Terminal Block
I/O TERMINAL BLOCK
24 VDC
2 AMP
Rated Voltage: 250 V AC/DC
Rated Current: 10 A
Solid wire: 0.2 to 4 mm²
Stranded wire: 0.2 to 4 mm²
RTD / Resistance Input Card
Local Bus Power 12 VDC at 160 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz;
0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –
1985 AirborneContaminants Class G3
Relative Humidity 5 to 95% Non-Condensing IP 20 Rating
Terminal Block keyPosition C3
16-CH AI Terminal Block
Input Power Rating 30 VDC @ 100m A
AmbientTemperature-40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration
1 mm peak to peak from 2 to 13.2 Hz;
0.7 g from 13.2 to 150 Hz
AirborneContaminants
ISA-S71.04 –1985 Airborne
Contaminants Class G3
Relative Humidity 5 to 95% non-condensing
I.S. DO 45 mA CHARM
CHARM Bus power rating +6.3 VDC at 0 mA
Field circuit power rating+24 VDC at 78 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to13.2Hz;
0.7g from 13.2 to 150Hz
Airborne Contaminants
ISA-S71.04 –1985 Airborne
Contaminants Class G3
Industrial Control Module
Digital Inputs/Outputs:
Supports discrete I/O for control and status monitoring.
Analog Inputs/Outputs:
Can include support for continuous analog signals
Operating Temperature: 0°C to 60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95%, non-condensing
IS module power supply carrier
IS module power supply carrier 8724-CA-PS
Accommodates one 8920 PSU module
DIN rail or panel mounting
printed wiring board
rugged polycarbonate moulding
32- and 64-slot address capable
CARRIER MOUNTING MODULE:
System Power Supply module: 8920-PS-DC
DC power supply
8920-PS-DC
Power Module-Field Input
24VDC In
5A@12VDC Out
Power for 2/1 (IS) modules
Use2/1 (IS)
modules power with
support for load sharing redundancy
DC power supply
PAC8000 I/O
Power Module-Field Input24VDC In
5A@12VDC Out;
Power for 2/1 (IS) modules
Use2/1 (IS) modules power
with support for load sharing redundancy
PAC8000 Intrinsically Safe module
DC power supply (8 modules)
Analog Input Module
Ovation Distributed Control System
8 to 16 analog input channels
Analog signals
4-20 mA, 0-10 V
16-bit resolution for high precision
0°C to 60°C
Analog Input Module
Channels: 15
Signal Types:
standard current input:4-20 mA
voltage inputs0-5 VDC
Input Range: 0-10 VDC, ±10 VDC,
Signal Conversion: 16-bit
Input Impedance: High input impedance f
or accurate measurements without significant loading.
Input Accuracy: Typically ±0.1%
Operating Temperature: -20°C to +60°C
Analog output module
Channels: 16 or 32
current output:4-20 mA
voltage output:0-10 VDC or ±10 VDC
Output Range:0-10 V, ±10 V, 4-20 mA
Resolution: 16-bit
Accuracy:
±0.1% of full scale for voltage outputs
±0.1% of full scale for current outputs
INPUT MODULE
396569013
DISCONTINUED BY MANUFACTURER
INPUT MODULE
ISOLATED
24V LOCAL CONNECTOR
INCLUDES LED DAUGHTERBOARD
INPUT MODULE
396571026
DISCONTINUED BY MANUFACTURER
INPUT MODULE
ISOLATED
24V LOCAL CONNECTOR
INCLUDES LED DAUGHTERBOARD
COMMUNICATION MODULE
396581013
DISCONTINUED BY MANUFACTURER
COMMUNICATION MODULE
400 MA AT 3.3 VDC
510 MA AT 24 VDC
2 X 9-PIN MALE CONNECTORS
RADIO PORT
RJ45 MODEM PORT
LED INDICATORS
PROVOX DISCRETE I/O TERM
Model: CL6343X1-A1 (34B2790X032)
System: Emerson PROVOX DCS
Function: Control and monitor discrete (on/off) I/O signals for industrial process automation
Input/Output: Discrete signal input and output (typical voltage 24V DC)
Installation: Control cabinet or rack installation
Communication: Integrated with PROVOX DCS system, supporting real-time data exchange
Power supply: Standard DC power supply compatible with PROVOX system
BUS TERMINATOR MODULE
1B30023H01
DISCONTINUED BY MANUFACTURER
I/O BUS TERMINATOR ASSEMBLY
12 PIN
