The GE IC695ETM001 PACSystems™ RX3i Ethernet module is a critical component for industrial automation systems, enabling seamless communication between controllers and external networks. With its robust design and advanced features, this module is ideal for high-performance applications that require reliable and efficient data exchange.
Key Features and Specifications
The IC695ETM001 module provides an array of features that enhance industrial networking capabilities. Below are its core specifications:
Part Number: IC695ETM001
Module Type: RX3i Ethernet module
Connectivity: 10/100 Mbits, 2 RJ45 ports, single IP address
Current Consumption: 840 mA @ 3.3 VDC; 614 mA @ 5 VDC
System Integration: Occupies one slot in the system base
Backplane Compatibility: Universal backplane only, uses PCI Bus
Communication Protocols: SRTP, Modbus TCP, Ethernet Global Data (EGD)
Communication Capabilities
One of the standout features of the IC695ETM001 module is its diverse communication capabilities. It supports multiple protocols, allowing it to interface seamlessly with various controller platforms, including the Series 90 and VersaMax controllers.
Service Request Transport Protocol (SRTP): Enables reliable data transmission between devices.
Modbus TCP: Functions as both a Modbus TCP server and client for industrial automation.
Ethernet Global Data (EGD): Facilitates efficient periodic data exchange over Ethernet.
Embedded Network Management Features
The IC695ETM001 module includes an embedded switch with various configuration options, ensuring seamless network performance. Key features include:
Auto Negotiation: Adjusts network speed and duplex settings for optimal performance.
Sense and Speed Detection: Identifies and configures the appropriate data transmission speed.
Crossover Detection: Automatically detects and adjusts to crossover connections, reducing installation complexities.
Time Synchronization Capabilities
A crucial functionality of the IC695ETM001 module is its ability to synchronize time across the network. It can communicate with an SNTP (Simple Network Time Protocol) time server over Ethernet TCP/IP, ensuring accurate time-stamping for industrial processes.
Conclusion
Conclusion
The GE IC695ETM001 PACSystems™ RX3i Ethernet module is an essential component for industrial automation systems, offering robust communication capabilities, efficient network management, and precise time synchronization. Its compatibility with multiple protocols and controllers makes it a valuable choice for industries requiring reliable and scalable networking solutions. Whether integrating with legacy systems or deploying in new installations, the IC695ETM001 ensures seamless connectivity and operational efficiency.
