Server motherboard

Slots: 4x DDR4 DIMM slots
Capacity: Up to 128 GB ECC RAM
Operating Temperature: 0°C to +60°C (32°F to +140°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 10–90% (non-condensing)
Vibration Resistance: 5–500 Hz
Ethernet Ports: 4x 10/100/1000 Mbps (RJ45)
with optional 1 Gbps/10 Gbps SFP+ fiber ports
Protocols: PROFINET, EtherNet/IP, OPC UA, Modbus TCP

Signal concentrator board

Voltage: 24 V DC (±10%)
Power Consumption: ≤6 W
Input Channels: 32 channels
Digital Inputs: 24 V DCc
Analog Inputs: 4–20 mA, 0–10 V, RTD
Channel-to-Channel: 250 V AC
Field-to-System: 1500 V AC reinforced isolation
Ethernet Port: 10/100 Mbps (RJ45) for integration with PLC networks
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)

Control board

Voltage: 24 V DC (±10%)
Power Consumption: ≤10 W
Processor: 32-bit ARM Cortex-R5F
Clock Speed: 500 MHz
Channels: 32 channels
Voltage: 24 V DC
Field-to-System: 1500 V AC reinforced isolation
Channel-to-Channel: 250 V AC
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5–95% (non-condensing)
Vibration Resistance: 5–100 Hz

Control Board

Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
RAM: 1–2 GB DDR3
Storage: 4–8 GB Flash
Video Input: VGA/HDMI for external display connectivity.
USB Ports: 2x USB 2.0/3.0 for peripherals

VDU Board

Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
RAM: 1–2 GB DDR3
Storage: 4–8 GB Flash
Video Input: VGA/HDMI for external display connectivity.
USB Ports: 2x USB 2.0/3.0 for peripherals (e.g., keyboard, mouse).
Ethernet: 10/100/1000 Mbps (RJ45) for network integration

Channel Control Unit

Voltage: 24 V DC (±10%)
Power Consumption: ≤4 W
Digital: 24 V DC (sink/source).
Analog: 4–20 mA, 0–10 V
Analog inputs: ±0.05% of full scale (at 25°C).
Digital response time: ≤1 ms
Overvoltage Protection: ±30 V

Channel Control Unit

Voltage: 24 V DC (±10%)
Power Consumption: ≤4 W
Digital: 24 V DC (sink/source).
Analog: 4–20 mA, 0–10 V
Analog inputs: ±0.05% of full scale (at 25°C).
Digital response time: ≤1 ms
Overvoltage Protection: ±30 V
Removable screw terminals (0.2–2.5 mm² / AWG 24–12)

CONNECTION UNIT

Model: PFSK108
Part Number: YM322001-EH
Voltage: 24 V DC
Wire Gauge Support: 0.2–2.5 mm²
Max Current: 10 A
Digital I/O (24 V DC).
Analog signals (0–10 V, 4–20 mA).

Analog Input Module

Model: PFSK110
Part Number: YM322001-EP
Voltage: 24 V DC (±10%)
Power Consumption: ≤3 W
Voltage: 0–10 V, ±10 V
Current: 0–20 mA, 4–20 mA
Accuracy: ±0.1% of full scale (25°C)
Sampling Rate: 100 samples/sec per channel
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5–95% (non-condensing)
Vibration Resistance: 5–100 Hz

Signal Processing Control PLC Circuit Board

Model Number: PFSK106
Part Number: YM322001-EC
Voltage: 24 V DC (±10%)
Power Consumption: ≤5 W
Digital Inputs: 16 channels
Flash: 512 KB
Analog Inputs: 8 channels

Power Factor Controller

Sensitivity: ≥ 20 mA.
Frequency range: 50 or 60 Hz +/- 5%
Input current impedance: < 0.1 Ohm
Controller energy consumption: ≤ 15VA
Maximum inductive load AC 250V/2.0A
Voltage: ±1%
Current: ±1%
Power factor: ±1.5%
Active power: ±2.5%
Reactive power: ±2.5%

Digital Slave Output Module

Number of Inputs: 14 digital Output
Input Type: Sinking or sourcing (configurable)
Input Current: Typically 5-10 mA per input
Isolation Voltage: Typically 500V AC between field and logic side
Response Time: Typically 1-10 ms
Analog: 20 mA max per channel

Digital Input Module

Number of Inputs: 16 digital inputs
Input Type: Sinking or sourcing (configurable)
Input Current: Typically 5-10 mA per input
Isolation Voltage: Typically 500V AC between field and logic side
Response Time: Typically 1-10 ms
Analog: 20 mA max per channel

Universal Signal Converter

Brand:ABB
Input Range:0 → 10 V, 0 → 20mA
Mounting Type:DIN Rail
Operating Temperature Range:-20 → +60°C
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:+60°C

Driver board

Input Voltage Range: Typically 24V DC
Output Voltage Range: Dependent on the connected load
Current Rating: Up to 10A
Power Rating: Typically around 240W
Operating Frequency: 1kHz to 20kHz

IGBT MODULE

INVERTER TRIGGER DRIVER BOARD
PROTECTION
Rated Voltage (V_CE):650V
Rated Current (I_C):70A
Peak Current (I_C_peak):Up to 180A
Power Dissipation:150W to 300W
Switching Frequency:Up to 20 kHz
Thermal Resistance (R_thJC):1.5°C/W to 2.5°C/W
Junction Temperature (T_j):-40°C to 150°C

Transducers Current Sensors

Part Status:Not For New Designs
For Measuring:AC/DC
Current - Sensing:1000A
Frequency:DC ~ 150kHz
Linearity:±0.1%
Accuracy:±0.4%
Voltage - Supply:24V
esponse Time:1µs
Current - Supply (Max):20mA
Operating Temperature:-10°C ~ 70°C

INVERTER ACS850 SERIES ADAPTER BOARD

PC BOARD
INVERTER ACS850 SERIES
ADAPTER BOARD

Contactor

220-230V 50Hz / 230-240V 60Hz
Model Number: A30-30-10
Rated Operational Current (Ie): 30 A
Rated Operational Voltage (Ue): Up to 690 V AC
Control Voltage: 24-230 V AC/DC
Poles: 3 (3-phase)
Mechanical Life: Up to 10 million operations
Electrical Life: Up to 1 million operations
Enclosure Rating: IP20

Frequency converter

ACS510-550 Frequency converter
Model Number: 3X4K7 10028493B
Input Voltage: 3-phase, 380-480 V AC
Output Voltage: 0-480 V AC
Frequency Range: 0-400 Hz
Rated Power: 7.5 kW (10 HP)
Current Rating: 16 A
Enclosure Rating: IP20 (suitable for panel mounting)
Cooling Method: Air-cooled

Main Circuit Interface Board

Manufacturer: ABB
Model: RINT-6512C
Type: Main Circuit Interface Board
Function: Interfaces between control logic and power circuits in drives/inverters.
Voltage Rating: 24V DC
Temperature Range: -20°C to +70°C.
Humidity: Up to 95% (non-condensing).

Driver board

Manufacturer: ABB
Model: RINT-6421C
Type: Driver Board
Operating Voltage: Typically 24V DC
Current Hadling: Low to moderate
Isolation: Galvanic isolation for control and power stages
Protection: Over-current, over-voltage, short-circuit protection
Temperature Range: -20°C to +70°C
Humidity: Up to 95% (non-condensing)

FAN

Voltage: 230V AC
Frequency: 50/60 Hz
Current Consumption: Approximately 0.3A
Power Consumption: Around 65W
Airflow: Approx. 280 m³/h (165 CFM)
Speed: 2650 RPM
Noise Level: Approx. 55 dB(A)

Processor board

AC 800M series systems
Voltage Supply: Typically 24 VDC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C.
Humidity: 5% to 95%

IGBT Module

Voltage Rating: 1200 V
Current Rating: 450 A
Configuration: Sixpack
Technology: IGBT3 – E3
Package Type: EconoPACK™ + B
