General Electric

Genius I/O module

IC660ELD021
ELECTRONIC ASSEMBLY FOR GENIUS I/O BLOCK
24/48 VDC SINK
8 CIRCUIT

Genius Network Interface module

Series:Genius I-O
Series:PC Interface Module (PCIM)
Part Number:IC660ELB912
Memory Requirement:16 Kbytes
Status LEDs:GENI OK, COMMS OK
Communication protocol:Genius Protocol
No. of supported devices:30 per daughtercard
Compatibility:IBM PC/ AT/ XT
LEDs indicators:GENI OK; COMMS OK

Genius I/O block

Series:Genius I-O
Part Number:IC660ELB905
Product Type:Network Adapter Interface Board
Block to Block Isolation:1500 V
Control Power:8 W
Frequency:47 to 63 Hz
Maximum Frequency Ripple:10 percent
Power Supply Dropout Time:1 Cycle
Humidity:5 to 95 percent (non-condensing)

ANALOG GENIUS I/O BLOCK

IC660ELA100
ELECTRONIC ASSEMBLY FOR GENIUS I/O BLOCK
FOR IC660CBA100
115 VAC
ANALOG GENIUS I/O BLOCK

Genius I/O block

Series:Genius I-O
Part Number:IC660EBS103
Product Line:Genius I/O
Block to Block Isolation:1500 V
Operating Temperature:0 to 60 degrees Celsius
Storage Temperature:-40 to 100 degrees Celsius
Frequency:47 to 63 Hz
Humidity:5 to 95 percent (non-condensing)
AC Power:Yes
DC Power:Yes

Genius I/O block

Series:Genius I-O
Part Number:IC660EBS102
Product Line:Genius I/O
Produt Type:Electronics Assembly
Nominal Voltage:115 V AC/125 V DC
Frequency:47 to 63 Hz
Required Control Power:8 W
DC Power:Yes
AC Power:Yes

Genius I/O block

Brand:GE Intelligent Platforms/GE Fanuc
Series:Genius I-O
Part Number:IC660EBS101
Product Type:Electronic Assembly
Block to Block Isolation:1500 V
Operating Temperature:0 to 60 degrees Celsius
Storage Temperature:-40 to 100 degrees Celsius
Frequency:47 to 63 Hz
Maximum Ripple:10 percent

Genius I/O block

Series:Genius I-O
Part Number:IC660EBR100
Product Type:Electronic Assembly
Frequency:47 to 63 Hz
Power Required:87 mA at 115 V AC
Power Supply Dropout time:1 cycle
Heat Dissipation:10.1 Watts with 16 Outputs
Min. Load Recommended:10 mA
Relay Type:Fixed Coil moving armature

Genius Block I/O module

Series:Genius I-O
Part Number:IC660EBD120
Series:Block I/O
Product Type:Electronics Assembly
Storage Temperature:-40 to 100 degrees Celsius
Nominal input voltage:115 VAC
Non-Condensing Humidity:5 to 95 percent
Input voltage range:93-132 VAC
Frequency:47 to 63 Hz
No. of discrete inputs:Twelve (12)
No. of discrete outputs:Four (4)
LED block:I/O Enabled, Unit OK
Circuit Overcurrent Threshold:4 Amps

Genius Block I/O module

Series:Genius I-O
Part Number:IC660EBD110
Series:Block I/O
Product Line:Genius I/O
Product Type:Electronic Assembly
Nominal input voltage:115 VAC
Input to Ground Isolation:1500 V
Input voltage range:93-132 VAC
Input Current:5 A
No. of discrete inputs:Sixteen (16)
Frequency:47-63 Hz

Genius Block I/O module

Series:Genius I-O
Part Number:IC660EBD101
Series:Block I/O
Brand:GE Intelligent Platforms/GE Fanuc
Product Line:Genius I/O
Product Type:Electronics Assembly
Block to Block Isolation:1500 V
No. of channels:Eight (8)
Input current:6 mA
Output current:2 Amperes
Standby Power:8.5 W
Nominal Operating voltage:115 VAC
Operating Voltage:93 to 132 V AC
Frequency:47 to 63 Hertz
Humidity:5-95% non-condensing

Electronic Assembly

Series:Genius I-O
Part Number:IC660EBD100
Product Line:Genius I/O
Product Type:Electronics Assembly
Standby Power:8.5 Watts
Operating Voltage:93 to 132 V AC
Frequency:47 to 63 Hz
Block to Block Isolation:1500 V
Heat Dissipation:16 W with 8 inputs
Operating Temperature:0 to 60 degrees Celsius

Electronics assembly block

Series:Genius I-O
Part Number:IC660EBD025
Product Line:Genius I/O
Product Type:Electronics Assembly
Circuits:2, 32-circuit
Block to Block Isolation:850 V
Block Output Current:16 Amps
Max. Output turn-on delay:0.5 microseconds
Operating Temperature:0 to 60 degress Celsius
Output Diagnostic:Switch Fault
Storage Temperature:-40 to 100 degrees Celsius
Non-Condensing Humidity:5 to 95 percent

Genius I/O Electronics Assembly

Series:Genius I-O
Part Number:IC660EBD024
Product Line:Genius I/O
Block to Block Isolation:850 V
Min. Heat Dissipation:11 Watts with 8 inputs
Storage Temperature:-40 to 100 degrees Celsius
Non-Condensing Humidity:5 to 95 percent
Max. Output Current:0.5 A per circuit
Output Diagnostics:Switch Fault
Required DC Power:150 mA (typical)
Max. Required DC Power:300 mA

Genius Block I/O module

IC660EBD023
ELECTRONIC ASSEMBLY FOR GENIUS I/O BLOCK
FOR IC660BBD023
24 VDC
SINK I/O
16 CIRCUIT

Genius Block I/O module

IC660EBD022
ELECTRONIC ASSEMBLY FOR GENIUS I/O BLOCK
FOR IC660BBD022
24 VDC
SOURCE I/O
16 CIRCUIT

Genius Block I/O module

Series:Genius I-O
Manufacturer:GE Fanuc / Emerson Automation
Part Number:IC660EBD021
Series:Block I/O
Product Type:Electronic Assembly
Ripple:10%
Nominal input voltage:24 VDC / 48 VDC
Required DC Power:300 mA (Max)
Input voltage range:18-56 VDC
No. of configurable Discrete inputs:Sixteen (16)
Block to Block Isolation:1500 V
Circuit LEDs:Individual load side indicators
Power Supply Dropout Time:10 microseconds
Output Off-State Leakage Current:1.0 mA

Genius Block I/O module

Series:Genius I-O
Part Number:IC660EBD020
Series:Block I/O
Type:Electronic Assembly
Main Equipment:Analog output block
Product Description:Electronics Assembly
Power Supply Voltage:18-56V DC
Nominal input voltage:24 VDC
Heat Dissipation:68.8 Watts
Input voltage range:18-56 VDC
Block to Block Isolation:1500 V
No. of discrete inputs:Sixteen (16)
Thermal Drift:70 PPM per degrees Celsius

Genius I-O input block

Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660EBA106
Type:Electronic Assembly
Main equipment:Analog output block
Frequency:47-63 Hz
Ripple:10% max.
Accuracy:0.15% full scale reading at 25 °C
Thermal drift:70 PPM per degrees Celsius
Diagnostics:Yes
Operating temperature:0-60 degrees Celsius

Genius Block I/O module

Series:Genius I-O
Part Number:IC660EBA105
Series:Block I/O
Type:Electronic Assembly
Main equipment:Analog output block
Product Description:Electronics Assembly
Power supply voltage:93-132V AC and 105-145V DC
Maximum current:250 mA (AC) and 140 mA (dc)
Compatible Terminal base:IC660TBA105
Frequency:47-63 Hz
Ripple:10% max.
Block to Block isolation:1500 V for 1 minute
Thermal drift:35 PPM per degrees Celsius
Group to group isolation:N/A

Electronic Assembly

Series:Genius I-O
Part Number:IC660EBA104
Series:Block I/O
Type:Electronic Assembly
Main equipment:Analog output block
Product Description:Electronics Assembly
Maximum current:250 mA (AC) and 140 mA (dc)
Compatible Terminal base:IC660TBA104
Frequency:47-63 Hz
Ripple:10% max.
Block to Block isolation:1500 V for 1 minute
Heat dissipation:12 Watts max.
Group to group isolation:300V rms
Thermal drift:70 PPM per degree Celsius
Operating temperatura:0-60 degrees Celsius

ELECTRONIC ASSEMBLY FOR GENIUS I/O BLOCK

Series:Genius I-O
Part Number:IC660EBA103
Series:Genius I/O
Series:Block I/O
Type:Electronics Assembly
Product Description:Electronics Assembly
Power supply voltage AC:93-132V AC
Power supply voltage DC:105-145V DC
Group to group isolation:300V rms
Heat dissipation:9 Watts maximum
Operating voltage:115 VAC / 125 VDC
Frequency:47-63 Hertz
LEDs (I/O Block):Unit OK, I/O Enabled

Electronics Assembly

Series:Genius I-O
Part Number:IC660EBA101
Series:Genius I/O
Series:Block I/O
Type:Electronics Assembly
Main equipment:I/O Block
Input:6 inputs divided into 3 isolated groups
LEDs:1 unit LED and 1 input LED
Power Supply, AC:93-132V AC
Operating voltage:15 VAC / 125 VDC
Group to group isolation:1500 V rms
Power Supply, DC:105-145V DC
Communication protocol:Genius Protocol
Operating Temperature:0 Degree to 60 Degree Celsius
Heat Dissipation:7 Watts
Block to Block Isolation:1500 V for 1 minute
Input update frequency:400, 800, or 1600 ms

Electronic Assembly

Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660EBA100
Type:Electronic Assembly
Main equipment:Analog I/O block
Maximum power:10 VA
Frequency:47-63 Hertz
Resolution:12 bit plus sign
Update frequency:4 ms
Diagnostics:Yes
Heat Dissipation:6 Watts

Electronic Assembly

Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660EBA026
Type:Electronic Assembly
Main equipment:Analog output block
Power supply voltage:18-56V DC
Maximum current:600 mA
Ripple:10% max.
Resolution:6 uA
Update frequency:25 ms
Diagnostics:Yes
