic
Resolution:16-bit ADC/DAC resolution
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Wind Turbine Board

Manufacturer:GE Energy
Series:Mark VIe Speedtronic
Part Number:IS200WEORG1A
Functional Acronym:WEOR
Functional Description:GE Printed Circuit Board
PCB Coating:Normal Coating

Printed circuit board

Power Supply: 24 VDC
analog inputs/outputs:4–20 mA, 0–10 VDC
Resolution:16-bit ADC/DAC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Printed circuit board

Manufacturer:GE Energy
Series:Mark VIe Wind
Part Number:IS210AEBIH3B
Functional Acronym:AEBI
Functional Description:Alternative Energy Bridge Interface
PCB Coating:Conformal Coating
AEBI:CARD GE WIND TURBINE
Input Voltage: 24V DC
Operating Temperature: Typically between -30°C to +65°C
Humidity: Typically 0-95% (non-condensing)

I/O EXPANSION BOARD

Power Supply:24 VDC
I/O Channels: 4–20 mA, ±10 VDC
Typical expansion capacity: 16–32 channels
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Input terminal board

Series: EX2100
Product Type: Alternative Energy Application D
Number of channels: 6
Input Span: 1-5 V dc
Outputs: 24 V outputs
Technology: Surface Mount
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C

Multiple Application Converter Control Board

Input Voltage:Typically 24 VDC
Signal Compatibility:
Analog: 4–20 mA, 0–10 VDC
Digital: 24 VDC logic
Analog resolution: 12-bit to 16-bit
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity
