Eddy Current Sensor
Measurement Range: 2 mm (80 mils)
Initial Air Gap: 0.5 mm (20 mils)
Incremental Scale Factor (ISF):
8 V/mm (203.2 mV/mil)土5%
Deviation from Best Fit Straight Line (DSL)
士0.025 mm (土1 mil)
Minimum Shaft Diameter: 25 mm (0.79”)
Target Material:
Ferromagnetic Steel (42CrMo4 / AISI 4140)
Protection Class: IP66 (IEC 60529)
8mm Eddy Current Sensor
Linear Measurement Range 2 mm (80 mils)
Initial Air Gap 0.5 mm (20 mils)
Incremental Scale Factor (ISF) ISO:
8 V/mm (203.2 mV/mil) ± 5%@
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)@
temperature range 0 to 45°C(+32 to +113°F)
Minimum Shaft Diameter 25 mm (0.79”)
8mm Eddy Current Sensor
Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor (ISF):
ISO: 8 V/mm (203.2 mV/mil) ± 5%
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)
temperature range 0 to 45°C(+32 to +113°F)
