General Electric

Digital Input Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: 3 W typical
Input Voltage: 24 VDC
Input Current: 10 mA
perating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Digital Input Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 3 W
Input Voltage: 24 VDC
Input Current: 10 mA
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Control Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Analog voltage: ±10 VDC
Current: 4–20 mA
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Control Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Input Types:Voltage: ±10 VDC
Input Types Current: 4–20 mA
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Signal Types Supported Voltage: ±10 VDC
Signal Types Supported Current: 4–20 mA
Accuracy: ±0.1% of full scale
Sampling Rate: 500 Hz per channel
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W

Analog Input Module

Input Channels: 16 Analog input channels
Voltage :0–10 VDC, ±10 VDC
Current: 4–20 mA
Sampling Rate: 500 Hz
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Input Channels: 16 Analog input channels
Voltage :0–10 VDC, ±10 VDC
Current: 4–20 mA
Sampling Rate: 500 Hz
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Input Channels: 12 Analog input channels
Signal Type:Voltage 0-10 VDC
Current :4-20 mA
Accuracy: ±0.1% of full scale
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically <6 W

Speed Protection Module

Nominal Operating Voltage: 125 VDC
Voltage Range: 85–250 VDC
Power Consumption: Typically <10W
Range: 0–100,000 RPM
Accuracy: ±0.1% of full scale
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Speed Protection Module

Operating Voltage:125 VDC
Voltage Range: 85–250 VDC
Power Consumption: typically <10W
Range: 0–100,000 RPM

Embedded Controller Module

Product Type: PAMC Acoustic Monitor (Processor)
Software: ControlST V04.03.18C
Relative humidity: 5% to 95%, no-condensing
Power Requirements +32 V dc to 18 V dc
Microprocessor: Freescale Power PC (Power QUICC II PRO 667 MHz)
Memory: 256 MB DDR SDRAMs

Power Supply Module

Product Type: Power Supply Module
Nominal Rated Voltage: 24 volts DC
Input Voltage Range: 18 to 32 VDC
Input Power: 160 watts at full load
Output power: 90 watts
Location on Baseplates: Leftmost slot
DC Output: +5VDC, +12 VDC, -12 VDC

CENTRAL PROCESSING UNIT

Module Type:Central Processing Unit
Number of Slots:1 (Single slot)
Battery-backed memory: 1 Mbyte
Number of Points:12K discrete inputs and outputs
Serial Ports:1 (RS422/485 compatible)
Current Required:3.3 Amps nominal

PROTECTION RELAY

369 Motor Management Relay
369 - Basic unit (no RTD)
HI-50-300 VDC / 60-265 VAC control power
R-Optional 12 RTD inputs (built-in)
M-Optional metering package
0-No optional Fiber Optic Port
E-Optional Modbus/TCP protocol interface
0-No Harsh environment option

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
64MHZ
32-BIT FLOATING
1MBYTE MEMORY
SERIES 90-70

POWER INTERFACE BOARD

24V DC
Operating Temperature Range:
-20°C to 60°C
Storage Temperature:
-40°C to 85°C
PIB100 G SLASTOM

Analog Input Terminal Board

4-20 mA current loops
0-5 V or 0-10 V DC voltage signals
Operating Temperature Range: -30°C to +65°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% RH, non-condensing

Turbine Protection Input Terminal Board

Series: Mark VIe
Simplex Primary Turbine Protection Input Terminal Board
Number of inputs: 4
Number of outputs: 2
MPU pulse rate range: 2 Hz to 20 kHz
Contact voltage sensing: 20 V dc
Technology: Surface mount
Temperature: -30 to +65C

Central Processing Unit

Part Number IC695CPE305
Form Factor Backplane
User Memory 6MB
I/O32k Bits Discrete I/O, 32k Words for Analog I/O
Energy PackIncluded
Redundancy SupportMedia Redundancy (MRP) with PNC001
Ethernet Port2 - 2 port switch 10/100/1000
Ethernet ProtocolsSRTP Client/Server,
Modbus TCP/IP, OPC UA , EGD, PROFINET,
DNP3 Outstation, IEC-61850 Client,
IEC-104 Server,HART passthrough

Part Number IC695ETM001
Specialty ModuleRX3i Ethernet module
10/100 Mbits 2 RJ45 connections one IP
address occupies one slot on system base
Current Consumption
840 mA @ 3.3 VDC; 614 mA @ 5 VDC
Operational NotesUniversal Backplane Only.
Uses PCI Bus. Client/Server

Turbine Emergency Trip Terminal Board

Mark VI
Triple Modular Redundancy (TMR)
Input Voltage Range: 24 VDC to 125 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Turbine Emergency Trip Terminal Board

3 independent trip solenoids
Solenoid voltage typically:
24 VDC to 125 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Protective Termination Board

Series: Mark VI
Input Voltage:  0-10 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Analog Processor Module

Series: Mark VI
Function: Analog Processor Module
Input Voltage: 125 V dc
Output Voltage: 24 V dc
Operating temperature: -30 to +65oC
Mounting: DIN-rail
Model Type: Safety I/O Pack

DC Power Supply

AC Input Voltage Range: 90-132V or 180-264V
Nominal Output DC Voltage: 24 VDC
Operating Temperature:
Typically 0°C to 50°C (32°F to 122°F)
Typically -20°C to 70°C (-4°F to 158°F)
