OPERATOR PANEL
OPERATOR PANEL
PMU
PARAMETER ASSIGNMENT UNIT
FOR DESIGNS A / B
SIMOVERT MASTERDRIVES
Current Transformer
Symmetry resistance
3x 2K7 Ohm 190W 5%
Power:1kV
Primary Current:15 A
Accuracy Class:1 or 3
Voltage:400-440 V
Phase:Three Phase
CU240B-2DP Control Unit
SINAMICS G120
Control Unit CU240B-2
DP B type PROFIBUS DP 4 DI
1 DQ, 1 AI, 1 AQ PTC/KTY/thermoclick
interface USB and SD/MMC
interface degree of protection IP20
ambient temperature 0 to +50 °C
without Power Module
GATE/POWER MODULE BOARD
GATE/POWER MODULE BOARD
SIMOREG DRIVES
POWER-INTERFACE
GATING + SV(POWER-INTERFACE)
(C98043-A1601-L1)
Machinery Control
Series:MM430
Input Voltage:380–480V AC ±10%
Input Frequency:50/60Hz ±5%
Output Power:7.5 kW
C751-009 I/O Module
Digital Inputs (DI) : 8 × 24V DC
Digital Outputs:4 × Relay Outputs
AC capacity:≤250V
Operating Voltage DC:+24 VDC +10%
Power Consumption:≤5W
Storage Temperature:-10˚C- +60˚C
Rectifier interfaces Module
Rectifier interfaces Module
PER2 for infeed/regenerative
feedback Supply units
with Designs H and K 3 AC 500-575V
50/60 Hz and 660-690V 3AC
50/60 Hz
INVERTER CPU BOARD
Processor: Infineon C167xx-series
Flash EPROM: ≥1 MB
SRAM: 128‒512 KB data cache
EEPROM: 8‒16 KB
On-Board Power: +5VDC ±1%
Temperature operating:-15˚C to +70˚C
Replacement IPD card
SINAMICS S120
Replacement IPD card
for air-cooled Basic Line Module
1100kW 500-690V 3AC/1400A
Synchronous servo motor
SIMOTICS S synchronous servo motor
1FK7 Compact 6.0 Nm, 100K, 4500 rpm 1.74 kW
naturally cooled IM B5 (IM V1, IM V3)
power/signal connector plug rotatable by 270°
ABSOLUTE ENCODER 2048 P/REV (ENCODER A-2048)
WITH DRIVE-CLIQ INTERFACE
PERFORMANCE REDUCTION BY 10% DUE TO
ABSOLUTE ENCODER
PLAIN SHAFT, TOLERANCE N
WITH HOLDING BRAKE DEGREE
OF PROTECTION IP64
IGBT Silicon Module
Insulation Class：2500 V
Collector (DC Link) Voltage:1200 V
Emitter Voltage:1200 V
Collector Peak:≤1800 A
Isolation (DC Link):≥5.0 kV RMS
Short Circuit Peak Current Limit:≤1.8kA
Replacement IPD card
SINAMICS S120
Replacement IPD card
for air-cooled Motor Module
500-690V
450kW
Replacement IPD card
SINAMICS S150
Replacement IPD card
for air-cooled Motor Module
basic unit 380-480V
110kW
Replacement IPD card
SINAMICS S120
Replacement IPD card
for air-cooled Motor Module
500-690V, 710kW
Synchronous servo motor
SIMOTICS S synchronous servo motor
1FK7 Compact 11 Nm
100K 3000 rpm
2.29 kW naturally cooled IM B5 (IM V1, IM V3)
power/signal connector plug rotatable by 270°
ABSOLUTE ENCODER 2048 P/REV (ENCODER A-2048)
WITH DRIVE-CLIQ INTERFACE
PERFORMANCE REDUCTION
BY 10% DUE TO ABSOLUTE ENCODER
PLAIN SHAFT, TOLERANCE N
WITH HOLDING BRAKE DEGREE
OF PROTECTION IP64
Replacement IPD card
SINAMICS S120
Replacement IPD card
for air-cooled Basic Line Module
560kW 500-690V
3AC/680A
Replacement IPD card
SINAMICS S120
Replacement IPD card
for air-cooled Basic Line Module
560kW 500-690V
3AC/680A
HR 2-AXIS CONTROL-LOOP BLOCK
SIMODRIVE 611 UNIVERSAL
HR 2-AXIS CONTROL-LOOP BLOCK
INCREMENTAL ENCODER SIN/COS 1 VPP
ABSOLUTE VALUE ENCODER ENDAT
SPEED/TORQUE SETPOINT POSITIONING
EXPANDABLE BY OPTIONS
G120 Standard Control Unit
SINAMICS G120 CONTROL UNIT
CU240E-2 E-TYPE SAFETY INTEGRATED
STO RS485-INTERFACE
USS-PROTOCOL 6DI, 3DO, 2AI, 2AO
MAX 1F-DI PTC/KTY INTERFACE
USB- AND SD/MMC-INTERFACE
PROTECTION IP20
AMBIENT TEMP 0 TO +50 DEG C
WITHOUT POWER MODULE AND PANEL
Driver Board
HV-IGBT modules: 1900A
Input Voltage Range:+24V DC
Isolation Voltage:min. 4000 V RMS
IGBT Voltage Monitoring:±5%
Gate Drivers Per Phase:2 channels
IGBT-TRANSISTOR MODULE
IGBT-TRANSISTOR MODULE
PRECHARGING RESISTOR 2 X 18 OHM
Voltage: 1500 V
DC Collector Current:160 A
Rated Pulse Current:320 A
Operating Junction Temperature:-40°C to +150°C
Current Transformer
CURRENT TRANSFORMER
2000 AMP
15-24VDC
AC Input Range: 0–2000 A AC
Overload Capacity: 130% of Ipn for 10 sec
DC Voltage or Current:4–20 mA (Two-Wire Loop)
Input Voltage: 15–24 V DC ±10%
Power Consumption: <2 W
