B&R

PC Control

Intel Atom E3800 processors (Bay Trail)
Up to quad-core CPU performance
Powerful graphics (Intel HD graphics)
Compact dimensions
2x Gigabit Ethernet
SDL/DVI or SDL3
1x USB 3.0, 1x USB 2.0
1x CFast slot
 1x slot for interface options
Fanless operation

Control Module

Type:Renata 950 mAh
Controller:MTCX
Buffer time:10 ms
Quantity:2
Variant:RJ45, shielded
Transfer rate:10/100/1000 Mbit/s
Max. baud rate:1 Gbit/s
Variant:DVI-I
Type:SDL/DVI/Monitor

Digital input module

I/O module:16 digital inputs 24 VDC in 4 groups
Status indicators:I/O function per channel
Operation:0 to 60°C
Storage:-25 to 70°C
Nominal voltage:24 VDC
Hardware:≤12 ms

INVERTER MODULE

Nominal:750 VDC
Input voltage:25 VDC ±1.6%
Input capacitance:23.5 µF
Output voltage:24 VDC +5.8% / -0%
Continuous current per connection 1.1 A
Max. internal resistance:0.5 Ω
Enable 1 → 0, PWM off:Max. 20.5 ms

POWER PANEL

Type:FT color
Diagonal:10.4" (264 mm)
Resolution:VGA, 640 x 480 pixels
Buffer time:10 min
Variant:Lithium ion
Clock frequency:266 MHz
L1 cache:16 kB
Flash:2 MB (for firmware)
Cooling:Passive via heat sink
Mode/Node switches:2, 16 positions each
Accuracy At 25°C: Typ. 10 ppm (1 second) per day
Controller:SMC

Touch screen

Renata 950 mAh
Lithium ion
0.8 µs
Resolution 1 s
448 kB FlashPROM
1024 kB FlashPROM
300 kB SRAM
115.2 kbit/s
9-pin male DSUB connector
I/O function per channel, status

Automation Frequency Inverter

4 Drive Sizes
Integrated EMC Filter
Brake Chopper
1-Phase or 3-Phase

Power Supply Module

Input: 3x 380 to 480 VAC ±10%
Output voltage adjustable via X2X Link
Status information readable via X2X Link
Chopper output for connecting an external braking resistor
3-phase wide range input
Closed metal housing

CPU Module

Intel Celeron 266
Performance with additional I/O processor
Ethernet, POWERLINK and USB onboard
1 slot for modular interface expansion
CompactFlash as removable application memory
Fan-free
Extremely compact

ACOPOS Servo Drive

Mains input voltage:3x 400 VAC to 480 VAC ±10%
Frequency:50 / 60 Hz ±4%
Installed load:Max. 17 kVA
Inrush current at 400 VAC:13 A
Switch-on interval:>10 s
Input voltage:24 VDC +25% / -20%
Input capacitance:40,000 µF
Switch-on voltage:455 VDC
Mains input voltage applied:22 to 24 VDC

ACOPOS Servo Drive - 0.7 KW

CAN Interface Module

ACOPOS plug-in module
B&R ID code 0x1198
Slot Slot 1
Power consumption Max. 0.7 W
Certifications
CE Yes
UL cULus E225616
Power conversion equipment
KC Yes
odule-side connection 9-pin male DSUB connector
Status indicators RXD/TXD LEDs
Baud rate 500 kbit/s
Electrical isolation Yes
Max. distance 60 m

INDUSTRIAL COMPUTER

INDUSTRIAL COMPUTER
APC810 SYSTEM UNIT 1 SLOT
(PCI EXPRESS / PCI / DEPENDS ON BUS)
1 SLIDE-IN COMPACT SLOT
SMART DISPLAY LINK/DVI/MONITOR
2X RS232
5X USB 2.0
2X ETH 10/100/1000
24 VDC

128 MB Compact Flash Memory Card

5CFCRD012803
COMPACTFLASH CARD ATA/IDE SANDISK

CPU/Power Supply Module

M2NTCP330
DISCONTINUED BY MANUFACTURER
MAIN RECEIVER

Graphic Controller

HCMGC10
B&R
HCMGC1-0
GRAPHIC CONTROLLER MAESTRO
