General Electric

Embedded Single Board

Up to 512MB PC100 SDRAM
(PC133 stepped down to 100 MHz)
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

CONTROL COMMUNICATION GATEWAY

Input Voltage: 24 VDC nominal
Power Consumption: ≤ 15 W
Ethernet Ports: Dual 10/100 Mbps
Operating Temperature: -30°C to +70°C (-22°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5% to 95% non-condensing
Data Transfer Rate: Up to 100 Mbps

SPINDLE DRIVE BOARD

POWER CONNECTION MODULE
DC300 SPINDLE DRIVE BOARD
CNC
Input/Output: typically 0-10V, 4-20mA
Operating Temperature Range: Typically -40°C to +70°C
Power Input: Receives AC or DC

MICRO ANALOG BOARD

Input/Output:
typically 0-10V, 4-20mA
Operating Temperature Range:
Typically -40°C to +70°C
Function:
Processes and converts analog signals

Digital I/O Module

Nominal Voltage Options:
24 VDC, 48 VDC, 125 VDC, or 250 VDC.
Input Voltage Range: ±20% of nominal value
Logic 0 (Low): 0-3 V
Logic 1 (High): 15-250 V
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

CONTROL COMMUNICATION GATEWAY

Power Supply: Typically 24V DC
Operating Temperature Range: Typically -40°C to +85°C
Storage Temperature Range: -40°C to +85°C.
Humidity: humidity up to 95% (non-condensing).

Process Interface Board

Voltage Rating:24V DC
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: From -20°C to +70°C
Humidity: humidity up to 95% (non-condensing).
Overcurrent Protection: Yes
Overvoltage Protection: Yes
Short-Circuit Protection: Yes
Ingress Protection: Typically rated IP20 or higher,
depending on the enclosure and environmental requirements.

Control Card

Voltage Rating:24V DC
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: From -20°C to +70°C
Overcurrent Protection: Yes
Overvoltage Protection: Yes
Short-Circuit Protection: Yes
Ingress Protection: Typically rated IP20 or higher,
depending on the enclosure and environmental requirements.

TB Option Card

the DC-300 drive
Operating Voltage  24V DC
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: -20°C to +70°C

Hand-Held Monitor

Hand-held monitor
Hardware configuration
fault clearing
I/O forcing and bus selection.
0-60 Degree Celsius (32-140 Degree Fahrenheit)
-40 to 70 Degree Celsius (-40 to 158 Degree Celsius)
Product Description Hand-held monitor
115 to 230V AC, 47 to 63 Hz
Fully Charged Operation 6 hours
4 lines of 16 characters each
20 sealed keys
English, German, French/Italian

CMOS MEMORY BOARD

PC BOARD ASSEMBLY
CMOS MEMORY BOARD
Memory Capacity: 128KB to 1MB
Operating Voltage:operates on +5V DC
Operating Temperature: 0°C to +60°C
Storage Temperature: Typically -40°C to +85°C.
Humidity: Generally 5% to 95% non-condensing

Terminal Board Relay Card

MCF/ POWER SUPPLY CARD
SPEEDTRONIC / MARK V
MOTOR FIELD CONTROL

Contactor

Contactor Includes
CR353XAAB
KIT 90Amp 240/480/600V

Discrete input module

Input voltage 0 to +30VDC,+24VDC nominal
On state voltage +15 to +30VDC
Off state voltage 0 to +5VDC
Off state current 2.0 to 5.5mA0 to 0.5mA
Off response time 0.5ms maximum
Configurable filtertime0 ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum

Extended Analog I/O board

Series Speedtronic Mark V
Part Number DS200TCQBG1B
Functional Description RST Extended Analog I/O Board
Functional Acronym TCQB
Used With TCQA Boards

Extended Analog I/O Board

Series: Mark V
Product Type: Analog I/O Board
Proximitor Inputs
LVDT/LVDR Inputs
Two Regulator Milliamp Outputs
LM Vibration Inputs

LAN Communication Card

Data Transfer Rate: Up to 2.5 Mbps
Dimensions: Standard 6U card size for easy installation
in GE control system racks.
Power Requirements:
Logic Power: +5V DC.
Auxiliary Power: 3.3V DC or as specified by the system.
Power Consumption: <10W (typical).
Connector: Multi-pin slot connectors compatible

RST Analog Termination Board

I/O BOARD ANALOG
MARK 5
TURBINE CONTROL
MULTI INPUT/ OUTPUT
ON BOARD RAM

Normally Closed Relay Output Block

Series Genius I-O
Part Number IC660BBR100
Product Type Relay Output Block
Output Block Type Normally Closed
Number of Outputs 16
Output Configuration 4 Groups of 4 Outputs Each
Output Voltage Type AC or DC
Power Requirements 87 Milliamps at 115 Volts AC

Normally Closed Relay Output Block

Series Genius I-O
Part Number IC660BBR100
Product Type Relay Output Block
Output Block Type Normally Closed
Number of Outputs 16
Output Configuration 4 Groups of 4 Outputs Each
Output Voltage Type AC or DC
Power Requirements 87 Milliamps at 115 Volts AC

Multifunctional Serial Input/Output Board

A16:D8
Four Full-Duplex Channels
Fully Programmable Synchronous
Asynchronous Operation
RS-232C, RS-423, RS-422A,
and RS-485 Compatible
0 to 1 Mbaud Data Rate
Self-Test Capability
Programmable Interrupt Capability
Modem Control Lines for Each Channel
Uses Four Industry-Standard 25-Pin Subminiature D Connectors
Double Eurocard Form Factor
Four Programmable Baud Rate Generators

Analog I/O Board

(8) Sample-and-Hold
Analog Input Channels
12-Bit A/D Converter
PGA Provides Program-Controlled
Gains of x1, x2, x4, x8 and x16
125 kHz Maximum Scan Rate (Gain = x1)
Dual 128 KB Data Buffers for Analog Inputs / Outputs
Analog Function Generation

5-slot baseplate

Series 90-30
CPU Baseplate
25-Pine D-Type Female Connector
Option modules: Slot 2-5
Unnumbered slot: Power supply module
Expansion cable: Expansion cable

Genius Bus Controller

Series 90-30
<300mA at +5V DC
2 (OK and COMM OK)

Safety Controller Board

UCSB CONTROLLER MODULE
256 MB DDR2 SDRAM
600 MHZ INTEL EP8059
28 VDC
