POWER INTERFACE CONTROL BOARD
control electronics Standard incl.
terminals C98043-A7100-L1
Primary Supply (Logic): 24 V DC ±10%
Current Handling (Logic): ≤5 A
Analog signal inputs:±10 V, 4–20 mA
Operating: 0°C to +40°C (full rating).
Extended: Optional derating up to +60°C
Humidity: ≤85% (non-condensing)
Power supply module
SIMOVERT Master drives
Power supply module
PSU1 For devices with
Designs E through H 3 AC
380-460, 660-690V, 50/60 Hz
and 510-620V DC
890-930 V DC
Inverter IGD trigger board
Input Voltage: 24 V DC
Voltage Range: +15 V to -10 V
Current Capacity: 5–10 A
Switching Frequency: Up to 20 kHz
Galvanic Isolation Voltage: ≥2500 V AC
Operating Temperature: -20°C to +55°C
Storage Temperature: -40°C to +85°C
Inverter drive board
Control Voltage: 24 V DC
Signal Voltage: 5 V/3.3 V
Switching Frequency:12–16 kHz
Current Ratings:55–160 kW
Overload Capacity: Typically 150%
Temperature: –10°C to +40°C
Humidity: ≤90% (non-condensing)
Inverter drive board IGD trigger board
Trigger Voltage/Current:+15 V/-10 V
Switching Frequency: Up to 20 kHz
Isolation Voltage: ≥2000 V AC
Logic Supply: +24 V DC (±10%)
Gate Driver Supply: ±15 V DC
Operating Temperature: 0–55°C
DRIVE BOARD
Power Supply (Control Section): 24 V DC (±20%)
DC Link Voltage Handling:500–800 V DC
Motor Compatibility: up to 100s of kW
Switching Frequency: 2–16 kHz
Digital Inputs/Outputs:≥6 DI/DO
Analog Inputs:≥2 × ±10 V, 4–20 mA
Operating Temperature: 0–45°C
POWER ENTRY CONTROL MODULE
Voltage Range: 3-phase AC input
Frequency: 50/60 Hz (±5%)
DC Link voltage:510–720 V DC
Continuous Current (DC Link): Up to 60–80 A
Auxiliary Voltage Supply: 24 V DC
Aambient Temperature: 0–40°C
G120L Inverter Motherboard
Supply Voltage: 24 V DC (±20%)
Power Consumption: ≤15 W
Motor Compatibility: up to 55 kW
Standard Communication:PROFIBUS DP
Operating Temperature: -20°C to +60°C.
Relative Humidity: ≤95% (non-condensing)
Inverter Power Board
Voltage Range:380–480 V AC
Frequency: 50/60 Hz ±5%
Rated Current:20–200 A
Continuous Power: 10–150 kW
Operating Temperature: -10°C to +50°C (storage up to +70°C)
Frequency Converter Drive Board
PROFIBUS/MPI or PROFINET
Control Voltage: 24 V DC (±15%)
Output Switching Frequency: 1–16 kHz
Isolation Voltage: ≥2.5 kV AC
Operational Temperature: 0°C to +50°C
Inverter control board
Control Voltage: +24 V DC
Switching Frequency: 5 kHz–15 kHz
Output Pulses: ≥8 PWM
Digital: Start/stop, fault reset
Analog: ±10 V
Operating Temperature: –10°C to +50°C
Inverter control board
Inverter control board
IGD9 for devices 510-620 V DC
1300 A
Logic Supply Voltage: +24 V DC (±10%)
DIP Switches:0–10 V, 4–20 mA
Operating Temperature: 0°C to +40°C
Humidity: ≤95% (non-condensing)
INVERTER DRIVE TRIGGER BOARD
Control Voltage: 24 V DC (±10%)
Isolation Voltage: ≤2.5 kV AC
Output Frequency: ≤20 kHz
Max Output Current: 3–5 A
Signal Logic: 0–24 V DC control signals
Operating Temperature: –10°C to +55°C
Storage Temperature: –40°C to +85°C
Relative Humidity: ≤93% (non-condensing)
Frequency converter trigger driver board
Logic Circuit: 24 V DC
Isolation Voltage: ≥2.5 kV AC
Output Current: Up to 2–3 A
Frequency Range: 1 kHz–20 kHz
Operating Temperature: 0°C to +60°C
Humidity: ≤95% (non-condensing)
Impedance capacitance plate
SIMOTRAS HD Snubber circuit
Rated Voltage (Unm): 690 V AC (50/60 Hz)
Operating Voltage Range: 200–750 V AC
Capacitance: 10–50 μF
Impedance Range: 5–50 Ω at 50 Hz
Dielectric Strength: 2.5 kV AC
OPERATOR PANEL
OPERATOR PANEL
PMU
PARAMETER ASSIGNMENT UNIT
FOR DESIGNS C / D
SIMOVERT MASTERDRIVES
Power supply module
PSU2 Power Board
Power supply module
Nominal Voltage: 400 VAC
Input Range: 380 VAC – 480 VAC
Frequency: 45–65 Hz
Output Voltage: 24 VDC
Output Current: Typically 10 A
Power Rating: 240 W
Thermal sensor
Thermal sensor
THERMAL DETECTOR
FOR ACQUISITION OF HEAT SINK TEMPERATURE
Operating Range: -25°C to +150°C
Accuracy:±1.5°C
Response Time:<1 second
Operating Voltage: 24 VDC
Shock/Vibration Resistance: 5–100 Hz
DC speed regulator cable
DC speed regulator cable
Flat ribbon cable
Power Interface
Allocation Board A7126-X108
