ICS Triplex

EXPANDED MODULE TRUSTED FIBRE TX RX UNIT

Voltage: 100–240V AC (auto-ranging), 50/60 Hz.
Current: 10A (max at 100V AC)
Efficiency: ≥90%
Operating Temperature: -20°C to +70°C
Humidity: 5–95% non-condensing

Expander Processor

2 x 30 mm (1.2 in) Trusted Expander Processor Slots
12 x 30 mm (1.2 in) single width Trusted I/O Module Slots.
No user-serviceable parts inside.
Fast assembly.
Minimum tooling/parts.
32, 48, 64 and 96-way
DIN 41612 I/O port connector capability
Cable entry options.
Convection cooling of modules through the Chassis

Monitored Digital Input Module

Safetybus Power 0.85 load units
Number of Inputs 16, common power return
Vibration10 to 55 Hz: ±0.15mm
Turn-On Voltage (default) > 12 Vdc
Voltage: 15 to 80 VDC
Current:450 mA, maximum

COMMUNICATION INTERFACE

COMMUNICATION INTERFACE
TRUSTED
40 CHANNEL
24 VDC

Trusted 24V DC Rack Grill Fan

Simple installation and connection.
Capable of moving 69 m3/h (40.6 ft3/min).
24 Vdc operation.
Low noise (32 dB per fan)

Trusted 40 Channel Analogue Input

40 input channels per FTA.
Industry standard field device connections (2-wire).
Standard DIN rail compatibility.
Simple installation and connection.
24 Vdc operation.
SmartSlot connection for ‘one to many’ hot replacement of input modules.
Fused field power supply per channel.
On-board Light Emitting Diode (LED) indication of field power supply integrity.

Field Termination Assembly

40 output channels per FTA
Industry standard field device connections (2-wire)
Standard DIN rail compatibility
Screw clamp terminals on both field and power
Simple installation and connection
24 Vdc operation

AADVANCE WORKBENCH 2

OPC portal server

IEC 61131 Workbench, 5 user USB key, multiple controllers

IEC 61131 Workbench, hard disk key, multiple controllers

Multiple controller

Input Voltage: 24 Vdc (±10%)
Power Consumption: ≤ 5 W (typical).
Operating Temperature: -40°C to +70°C.
Humidity: 5–95% non-condensing.

IEC 61131 Workbench, hard disk key, single user, single controller

IEC 61131 Workbench, USB key, single user, single controller

FUSE

T9901
FUSE
T9901 REPLACEMENT INPUT FUSE
Replacement input fuse 50 mA for
T9801/2/3 and T9831/2/3, pack of 20

Replacement output fuse

REPLACEMENT INPUT FUSE
Replacement output fuse 10A for T9851/2, pack of 20
SMF Omni-Block
Surface Mount Fuse Block 154 010
with a 10 A
125 V Fast Acting Fuse
Littelfuse

Blanking cover (short) for I/O positions with TA or a Processor

Blanking cover (tall) for I/O positions with no TA fitted

Analogue output TA, 8 channel, dual, isolated

Output Range:4–20 mA
Resolution: 16-bit (high precision).
Accuracy: ±0.1% of full scale.
Channel-to-Channel Isolation: 1,500 Vdc
Operating Temperature: -40°C to +70°C.
Humidity: 5–95% non-condensing
Supply Voltage: 24 Vdc (±10%) via AADvance backplane.
Power Consumption: ≤ 5 W (typical).

Analogue input TA, 16 channel, TMR, isolated

Analogue input TA, 16 channel, simplex, commoned

Digital input TA, 16 channel, TMR, isolated

Analogue output module, 3 channel, isolated
