Converter Driver Board +IGBT Silicon Module
Collector-Emitter Voltage :1200 V
Nominal Collector Current:300 A
Reverse Voltage:1200 V
Forward Current :300 A
Gate Drive Power: +15 V / -8 V
Excitation board
Input Voltage Range:380–480 V AC
Output Voltage (DC):50–250 V DC
Continuous Excitation Current: 10–20 A DC
Analog Input: Accepts ±10 V or 4–20 mA
Internal Logic Supply: Isolated 24 V DC
Temperature: 0°C to +60°C operation (-25°C storage)
Humidity: ≤96% non-condensing
DRIVE MAIN BOARD
Control Circuit: +24 V DC ±15%
Sensor Integration: 0–10 V/4–20 mA
Standard: 0°C to +55°C
Isolation Voltage: ≥ 2.3 kV
Condensation Avoidance: Operates at ≤95% humidity
DRIVE MAIN BOARD
Control Voltage: +24 V DC (±10%)
Power Handling:75–150 kW
Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
Humidity: Up to 95%
LINE MODULE
SINAMICS / SIMODRIVE 611 BASIC
LINE FILTER FOR 55KW ACTIVE
LINE MODULE INPUT: 3AC 380-480V
50/60HZ
CONTROL MODULE
CONTROL MODULE
CLOSED-LOOP / OPEN-LOOP
CUPM
MOTION CONTROL PERFORMANCE 2
FOR SIMOVERT MASTERDRIVES
Power Interface Board
6RY18030-DA02
Power Interface Board
Input Voltage:+24 V DC
Optional Input Ranges: 10~30 V DC
Continuous (Logic/Control): 1–3 A
Rush (Reley Outputs): 5–10 A
Operating Temperature: 0°C to +55°C
Allocation board
Allocation board
C98043-A7126-L1
Control Circuit: 24 V DC ±10%
Communication: +15 V DC/-15 V DC
Screw-terminals for ≤1.5–2.5 mm² wires
Temperature: 0°C to +55°C (derating at >+40°C).
Humidity: ≤90% non-condensing
POWER INTERFACE BOARD
POWER INTERFACE BOARD
Terminals C98043-A7105-L1
SCREW CLAMP TERMINALS
W/ FUNCTIONAL SAFETY
REPLACES 6RY1803-0DA01
Power interface board
power interface
C98043-A7003-L1 incl
painted terminals
Power Side:240-690 V AC
Control Voltage: 24 V DC
Terminal Current Rating: 5–20 A
Thermal Compliance:500–600 W
Excitation board
Excitation board
power unit 15 A 4Q
C98043-A7111-L1
Continuous Output Current: 15 A
Output: 160–400 V DC
Input: Logic supply 24 V DC ±10%
Isolation: ≥2500 V AC
Temperature: 0–55°C (non-condensing)
Relative Humidity: ≤95%
Power Interface Board
AC: 120–480 V AC
DC Voltage Input: 24 V DC ±15%
Relay Outputs:10 A @ 250 V AC
Current Handling: Up to 100 A
Isolation Voltage: Up to 2.5 kV
Secondary Voltage: 12 V/24 V DC
POWER INTERFACE BOARD
POWER INTERFACE BOARD
RELAY OUTPUTS
WITH ON-BOARD TRANSFORMERS
Signal Interface:24 V DC
Number of Relays:8 to 16 channels
AC Load: 240 V AC @ 8–10 A
DC Load: 24–48 V DC @ 5-8 A
6RY1703-0GA01
PC BOARD
BACK PANEL
REAR
6RY1703-0GA01
Contact Rating: 5‒10 A @ 24–230 V AC/DC
Isolation Class:24 V AC/DC isolation
Control Side: 24 V DC
Power Circuit: Up to 690 V AC three-phase
POWER INTERFACE BOARD
POWER INTERFACE BOARD
RELAY OUTPUTS
WITH ON-BOARD TRANSFORMERS
Contact Configuration:Typically SPDT or DPDT relays
Maximum Switching Voltage:250 V AC/DC
Current Rating:5–15 A per relay
Purpose:24 V AC/DC to lower voltage
Control Input(s): 24 V DC
FIELD POWER SUPPLY PC BOARD
PC BOARD ASSEMBLY
FIELD POWER SUPPLY PC BOARD
Nominal Input: 110-240 V AC
Frequency: 47-63 Hz
Voltage Output: Likely 24 V DC
Operating Temperature: Range of 0°C to +60°C
Humidity Tolerance: ≤95%, non-condensing
Inverter snubber Module
AC/DC DRIVE
SIMOVERT MASTERDRIVES
675-810 V DC INPUT
500-600 V AC OUTPUT
3 PH
31.7 KW
1200 AMP
IP00
RATING - 1700 KW
SC646-2C Industrial Security Appliance
SCALANCE SC646-2C
Industrial Security Appliance
For protection of devices and networks
manufacturing and the process industry
for protection of the industrial communication with
firewall and VPN
address conversion (NAT/NAPT)
Connection to SINEMA RC
4x ports electrical 10/100/1000 Mbit/s RJ45 and
2x combo port electrical or optical
10/100/1000 Mbit/s RJ45
100 Mbit/s SFP or 1000 Mbit/s SFP
