3300 System

Low Frequency Velocity Sensor

Individual M8 x 1
mountingadapter
Sensitivity 20 mV/mm/s (508mV/in/s) ±10%
VelocityRange102 mm/s (4 in/s) peak
AmplitudeLinearity±3%—102 mm/s (4 in/s) peak
Output BiasVoltage-12 ±1 VDC
ShockSurvivability981 m/s2 (100g) peak
Casematerial300 series stainless steel.

3300 XL 50 mm Proximitor Sensor

3300 XL 50 mm Proximitor Sensor
9 19.0 meters (29.5 feet)
systemlength
DIN mount
0 0 No Approvals

3300 XL 8 mm Proximity Probe

3300 XL 8 mm Probe
3/8-24 UNFthread
with armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
00 Not required

3300 XL 11 mm Probe

3300 XL 11 mm Probe
1/2-20 UNFthread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
00 Not required

Proximity ProbeHousing Assemblies

16 3300 XL 8mm probe
05 0.5 m (20 in)
03One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Proximity Probe HousingAssemblies

16 3300 XL 8 mm probe
10 1.0 m (39 in)
03Two plugs,
one 3/4-14 NPT fittingOne 3/4-14 to 1/2-14 NPT SST
reducerOne cable seal grip with grommets
forthe following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

3300 XL 8 mm Probe

3300 XL 8 mm Probe
3/8-24 UNFthread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
00 Not required

3300 XL 8 mm Probe

3300 XL 8 mm Probe
3/8-24 UNFthread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
05 CSA, ATEX, IECEx  Approvals

REVERSE MOUNT PROBE

REVERSE MOUNT PROBE
3300 XL
11 MM
1 M TOTAL LENGTH
MINIATURE CLICKLOC COAXIAL CONNECTOR

3300 XL 25 mm Proximity Probe

02 M30x2 thread
MaximumUnthreadedLength224 mm
MaximumUnthreadedLength8.9 in
MaximumUnthreadedLength250 mm
10 1.0 metre (3.3 feet)
00 No Armor
00 No Approvals

3300 XL 8 mm Proximity Transducer

3300 XL 8 mm Probe
3/8-24 UNFthread
without armor
15 1.5 meter (4.9 feet)
02 Miniature coaxial ClickLocconnector, standard cable
05 CSA, ATEX, IECEx  Approvals
Order in increments of 0.1 in.
Standard thread configurations:
Maximum case length: 9.6 in.
Minimum case length: 0.8 in.
Example: 2 4 = 2.4 in

3300 XL 11 mm Probe

3300 XL 11 mm Probe
1/2-20 UNFthread
with armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 Multiple Approvals
Order in increments of  0.1 in
Length configurations:
Maximum unthreaded length:8.9 in
Minimum unthreaded length:0.0 in
Example: 0 4 = 0.4 in

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread
without armor
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector, FluidLoc cable
CN CSA, ATEX, IECEx  Approvals
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm

3300 XL 8 mm Probe

M10 x 1 threads(2)
90 9.0 meters (29.5 feet)
02 Miniature ClickLoc coaxialconnector
00 Not required

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
05 CSA, ATEX, IECEx  Approvals
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread,without armor
15 1.5 meter (4.9 feet)
02 Miniature coaxial ClickLocconnector, standard cable
05 CSA, ATEX, IECEx  Approvals
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
05 CSA, ATEX, IECEx  Approvals
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature ClickLoc coaxialconnector
05 CSA, ATEX, IECEx  Approvals
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm

330101-00-10-05-02-05

3300 XL 8 mm Probe,
3/8-24 UNFthread
without armor
05 0.5 meter (1.6 feet)
05 CSA, ATEX, IECEx  Approvals
02 Miniature coaxial ClickLocconnector, standard cable
Order in increments of 0.1 in.
Length configurations:
Maximum unthreaded length: 8.8 in.
Minimum unthreaded length: 0.0 in.
Example: 0 4 = 0.4 in.

Vibration Transmitter

Measurement Range: +/- 50 mils (1.27 mm)
Frequency Range: DC to 10 kHz
Output Signal: 4-20 mA
Power Supply: 24 VDC nominal, 18-32 VDC
Temperature Range: -40°C to +85°C

3300 XL 8 mm Probe

3300 NSv Probe, M10X1 thread, witharmor
Order in increments of 10 mm.
Metric thread configurations:
Maximum length: 250 mm
Minimum length: 20 mm
Example: 06 = 60 mm
Example: 0 4 = 0.4 in.
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector,standard cable
CN Multiple Approvals

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread
with armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector with connectorprotector,
standard cable
00 Not required
Order in increments of 10 mm
Length configurations:
Maximum unthreaded length: 230 mm
Minimum unthreaded length: 0 mm
Example: 0 6 = 60 mm

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
3/8-24 UNFthread
with armor
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector,
standard cable
05 CSA, ATEX, IECEx  Approvals
Order in increments of 0.1 in.
Length configurations:
Maximum unthreaded length: 8.8 in.
Minimum unthreaded length: 0.0 in.
Example: 0 4 = 0.4 in.

3300 NSv Extension Cable

060 6.0 meters (19.7 feet)
03 Without stainless steel armor
with connector protector
05 Multiple Approvals

3300 NSv Proximity Probes

3300 NSv Probe
M10X1 thread
without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector,
standard cable
00 Not required
