ROTARY ENCODER

ROTARY ENCODER
10-30 VDC
HTL
M8 THREADED SHAFT
12-PIN M16 CONNECTOR
1024 PPR
IP64

ANALOG INPUT MODULE

INPUT MODULE
ANALOG
SIMATIC S5
FOR S5-90U/-95U/-100U
ET 100U
ET 200U
4 INPUTS
0-10 V

ECT SIGNAL ISOLATER

ECT420MA2X420MA24DCTXDIN
ECT SIGNAL ISOLATER
CONVERTER
SPLITTER
INPUT
4 - 20MA
OUTPUT
2X4 - 20MA
24 VDC
4 WIRE
DIN RAIL MOUNTING
SCREW TERMINALS

SITRANS P320 Pressure Transmitter

SITRANS P320 Pressure Transmitter
Gauge pressure HART (4...20 mA)
 63 bar (914 psi)
Silicone oil
Female thread 1/2-14 NPT

Comfort HMI Panel

SIMATIC Series KP1500
Comfort HMI Panel
15.4 in
TFT Display
1280 x 800pixels

Backup battery

SIMATIC S7
Backup battery (LI) 3.6 V/min.
0.85 Ah
for S7-300
CPUs and S5-90U

CP5611-A2 MPI/Profibus PC Card PCI

Smart Electropneumatic Positioner

Terminal Module

PC BOARD

C98043A7044L16
PC BOARD
6RY1703-0CM02

Single Motor Module

INTERFACE MODULE

TELEPERM XP INTERFACE MODULE IM308C
INTERFACE MODULE LOCATED IN THE AP OR EG FOR
THE CONNECTION BETWEEN AP AND ET200 /
INTELLIGENT FIELD DEVICES,
FOR THE SUPPORT OF
THE CENTRALIZED ENGINEERING OF
THE INTELLIGENT FIELD DEVICES

SENSOR CONDITIONING

TELEPERM XP MODULE FUM 210
FOR SENSOR CONDITIONING FAST BINARY SIGNAL ACQUISITION,
OR DRIVE CONTROL SENSOR, MONITORING AND SIGNAL.
MODULE CONDITIONING:
14 CHANGEOVER OR 28 SINGLE CONTACTS
WITH SENSOR SUPPLY AND MONITORING,
28 BINARY INPUTS WITHOUT SENSOR SUPPLY

BINARY SIGNAL COUPLING MODULE

TELEPERM XP MODULE FUM 211,
BINARY SIGNAL COUPLING MODULE
16 BINARY INPUTS
WITE ELECTRICAL ISOLATION
VIA OCTOCOUPLERS 16 BINARY
OUTPUTS 250 MA (WITH LIMITATION)
STEADY OR FLASHING (8, 2, 0,5 HZ)
SUITABLE TO CONNECT CONSOLE CONTROL TILES.
CAPABLE FOR 2 DESK TILES USE IN SPPA-T200

SENSOR CONDITIONING

TELEPERM XP MODULE FUM 210
SENSOR CONDITIONING FAST BINARY SIGNAL ACQUISITION,
OR DRIVE CONTROL SENSOR,
MONITORING AND SIGNAL. MODULE CONDITIONING:
14 CHANGEOVER OR 28 SINGLE CONTACTS
WITH SENSOR SUPPLY AND MONITORING,
28 BINARY INPUTS WITHOUT SENSOR SUPPLY

DP/AS-i Link Advanced

SIMATIC NET,
DP/AS-INTERFACE LINK ADVANCED;
GATEWAY PROFIBUS
DP/AS-INTERFACE WITH MASTER PROFILE M3, M4 ACC.
TO EXTENDED AS-I SPEC.
V3.0 FOR INTEGRATION IN PROFIBUS DP;
DOUBLE MASTER WITH DISPLAY;
DEGREE OF PROTECTION IP20.

logic module

230RCE,logic module
Display PS/I/O: 115V/230V/relay
8 DI/4 DO, memory
230 V AC/DC
400 blocks, modular expandable

LCD Screen Display Panel

TFT-LCD
200-600 cd/m²
Usually between 0°C and 50°C
Typically between -20°C and 60°C

MASTER MODULE

E3X102
MASTER MODULE
1MB RAM

I/O MODULE

E3L020
INPUT/OUT MODULE
16-WAY
16 X 24 VDC
40 MA INPUTS OR OUTPUTS. EACH WAY FREELY PROGRAMMABLE
CAN BE USED IN CONJUNCTION WITH Z3B171 TO PROVIDE 250 VAC / 10 A CONTROL OUTPUTS

INTERACTIVE LINE MODULE

E3M071
ALGOREX INTERACTIVE LINE MODULE

C-BUS GATEWAY PCB CARD

E3H020
C-BUS GATEWAY RS232 INTERFACE 9-30VDC 100MA

Power Supply Module

24 VDC
150 W
SIMATIC PC
Power supply

Repeater Module

SIMATIC DP, RS485 REPEATER FOR THE CONNECTION OF PROFIBUS/MPI BUS SYSTEMS WITH MAX. 31 NODES; MAX. 12 MBIT/S, DEGREE OF PRO- TECTION IP20

Profibus Connector

6ES79720BB500XA0
SIMATIC DP BUS CONNECTOR
FOR PROFIBUS UP TO 12MBIT/S
90DEGREE ANGLE CABLE OUTLET
15.8X72.2X36.4MM
IPCD TECHOLOGY FAST CONNECT
W/PG SOCKET
