Woodward

OPERATOR INTERFACE

Enclosure Type:NEMA 4
Features:Program upload/download capability
Input Voltage:18–32 Vdc
Keypad/Display:30 Analog Keys
Operating Temperature:-13C to +149F
Output Type:
2 Actuator Outputs,
8 Relay Outputs
6 Programmable Current Outputs
Resolution:2 Rows of 12 Characters

9905968
DISCONTINUED BY MANUFACTURER
LINKNET NODES AND I/O CONTROLLER MODULE
6-CH ANALOG INPUT
4-20 MA
WITHOUT 24 V LOOP

5501376
ANALOG MODULE

5466031
LINKNET CONTROLLER MODULE
4-CHANNEL
NETCON I/O

9905760
DISCONTINUED BY MANUFACTURER
LINKNET
TERMINATION RESISTOR MODULE

9905971
DISCONTINUED BY MANUFACTURER
INPUT MODULE
16 CHANNEL DISCRETE INPUT
24 VDC

Linknet 6-Channel Analog Input Module

Display Type: 2 line x 24 characters
Accuracy: 1 % at 25 °C
Power Supply Input: (18 to 32) V (dc)
Network to I/O channel: 277 V (ac)
Power supply input to network: 277 V (ac)
Power supply input to I/O channel: 500 V
Humidity Standards: 20 and 55 °C at 95% for 48hrs
Input Voltage: +24 Vdc at 1 A
Keypad/Display: 30 Multi-function Keypad
Temperature Range: (–40 to +55) °C

5466409
DISCONTINUED BY MANUFACTURER
PC BOARD
MICRONET PENTIUM CPU
64 MB
233 MHZ
