General Electric

Cable I/O non-shielded 2 connectors .5M for connector-style carrier

48VDC Input, Neg/Pos Logic, 1 msec filter, Neg/Pos Logic (16 points)

Profibus DP Slave Module

Analog Output Module, 8 channels,that is configurable for voltage and current, configured for Current: 0 to 20mA, 4 to 20mA; Voltage: +/- 10 VDC, 0 to 10VDC per channel non isolated. Up to 16 bit resolution. Requires high capacity terminal block IC694T

Analog Input module

Storage Temperature:-40 to 185 degrees Fahrenheit
Overvoltage:±60 VDC continuous, maximum
Humidity:5 to 95%, non-condensing
Overcurrent:±28mA continuous, maximum
Open Circuit Detection time:1 second maximum
Input Impedance:>100 k voltage inputs
Current Input Resistance:249  ±1%

Serial Communications Module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695CMM004
Product Type:Communications module
No of ports:Two (2) RS232 / RS422 / RS485
Serial Ports:4
Physical Interface:RJ-45
Connectors:RJ45
Supported Configurations:RS-232, RS-422/485
No. of installations per rack:Up to Six (6) modules
Baud Rates:1200 baud to 115.2 kilobaud
Status LED indicators:Module OK, Port Fault, Port Status
Current rating:0.7 mA at 3.3 VDC, 0.150 mA at 5 VDC
Operating Temperature:0 to 60 degrees Celsius
Parity:Even, odd, none
Data bits:7, 8
Stop bits:1, 2

Accessory module

Brand:GE Fanuc
Series:RX3i PacSystem
Part Number:IC695ACC412
Description:Cap Pack
Compatibility:RX3i

Input module 24 VDC 16 point POS/NEG logic.

CABLE

Series:RX3i PacSystem
Part Number:IC695CBL001
Compatibility:PACSystems RX3i
Cable Type:Energy pack cable
Type of Input/Output:Analog
Termination Resistor:Yes

Output Module

Brand:GE Intelligent Platforms/GE Fanuc
Series:Series 90-70
Part Number:IC697MDL340
Product Type:Output Module
Rated Voltage:120 V AC
Outputs:16
DC Power:No
AC Power:Yes
LED Indicators:Yes

INPUT MODULE

IC600BF841
DISCONTINUED BY MANUFACTURER
INPUT MODULE
SERIES SIX
4POINT
ANALOG
0-10VDC

Universal analog input module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695ALG600
Module Type:Universal Analog
No of Channels:Eight (8)
Number of Inputs:8 general purpose
No. of groups:Two (2)
Cold Junction Compensation:2 channels
No. of channels per group:Four (4)
Power Dissapation:5.4W max
Humidity:5 to 95%, non-condensing
Module conversion method:Sigma-delta
Module resolution:11-16 Bits
Internal Power:3.3V: 350mA; 5V: 400 mA

printed circuit board

Input Voltage: 24V DC
Operating Temperature: Typically between -30°C to +65°C
Humidity: Typically 0-95% (non-condensing)
