Bently Nevada

3300 XL Proximitor Sensor

11 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system lengtht
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330102 3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.4 in
Minimum case length: 4.5 in
50 5.0 meters (16.4 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

PROXPAC XL Proximity Transducer,English

0 0No probe; Proximitor sensor withoutapprovals
Minimum length: 2.0 in (50.8 mm)
0 3 8 3.8 in (96.52 mm)
0 0No fittings; two plugs and twowashers
0 23/4-14 NPT

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 8.0 in
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
00 Not required

Proximity ProbeHousing Assemblies

28 3300 XL 8mm, with approvaloption
10 39 in (1.0 m)
3.5 in (88.9 mm) = 35
2.7 in (68.58 mm) = 027
03One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPTreducer
One cable seal grip withgrommets for
the followingcable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

EnglishProximity Probe HousingAssemblies

28 3300 XL 8 mm probe, multipleapprovals
05 0.5 m (20 in)
No standoff adapter = 00
3.7 in (94 mm) = 037
03Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 1.5 in
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 11 mm Proximity Probes

330703    3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length:60 mm
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
05 Multiple Approvals

Proximity Probe HousingAssemblies

34 3300 XL 8mm probe with connectorprotector
selectable hazardous areaapprovals
05 0.5 m (20 in)
15 Minimum length 1.5 in (38 mm)
2.9 in (73.66 mm) =029
04 One 3/4-14 NPT plug only
023/4-14 NPT

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length:140 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 70 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 11 mm Proximity Probes

330709  3300 XL 11 mm Probe
M16 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length:70 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 20 mm
Minimum case length: 80 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Proximity Probes

330909    3300 NSv Probe
3/8-24 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length:  2.0 in
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 NSv Proximity Probes

330902 3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 3.8 in
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 10 mm
Minimum case length: 90 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
90 9.0 meters (29.5 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

X3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
90 9.0 meters (29.5 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 2.5 in
05 0.5 meter (1.6 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330102 3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 4.0 in
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Proximity Probes

330704 3300 XL 11 mm Probe
M14 x 1.5 thread,with armor
Minimum unthreaded length:0.0 in
Minimum case length: 5.0 in
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 Multiple Approvals

3300 XL 11 mm Proximity Probes

330701 3300 XL 11 mm Probe
1/2-20 UNFthread, without armor
Minimum unthreaded length:0.0 in
Minimum case length: 2.5 in
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
05 Multiple Approvals

PROXPAC XL Proximity Transducer,Metric

2 8 3300 XL 8 mm probe withMultiple Approvals
Minimum length: 60 mm
Minimum length: 155 mm
0 3 One M20 fitting, two plugs
0 23/4-14 NPT

Interconnect Cable

3-conductor shielded 22 AWG(0.5 mm2) cable
with 3-socketplug at one end
terminal lugs atthe other end
Minimum lengthof 2.0 ft (0.6 m)
maximumlength of 99 ft (30 m)

3300 XL 11 mm Extension Cable

080 8.0 meters (26.2 feet)
10 FluidLoc cable
05 Multiple Approvals
