GE Mark VIe

Application Control Layer Module

Part No: IS200AEPCH1ABCFA
Manufacturer: General Electric
Product Type: Application Control Layer Module
Series: EX2100

Printed circuit board

Series: Mark VIe
Product type: Printed Circuit Board
Ethernet Interfaces: 10BaseT/AUI connector
Relative Humidity: 10-95%, non-condensing
Female Plug Connectors: 2
Power Supply Rating: 125 VDC
Software Frame Rates: 10, 20 and 40 ms
Storage Temperature: -40 to +70 degrees Celsius

Printed Circuit Board

Series: Mark VIe
Product type: Printed Circuit Board
COM Ports: 3; COM1, COM2, and micro-miniature 9-pin socket D connector
Ethernet Interfaces: 10BaseT/AUI connector
Manual: GEP-9145
Relative Humidity: 10-95%, non-condensing
Shock: maximum 10G, non-operating
Female Plug Connectors: 2
No.of Metal Oxide Varistors: 4
Power Supply Rating: 125 VDC
Software Frame Rates: 10, 20 and 40 ms
Storage Temperature: -40 to +70 degrees Celsius

Turbine Control Card

Number of channels: 16 channels
Span: 0.3532 to 4.054 V
Common mode voltage range: 5 V
Maximum lead resistance: 15 ohm maximum
Fast scan: 40 ms (25 Hz)
Power consumption: Less than 12 W

Resistance Temperature Device

Part No.: IS200VRTDH1DAB
Manufacturer: General Electric
Number of channels: 16 channels
Span: 0.3532 to 4.054 V
Common mode voltage range: 5 V
Maximum lead resistance: 15 ohm maximum
Fast scan: 40 ms (25 Hz)
Power consumption: Less than 12 W

Printed circuit board

Part No.: IS200VSVOH1BED
Manufacturer: General Electric
Power supply voltage: Nominal 24 V dc
LVDT accuracy: 1 percent with 14-bit resolution
LVDT input filter: Low pass filter
LVDT common mode rejection: CMR is 1 V, 60 dB
Magnetic PR pickup signa:l Generates 150 V p-p
Active PR Pickup Signal: Generates 5 to 27 V p-p

VME Controller Card

Mark VI
Processor
VME Controller Card
QNX
Intel Celeron 300 MHz
32 MB DRAM
Twisted pair 10BaseT/100BaseTX, RJ-45 connector

Analog Output Board

Series: Mark VI
Part No.: IS200VAOCH1BBA
Manufacturer: General Electric
Product Type: Analog Output Board
Output: 16 analog 20 mA outputs
Functional Abbreviation:VAOC

Printed Circuit Board

Series: Mark VIe
Product type: Printed Circuit Board
COM Ports: 3; COM1, COM2, and micro-miniature 9-pin socket D connector
Ethernet Interfaces: 10BaseT/AUI connector
Manual: GEP-9145
Relative Humidity: 10-95%, non-condensing
Shock: maximum 10G, non-operating
Female Plug Connectors: 2
No.of Metal Oxide Varistors: 4
Power Supply Rating: 125 VDC

I/O Pack

Manufacturer: General Electric
Part Number: IS200PAICH1B
Series: Mark VI Speedtronic
Functional Part Number: IS220PDIAH1B
Function: I/O Pack
Functional Acronym: PDIA

DIN Rail Terminal Board

Part Number: IS200STTCH2A
Manufacturer: General Electric
Series: Mark VI
Function: Terminal Board

Turbine Protection Board

Series: Mark VIe
Product Type: Turbine Protection Board
Number of Inputs: 3
Number of Outputs: 6
Operating temperature: -30 to 65℃
Power Supply Voltage: 125 V

Servo I/o Module

Part No.: IS220PSVOH1B
Manufacturer: General Electric
Product Type: I/O Pack, Servo Control Pack
Series: Mark VIe

Terminal Board

Series: Mark VIe
Product Type: Terminal Board
Technology: Surface mount
Number of outputs: Generator breaker coil, 5A at 125 V dc
Power supply voltage: Nominal 125 V dc to breaker coil
MPU pulse rate range: 2 Hz to 20 kHz

Analog Output Module

Series: Mark VIe
Product Type: Analog Output Module
Number of channels: 12
Common Mode Voltage Range: +5 V dc
Maximum Lead Resistance: 15Ω
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C
Size: 8.26 cm high x 4.18 cm
Frequency: 50 or 60 Hz

Mark VIe I/O pack

Series: Mark VIe
Product Type: I/O PACK
Number of channels: 12
Maximum Lead Resistance: not exceed 450Ω
Analog output current: -8 to 45 mV

Analog Output Module

Series: Mark VIe
Product Type: Analog Output Module
Number of channels: 12
Common Mode Voltage Range: +5 V dc
Maximum Lead Resistance: 15Ω
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C
Frequency: 50 or 60 Hz

Primary Turbine Protection DIN Rail Module

Series: Mark VIe
Function: Primary Turbine Protection DIN Rail Module
Operating Temperature: -40°C to +70°C
Controller and I/O module Redundancy: Simplex
Internal operating system: QNX
Operating Voltage: 9 V to 16 V dc
Power Consumption: 4 W
Analog outputs: 0 to 10 V
Configuration Software: ToolboxST
Ethernet Ports: 2 Ethernet ports

Analog DIN Rail Input/Output Module

Series: Mark VIe
PCI bus: 32bit/33MHz
Product Type: Analog DIN Rail Input/Output Module
Number of channels: 12
A/D resolution: 16 bits
Number of inputs: 32 single-ended
Common Mode Voltage Range: +5 V dc
Maximum lead resistance: 15Ω max
Output Load: 500 Ω for 4-20 mA
Operating temperature: 0 to 70°C
Frequency: 50 or 60 Hz

Digital Input/Output board

Input Voltage Range: 24–125 VDCor 120 VAC.
Output Ratings:
Relay Outputs: Up to 5 A, 250 VAC/30 VDC.
Solid-State: 0.5–2 A (24–48 VDC).
Isolation:1500 VAC minimum
Operating Temperature: -40°C to +85°C (industrial-grade).
Certifications: CE, UL, IEC 61131-2

THERMOCOUPLE INPUT UNIT

THERMOCOUPLE INPUT UNIT
MARK VIE
I/O PACK
POWER SUPPLY / 0.16 AMP / 28 VDC
FOR SPEEDTRONIC MKVIE GAS TURBINE CONTROL

Rev AA and C VME COMM INTERFACE

IS215VCMIH2CC
PC BOARD

ACOUSTIC MONITORING CARD ASSEM

IS215VAMBH1A
DISCONTINUED BY MANUFACTURER
MONITORING CARD ASSEMBLY ACCOUSTIC

VME VIBRATION CARD

IS200VVIBH1C
DISCONTINUED BY MANUFACTURER
PC BOARD
VME VIBRATION CARD

MK6 GAS TMR PK TURBINE CARD
