The warranty of industry automation components and parts that "amikon" 1-year warranty.
Frequency Converter Power Board
Input Voltage Range: 230 V AC to 690 V AC
Frequency Range: 0–300 Hz
Efficiency: ≥ 98% under standard load conditions
Operating Temperature: -10°C to +55°C
Storage Temperature: -40°C to +70°C
Humidity: 5% to 95% (non-condensing)
ACS880 frequency converter drive board
ACS880 frequency converter drive board
Operating Voltage: 24 Vdc
Analog Inputs: 0–10 V or 4–20 mA
Operating Temperature: -10°C to +50°C
Humidity: 5–95% non-condensing
Compact alternating current drives
Output Power: 160 kW (215 HP) at 400 V AC.
Output Current: 302 A
Input: 380–480 V AC, 3-phase (±10%), 50/60 Hz.
Output: 0–480 V AC
Efficiency: ≥97% (typical at full load)
Control I/O: 5x analog inputs (2x 0–10 V / 0–20 mA)
Switching Frequency: 1–8 kHz
Analog Input Termination Unit
Input Types: Supports 4–20 mA, 0–20 mA, 0–10 VDC
Channels: Typically 8 or 16 channels
Resolution: 16-bit ADC
Supply Voltage: 24 VDC (±10%)
Power Consumption: 2–5 W
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5–95% non-condensing
GATE DRIVE BOARD
Input Voltage: 24 VDC (±10%)
Analog Inputs: 0–10 VDC / 4–20 mA
Fieldbus Support: PROFIBUS DP
Operating Temperature: -25°C to +55°C (-13°F to +131°F).
Humidity: 5–95% non-condensing
PCB CARD
Input Voltage: 24 VDC (±10%)
Analog Inputs: 0–10 VDC / 4–20 mA
Fieldbus Support: PROFIBUS DP
Operating Temperature: -25°C to +55°C (-13°F to +131°F).
Humidity: 5–95% non-condensing.
PCB CARD
Input Voltage: 24 VDC (±10%)
Analog Inputs: 0–10 VDC / 4–20 mA
Fieldbus Support: PROFIBUS DP
Operating Temperature: -25°C to +55°C (-13°F to +131°F).
Humidity: Up to 95% non-condensing
PCB CARD
Input Voltage: 24 VDC (±10%)
Analog Inputs: 0–10 VDC / 4–20 mA
Fieldbus Support: PROFIBUS DP
Operating Temperature: -25°C to +55°C (-13°F to +131°F).
Humidity: Up to 95% non-condensing
Control Card
Input Voltage: 24 VDC (±10%)
Analog Inputs: 0–10 VDC or 4–20 mA
Operating Temperature: -25°C to +55°C (-13°F to +131°F)
Humidity: Up to 95% non-condensing.
Vibration Resistance: 5–150 Hz
Drive board
Input Voltage: 24 VDC (±10%)
Analog Inputs: 0–10 VDC or 4–20 mA
Operating Temperature: -25°C to +55°C (-13°F to +131°F).
Humidity: Up to 95% non-condensing.
Vibration Resistance: 5–150 Hz
PHASE INTERFACE BOARD
RAM: Typically 512 MB to 1 GB
Supply Voltage: 24 VDC (±10%).
Power Consumption: Typically 5–10 W
Operating Temperature: -20°C to +70°C (-4°F to +158°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Humidity: 5–95% non-condensing
Control board
RAM: Typically 512 MB to 1 GB
Flash Memory: 2–4 GB
Supply Voltage: 24 VDC (±10%).
Power Consumption: Typically 5–10 W
Operating Temperature: -20°C to +70°C (-4°F to +158°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Humidity: 5–95% non-condensing
PULSE TRANFORMER
Isolation Voltage: Typically 2–4 kV
Primary/Secondary Voltage: 5–24 V AC/DC input
Operating Temperature: -40°C to +85°C
Certifications: Complies with IEC/EN
Turns Ratio: 1:1 or custom ratios
Impedance:50–100 Ω
Control panel
Type: LCD or TFT color touchscreen
Operating Voltage: 24 VDC (±10%) or 110–230 VAC
Power Consumption: 10–20 W
Operating Temperature: -10°C to +55°C
Storage Temperature: -40°C to +70°C
Humidity: 5–95% (non-condensing)
FIRING PULSE TRANSFORMER BOARD
Model: SDCS-PIN-H41
Part Number: 3ADT320600R1501
Pulse Voltage: 5–24 V DC
Isolated Pulse Voltage: Typically 10–30 V
Output Current: 1–2 A
Primary-to-Secondary Isolation: ≥2500 V AC
Insulation Resistance: >100 MΩ
Fast I/O module
Input Voltage: 24 VDC
Output Current: ≤0.5 A per channel
Channel-to-Channel: 500 VAC.
Channel-to-Backplane: 1500 VAC
Operating Temperature: -25°C to +60°C (-13°F to +140°F).
Humidity: 5–95% non-condensing
Supply Voltage: 24 VDC (±10%) via backplane.
Power Consumption: ≤5 W
HVD BOARD
Voltage Rating: 3.3 kV, 6.6 kV
Control Voltage: 24 VDC
Power Consumption: <20 W
Operating Temperature: 0°C to +55°C
Humidity: Up to 95% RH (non-condensing)
Power Supply Board
Model: SDCS-POW-H01
Part Number: 3ADT318700R1501
Application: Dedicated power supply unit
Input Voltage Nominal: 24 V DC
Range: 20–30 V DC
AC Input Option: support 100–240 V AC (50/60 Hz)
Primary Output: 24 V DC
Continuous: 5–10 A
Peak Current: Up to 15 A
Excitation plate
Model: SDCS-FEX-4a
Part Number: 3ADT314500R1501
Input Voltage Nominal: 24 V DC
Range: 20–30 V DC
Voltage Range: 0–250 V DC
Current Capacity: Up to 20–50 A
Continuous Output Power: ~5–10 kW
Reference Input: 0–10 V DC or 4–20 mA
DCSLink communication options board
Supply Voltage Nominal: 24 V DC
Supply Voltage Range: 20–30 V DC
Power Consumption:Typically <5 W
Operating Temperature: -25°C to +70°C (-13°F to +158°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Humidity: 5–95% RH (non-condensing).
FIRING PULSE TRANSFORMER BOARD
Model: SDCS-PIN-H41
Part Number: 3ADT320600R1501
Pulse Voltage: 5–24 V DC
Isolated Pulse Voltage: Typically 10–30 V
Output Current: 1–2 A
Primary-to-Secondary Isolation: ≥2500 V AC
Insulation Resistance: >100 MΩ
Power supply board
Model: SDCS-PIN-H51
Order Code/Part Number: 3ADT320700R1501
Nominal Input Voltage: 24 V DC
Input Voltage Range: 20–30 V DC
Primary Output: 24 V DC
Output Current: Typically 2–5 A
Continuous Power: ~60–120 W
Typically ≥85%
1KHL015502R0004 N4BDTEBIT
Power Supply:24 V DC
Power consumption: < 3 W
Supports up to 64 modules
Operating Temperature:–25°C to +60°C
Humidity:≤ 95% (non-condensing)
Coupler Module
Power Supply:24 V DC
Power consumption: < 3 W
Supports up to 64 modules
Operating Temperature:–25°C to +60°C
Humidity:≤ 95% (non-condensing)
CONTROL CARD
Power Supply:24 V DC
Power consumption: < 3 W
Supports up to 64 modules
Operating Temperature:–25°C to +60°C
Humidity:≤ 95% (non-condensing)
